737NG TILLER PRO REAL FORCE FEEDBACK Installation and Operation Manual Version 2.1 - 03/2023 PRODUCT 289146 B737 Steering Tiller PRO Force Feedback Captain side 289147 B737 Steering Tiller PRO Force Feedback First Officer side ENGLISH ME172191 www.fsc.it Official website for information and support:...
C1 DRILLING TEMPLATE ..............18 APPENDIX D D1 POTENTIOMETER REPLACEMENT ..........19 APPENDIX E E1 MECHANICAL RE-ALIGNMENT / LOOSING THE KEYLESS LOCKING DEVICE .................21 HOW TO CONTACT SUPPORT ............22 DISCLAIMER All product names, logos, and brands are property of their respective owners. www.fsc.it...
1.1 BOX CONTENT AND FEATURES FSC 737NG TILLER PRO provides greater control of the aircraft during taxi operations. FSC 737NG TILLER PRO kit (CPT side SKU.289147shown), is composed by the following items: 1. 737NG Tiller pro (Built-in USB Interface) A) USB Cable 2.
Page 5
Installation and Operation Manual The FSC 737NG TILLER PRO kit is a no-compromise, reliable solution built for intensive use and ultimate realism, and provides very flexible features, letting to use it in a huge variety of situations and with most simulation software currently available: •...
B737 TILLER PRO - REAL FORCE FEEDBACK CHAPTER 2. INSTALLATION 2.1 HARDWARE INSTALLATION FSC 737NG TILLER PRO provides greater control of the aircraft during taxi operations. Fig.1 - Drilling template (B)- (see Chapter Fig.2 – Tiller body (1) on side panel.
Installation and Operation Manual 2.2 SOFTWARE SETTINGS AND CALIBRATION Generic Game Controller settings (to be calibrated before configuring FSUIPC or XPLANE) Plug the usb cable into PC. Press “START” menù and type “Joy.cpl” (Fig.1) Click on “Properties” and calibrate. (Fig.2) www.fsc.it...
Page 8
B737 TILLER PRO - REAL FORCE FEEDBACK Confirm wizard with NEXT button (Fig.3) Find center point and confirm with NEXT button (Fig. 4)
Page 9
Installation and Operation Manual Move axis from full left to full right to calibrate and select “Display raw data”. (Fig.5) Press APPLY to save calibration (Fig. 6) www.fsc.it...
Page 10
B737 TILLER PRO - REAL FORCE FEEDBACK XPLANE ONLY: One Tiller AXIS From “Settings” menu, select “Joystick, Keys & equipment”, select “axis” tab, move tiller to discover the axis, then assign it from the dropbox to “ Nose-wheel steering tiller”. FSX/P3D ONLY : NO Tiller AXIS, together with Rudder AXIS FSX/P3D With FSUIPC: One Tiller AXIS From “add ons”...
Page 11
From “Steering Tiller(direct!)” move the tiller to discover min,center & max values then press “Set” buttons to confirm values.. Magenta FBW with XPLANE/FSX/P3d: Two separate Tiller AXIS From FBW main page press “Calibrate” move Tiller to discover the axis. Near the axis press “Sel” to select and calibrate. www.fsc.it...
Page 12
B737 TILLER PRO - REAL FORCE FEEDBACK Under the calibration page select “Assign” button to assign the Axis “Tiller” or “Tiller F/O”.
Page 13
Then click: “Default” (arrow 8) for straight response, “Curve” (arrow 9) for progressive response (like in the picture). You can draw your own curve directly with your mouse pointer (arrow 10). To end calibration process, click “Lock Calibration” (arrow 11). www.fsc.it...
B737 TILLER PRO - REAL FORCE FEEDBACK CHAPTER 3. SETUP 3.1 ADJUSTING THE REACTION FORCE AND RETURN TO ZERO SPEED ADJUSTABLE FORCE FEEDBACK 2.0>6.2 Kg Reaction force adjustment (unit is factory-calibrated to optimal feeling) ADJUSTABLE DAMPING Return to zero speed adjustment ( every Tiller is factory-calibrated to optimal feeling ) CAUTION - Turn the screw few degrees at a time.
B737 TILLER PRO - REAL FORCE FEEDBACK APPENDIX C - C1 DRILLING TEMPLATE *This template is 1:1 scale. Please check with provided reference scale before drilling.
Installation and Operation Manual APPENDIX D - D1 POTENTIOMETER REPLACEMENT 3 mm Metric 1/8 inches SAE www.fsc.it...
Page 20
B737 TILLER PRO - REAL FORCE FEEDBACK 2 mm Metric 5/64 inches SAE FOR CORRECT CALIBRATION, POTENTIOMETER GEAR MUST BE ALIGNED AS IN FIGURE 90,00 Deg Please check potentiometer mechanical calibration (see Chapter 2.2 for procedure and Fig.5 for raw data value reading).
Set handle in right position and screw again the four screws in original position. Be careful to tight the four screws sequentially little by little. Please check potentiometer mechanical calibration (see Fig.5, Chapter 2.2). Pot is mechanically centered when X Axis value is as close to 2048 as possible. www.fsc.it...
ME172191 ww w.fsc.it FSC is a Research & Development Division of Professional Show S.p.A. FACTORY and DEMO ROOM MILAN Branch Via Praimbole, 15/bis Via Santa Maria, 83/85 35010 Limena (PD)
