  • Page 1 User Manual Modernist Built-In Fridge DRR24/30/36* Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 1 2017-03-20 5:36:15...

  • Page 2: Table Of Contents

    Critical usage warnings Usage cautions Cleaning cautions Critical disposal warnings What’s included Inside Parts, Storage, and Shelving Operations Control panel Dacor iQ Kitchen SMART GRID Function (Demand Response) Special features Handle and care Replacement Care and Maintenance Cleaning English Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 2...
  • Page 3 Troubleshooting General Do you hear abnormal sounds from the refrigerator? Auto Door Open (ADO) Dacor iQ Kitchen Smart Grid Warranty and Service Customer service Warranty Regulatory Notice FCC Notice IC Notice Open Source Announcement English 3 Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 3 2017-03-20 5:36:15...
  • Page 4 Website: www.Dacor.com Thank you for choosing Dacor for your home. We are a company built by families for families, and we are dedicated to serving yours. We are confident that your new Dacor product will deliver a high level of performance and enjoyment for many years to come.

  • Page 5: Important Information

    Serial Number Date of Purchase Since we continually improve the quality and performance of our products, we may make changes to the appliance without updating this manual. Visit www.dacor.com to download the latest version of this manual. Dacor Customer Service Phone: (800) 793-0093 (U.S.A.

  • Page 6: Safety Information

    Safety Information • Before using your new Dacor Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. • This appliance is not intended for use by persons (including children) with reduced...

  • Page 7: Important Safety Symbols And Precautions

    Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage.

  • Page 8: Critical Installation Warnings

    Safety Information Critical installation warnings WARNING • Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or fire. • Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.
  • Page 9 - Deteriorated insulation on electrical parts may cause an electric shock or fire. • If large amounts of dust or water enter the refrigerator, turn off the power switch and contact your Dacor service center. - Otherwise there is a risk of fire.

  • Page 10: Installation Cautions

    Safety Information • Only a qualified technician or service company should be allowed to change the fuse in the refrigerator. - Failing to do so may result in an electric shock or personal injury. Installation cautions CAUTION • Allow sufficient space around the refrigerator and install it on a flat surface. - Keep the ventilation space in the appliance enclosure or mounting structure clear of obstructions.

  • Page 11: Critical Usage Warnings

    Dacor service center. • If large amounts of dust or water enter the refrigerator, disconnect the power plug and contact your Dacor service center. - Otherwise there is a risk of fire. • Do not let children step on a drawer.
  • Page 12 Safety Information • Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter the refrigerator. • Do not allow babies or children go into a drawer. - It can cause death from suffocation by entrapment or personal injury. •...
  • Page 13 - Failing to do so may result in an electric shock, fire, problems with the product, or injury. • If the interior or exterior LED lamp has gone out, contact your nearest Dacor service center. • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact a Dacor service center.

  • Page 14: Usage Cautions

    • Service Warranty and Modification. - Any changes or modifications performed by a 3rd party on this finished appliance are not covered under Dacor warranty service, nor is Dacor responsible for safety issues that result from 3rd party modifications. • Do not block the air vents inside the refrigerator.

  • Page 15: Cleaning Cautions

    Cleaning cautions CAUTION • Do not spray water directly on the inside or outside the refrigerator. - There is a risk of fire or electric shock. • Do not use a hair dryer to dry the inside of the refrigerator. •...

  • Page 16: Critical Disposal Warnings

    Safety Information Critical disposal warnings WARNING • DANGER : Risk of child entrapment. Before you throw away your old refrigerator or freezer: - Take off the doors and door latch. - Leave the shelves in place so that children cannot easily climb inside. - Children trapped inside a refrigerator can hurt themselves or suffocate to death.

  • Page 17: What's Included

    What’s included Inside Parts, Storage, and Shelving 01 Power switch, Auto Door Open switch 02 Shelves 03 Door bins 04 Camera 05 Water dispenser 06 FreshZone 07 Control panel 08 Water filter (cover) English 17 Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 17 2017-03-20 5:36:16...
  • Page 18 What’s included Switch box • Use a flat head screwdriver to open the switch box cover. • The black one is the Power switch while the Auto Door Open switch is red next to it. • Close the switch box cover. English Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 18 2017-03-20...

  • Page 19: Operations

    Operations Control panel 01 Fridge / Power Cool 02 FreshZone 03 Deodorizer Reset 04 Filter Reset 05 Override 06 Door Alarm / °C  °F 07 Control Lock 08 Network connection 09 Sabbath mode 10 Cooling off NOTE • When you change the temperature on the panel, the panel displays the actual temperature inside the refrigerator until the temperature matches the temperature you set.
  • Page 20 Operations 01 Fridge / Power Cool (3 sec) The Fridge button can be used to set the fridge temperature, or to activate/deactivate Power Cool. You can manually adjust the cooling temperature for the fridge. Fridge The temperature indicator informs you of the currently set or selected temperature.
  • Page 21 CAUTION • Do not use the FreshZone for storing fruit or leafy vegetables. The food items may suffer cold-temperature damage. • Do not store glass bottles in the FreshZone in Chill/Meat mode. They may break and cause physical injury. 03 Deodorizer Reset (3 sec) After about 18 months of using the original deodorizer filter, the Filter indicator blinks red to remind you that the filter needs to be replaced.
  • Page 22 Operations 06 Door Alarm / °C  °F (3 sec) You can enable or disable the door alarm by pressing Door Alarm. When Door Alarm is enabled and a door is left open for more than 2 Door Alarm minutes, the alarm will sound and the alarm indicator will blink. The Door Alarm function is enabled by factory default.
  • Page 23 08 Network connection You can control and monitor your refrigerator through the Dacor iQ Kitchen app. For more information, see the Dacor iQ Kitchen section. NOTE • Recommended encryption systems include WPA/TKIP and WPA2/AES. Any newer or unstandardized Wi-Fi authentication protocols are not supported.
  • Page 24 Operations 10 Cooling Off Cooling Off mode (also called Shop mode) is designed for use by retailers when they are displaying refrigerators on a retail floor. In Cooling Off mode, the fan motor and lights operate normally, but the compressors do not run so the refrigerator does not get cold.

  • Page 25: Dacor Iq Kitchen

    Kitchen”. Download and install the Dacor iQ Kitchen app to your smart device. NOTE • The Dacor iQ Kitchen app is designed for Android 4.0 (ICS) or higher, or iOS 8.0 or higher. • For improved performance, the Dacor iQ Kitchen app is subject to change without notice, or discontinued support according to the manufacturer’s policy.
  • Page 26 Operations Category Item Description Displays the current temperature setting of the Fridge temperature fridge. FreshZone settings Displays the settings of the FreshZone. Monitoring Self Check Detects abnormal operations of the refrigerator. Checks the accumulated power consumption of Energy monitoring the refrigerator for the last 180 days. You can turn Power Cool on or off, and check Functions Power Cool...

  • Page 27: Smart Grid Function (Demand Response)

    SMART GRID Function (Demand Response) When the refrigerator operates in SMART GRID (Demand Response) mode, the Energy Management Refrigerator function can control energy usage or delay the operation of some functions to save money when energy prices or demand are the highest. NOTE •...
  • Page 28 Operations • Temporary Appliance Load Reduction (L4): The refrigerator responds to a TALR signal by aggressively reducing the load for a short time period. This function reduces energy consumption by stopping the compressor and controlling the functions that consume a lot of energy such as the defrost cycle and making ice.
  • Page 29 NOTE • Alternatively, you can activate or deactivate OVERRIDE mode using the Dacor iQ Kitchen app and the Energy Management function. See the next page. Using the Energy Management Function The Energy Management function enables you to control and monitor your Energy Management refrigerator using the Dacor iQ Kitchen app for your convenience.
  • Page 30 Operations Provision for Open Access to the Connected Product Requirements 1. SGIP Open Standards (Smart Energy Profile 2.0 - http://www.csep.org/) - Energy Consumption Reporting - Demand Response 2. OPEN API - Operational Status, User Settings & Messages - ICE Maker Status: GET /devices/0/Fridge/iceMaker - Door Open Alarm: GET /devices/0/Door/<<id>>/openState - DR Status: GET /devices/0/drlc - Delay Defrost Capability...

  • Page 31: Special Features

    Special features Water dispenser The dispenser lets you conveniently enjoy chilled water. To dispense chilled water, put a water glass on the dispenser lever and push it. Chilled water will be dispensed from the dispenser. CAUTION • For first-time use or after you have replaced the water filter, dispense 3 gallons of water (for about 6 minutes) to remove impurities from the water line beforehand.
  • Page 32 Operations Auto Door Open system The auto door open system helps the effortless opening of the door with the help of mechanical device. Gently push the door handle or door panel (in case of the handle-less door) Then, the door opens automatically. Touching or snapping does not trigger the auto door open system.
  • Page 33 NOTE • By default, the system is turned off. Turn the system on after turning the refrigerator on. • The system is not triggered immediately after the door is closed. Allow 2 seconds and try again. This is not a system failure. •...

  • Page 34: Handle And Care

    Operations Handle and care Tempered glass shelves To remove a shelf, fully open the corresponding door. Hold the front of the shelf, and then gently lift up and slide out. To reinsert, hold the shelf at an angle so the front is higher than the back, and then insert the top hook into the top shelf notch.
  • Page 35 Door bins To remove, lift up the door bin, and then pull out straight. CAUTION The door bin has 4 fitting holes, 2 for each side. When reinserting the door bin, make sure the 2 holes on one side of the door bin fit into 2 guiding fittings on the corresponding side of the door.
  • Page 36 Operations Metal Shelf By design, the drawer covers lock into the tabs on each corner of both walls. To attach or detach the cover, make sure the cover locks into or is released from the tabs. To detach the cover, hold both front sides of the cover.

  • Page 37: Replacement

    • Do not use third-party water filters. Use only Samsung-provided or -approved filters. • Unapproved filters may leak and damage the refrigerator, causing electric shock. Dacor is not responsible for any damage that may occur from use of third-party water filters.
  • Page 38 • The replacement process may cause the water dispenser to drip for a short period of time. If it drips, simply wipe up any water on the floor with a dry towel. Ordering a new filter To purchase a new water filter, contact a local service agent or Dacor Customer Service at (800) 793-0093. English Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 38...
  • Page 39 NOTE The lifecycle of the deodorizer filter is 18 months, which differs depending on the use conditions. You can purchase a new filter at a local Dacor service center. LED Lights To replace the LED lights on the refrigerator, contact a local service agent. Contact Dacor Customer Service at (800) 793-0093.

  • Page 40: Care And Maintenance

    Care and Maintenance Cleaning WARNING • Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning. They may damage the surface of the refrigerator and cause a fire. • Do not spray water onto the refrigerator. This may cause electric shock. •...

  • Page 41: Troubleshooting

    Troubleshooting Before calling for service, review the checkpoints below. Any service calls regarding normal situations (No Defect Cases) will be charged to users. General Temperature Symptom Possible causes Solution • Power cord is not plugged • Properly plug in the power in properly.
  • Page 42 Troubleshooting Frost Symptom Possible causes Solution Frost around the • Make sure no food blocks • Food is blocking the vents. vents. the refrigerator vents. • Make sure food does not Frost on interior • Door is not closed properly. block the door.
  • Page 43 Symptom Possible causes Solution • Check the water installation conditions. • Water line is not connected properly or water supply is not on. Water does not dispense. • Use only Samsung-provided or approved filters. • Do not use third-party • Unapproved filters may water filters.

  • Page 44: Do You Hear Abnormal Sounds From The Refrigerator

    Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal. • When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting.
  • Page 45 • As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling! • As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working.

  • Page 46: Auto Door Open(Ado)

    Troubleshooting Auto Door Open (ADO) Symptom Action • Turn on Auto Door Open switch. (factory setting is turn off about Auto Door Open switch) • In case of trying to open again directly after use of Auto Door Open(ADO) refrigerator, Auto Door Open system can not working is not working.

  • Page 47: Dacor Iq Kitchen

    In this case, use the Dacor iQ Kitchen app to connect and refrigerator. register your refrigerator to the access point (AP) of your house.

  • Page 48: Smart Grid

    • To use the Smart Grid (Demand Response) and Energy Management function on your Refrigerator, you need the following devices and apps: - Devices: 1) A Wireless Router, 2) A Dacor iQ Kitchen Refrigerator, 3) A Smartphone. (Recommended: Android OS Jelly Bean or later version) - Applications: 1) “Dacor iQ Kitchen App”...
  • Page 49 • Confirm that the rear where you live is properly entered into working normally? the Dacor iQ Kitchen App. • Confirm that the Smart Grid function works correctly. (Check the control panel. The DAL or TALR icon should not be displayed on the panel.)

  • Page 50: Warranty And Service

    3. If none of these tips or suggestions resolves your problem, call our Customer Service center at the number below. Dacor’s Customer Service center is available 6:00 a.m. to 5:00 p.m. Pacific Time. For warranty repairs or questions and for Dacor Distinctive Service (DDS) in the US and Canada Phone: (800) 793-0093...
  • Page 51 All Dacor products must be accessible for service. All cosmetic damage (such as scratches on stainless steel, paint/ porcelain blemishes, etc.) to the product or included accessories must be reported to Dacor within 60 days of the original purchase date to qualify for warranty coverage.
  • Page 52 Warranty and Service If your Dacor product fails to function within one year of the original date of purchase due to a defect in material or workmanship, Dacor will furnish a new part, F.O.B. factory to replace the defective part.
  • Page 53 ARE LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE. IN NO EVENT SHALL DACOR BE LIABLE FOR INCIDENTAL EXPENSE OR CONSEQUENTIAL DAMAGES. IN THE EVENT DACOR PREVAILS IN ANY LAWSUIT, DACOR SHALL BE ENTITLED TO REIMBURSEMENT OF ALL COSTS AND EXPENSES, INCLUDING ATTORNEY’S FEES, FROM THE DACOR CUSTOMER.

  • Page 54: Regulatory Notice

    Regulatory Notice FCC Notice FCC CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Contains Transmitter Module FCC ID: A3LWIDT30Q This device complies with Part 15 of FCC Rules. Operation is Subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause...

  • Page 55: Ic Notice

    IC Notice Contains Transmitter Module IC: 649E-WIDT30Q The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met. Operation is subject to the following two conditions : (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 56: Open Source Announcement

    Open Source Announcement The software included in this product contains open source software. You may obtain the complete corresponding source code for a period of three years after the last shipment of this product by sending an email to mailto:oss.request@samsung.com. It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM;...
