- Page 1 09/2018 Mod: MIC-36B/R6 Production code: UPD60-I BLACK...
- Page 2 Model: UPD60-UPD80 Content Important safety instructions Unpacking and installation Electrical connection Start-up of the cabinet Thermostat Defrosting Maintenance and cleaning Service Disposal 280-120424...
- Page 3 Important safety instructions 1. To obtain full use of the cabinet, we recommend reading this instruction manual. 2. It is the user’s responsibility to operate the appliance in accordance with the instructions given. 3. Contact your dealer immediately in case of any malfunctions. 4.
- Page 4 Electrical connecting The cabinet operates on 230 V/50 Hz. The wall socket should be easily accessible. All earthing requirements stipulated by the local electricity authorities must be observed. The cabinet plug and wall socket should then give correct earthing. If in doubt, contact your local supplier or authorized electrician.
- Page 5 Thermostat The thermostat is placed in the control panel, see fig. 2.0. Fig. 2.0 The thermostat has been pre-set and in most cases it is not necessary to adjust the settings. When turning on the cabinet the display will show the current temperature in the cabinet. Display set temperature: Press this key and the display will show the set temperature.
- Page 6 Defrosting The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the contents of the cabinet is changed frequently it may become necessary to defrost the cabinet manually. Pressing this key continuously for more than 3 seconds will start a manual defrosting and then return to normal operation.
