Timberk AC TIM 09HI R1R Instruction Manual page 5

Model
Indoor unit
Outdoor unit
Degree of protection against moisture (outdoor unit)
Refrigerant piping, Liquid side / Gas side, (inch)
Max. refrigerant pipe length, m
Maximum difference in level, m
Filling of Freon, g
Operating temperature range: cooling, ° C
Operating temperature range: heating, ° C
Net weight, indoor unit (kg)
Net weight, outdoor unit (kg)
Gross weight, indoor unit (kg)
Gross weight, outdoor unit (kg)
Net dimensions, indoor unit (mm)
Net dimensions, outdoor unit (mm)
Packing dimensions, indoor unit (mm)
Packing dimensions, outdoor unit (mm)
AC TIM 09HI R1R
AC TIM 09HI R1R
AC TIM 09HI R1R-01
IPX4
1/4 / 3/8
15
5
680
+18 ~ +43
-7 ~ + 24
7
28
10
32
718x240x180
700x256x552
805x305x255
803x325x600
www.timberk.com • Electric air conditioner
5
