11Mbps 802.11b Wireless AP with 4-Port Router + USB Adapter
Blitzz Connect! Quick and Easy!
Wi r el e ss Network Ki t
user's manual
model:BWK800

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BWK800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blitzz BWK800

  • Page 1 11Mbps 802.11b Wireless AP with 4-Port Router + USB Adapter Blitzz Connect! Quick and Easy! Wi r el e ss Network Ki t user's manual model:BWK800...
  • Page 2 Copyright All rights reserved. No part of this document may be reproduced in any format or by any means without written permission from Blitzz Technology Inc. Changes are periodically made to the information in this document. They will be incorporated in subsequent editions. The supplier may make improvements and/or changes in the product described in this document at any time.
  • Page 3 Technical support Up-to-date information Your new purchased Blitzz product is updated with the latest technology and design. However, we keep going to modify and update the product features to keep you with up-to-date technologies with firmware or software upgrade. You can visit our web site on http://www.iBlitzz.com to check if there is new...

  • Page 4: Table Of Contents

    Table of contents CHAPTER 1 INTRODUCTION ..........1 ...............1 RODUCT OVERVIEW ..............1 EATURES AND BENEFITS ’ ? ..............3 S IN THE PACKAGE ..........4 MPORTANT RULES FOR SAFE OPERATION WLAN R - BWA611 .............7 OUTER - BWP612 ............11 OTEBOOK ADAPTER - BWU613............. 12 ADAPTER CHAPTER 2 BUILD UP YOUR NETWORK –...
  • Page 5 Wireless Network Kit - User’s Manual...

  • Page 6: Chapter 1 Introduction

    Introduction Chapter 1 Introduction Product overview The Blitzz wireless network kit includes IEEE 802.11b compliant wireless Router and network adapter. It offers the easiest way to share files, printers and high-speed Internet connection. Features and benefits BWA611, BWP612 and BWU613 Features 11Mbps data rate by incorporating Direct Sequence Spread Spectrum technology.
  • Page 7 Introduction BWA611 WLAN Router with 4-port switch Broadband access sharing via Cable/DSL modem. Included 4-Port 10/100Mbps Fast Ethernet switch for fast local data exchange. 10/100Mbps Auto-sensing Ethernet for easy installation. Plug and play! Dynamic Host Configuration Protocol client and server (DHCP). Point-to-Point Protocol over Ethernet (PPPoE).

  • Page 8: Hats In The Package

    Introduction What’s in the package? BWA611 Wireless AP Router with 4-Port Switch Power adaptor Ethernet cable (USB cable comes with USB adapter) Ethernet USB adapter or Notebook adapter Software CD, Quick Installation Guide & User’s Manual Wireless Network Kit - User’s Manual...

  • Page 9: Important Rules For Safe Operation

    Introduction All packages have been checked carefully for their completeness and functionality before shipped. Please contact the place of purchase if any of the above listed items are missing or damaged. If you encountered any difficulty in using this product while all the above items are complete, please refer to Appendix C for Troubleshooting information before making the decision to return your Wireless LAN AP Router to your dealer.
  • Page 10 Introduction fire hazard. Periodically examine the cord, and if its appearance indicates damage or deteriorated insulation, have it replaced by your service technician. Protect Power Cords - Route power supply cords so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords where they are attached to plugs and convenience receptacles, and examine the point where they exit from the product.
  • Page 11 Introduction Keep Objects Out of Openings - Never push objects of any kind into this product through openings, as they may touch dangerous voltage or “short-out” parts, which could result in a fire or electric shock. Never spill liquid on the product. Protect From Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet, and disconnect the cable system.

  • Page 12: Wlan Router - Bwa611

    Introduction WLAN Router - BWA611 The BWA611 Wireless AP Router has 7 status LEDs for diagnostics. You can monitor the LEDs during operation. Following table shows the router status LEDs and identifies what each LED light means. Function Behavior Definition POWER Dark Power off...
  • Page 13 Introduction The rear panel of the BWA611 Wireless AP Router with 4-Port Switch consist of power jack, Local (LAN) Ports and Internet (WAN) connector and default button as shown below: Remove the label covered on the connectors. Peel off the indication label and place it below the sockets or on top of BWA611.
  • Page 14 Introduction The rear panel of the BWA611 Wireless AP Router with 4-Port Switch consist of power jack, Local (LAN) Ports and Internet (WAN) connector and default button as shown below: Power Socket The power adapter round terminal plugs into the socket labeled “DC 5V”. WAN (Internet) Port The BWA611 Wireless AP Router supports an Ethernet port for WAN (Internet) connection.
  • Page 15 Introduction least 15 seconds. The BWA611 will restore the Wireless AP Router’s default settings and you can configure the Wireless AP Router again. Factory Default Password: The default password of BWA611 is no password. You are strongly suggested to setup a password to prevent unauthorized changing of BWA611 settings.

  • Page 16: Notebook Adapter - Bwp612

    Introduction Notebook adapter - BWP612 The BWP612 Wireless CardBus PC Card has two status LEDs for diagnostics. You can monitor the LEDs during operation. Function Behavior Definition Link Dark BWP612 not enabled or not inserted complete Flashing Search for wireless link Solid Wireless link established Dark...

  • Page 17: Usb Adapter - Bwu613

    Introduction USB adapter - BWU613 The BWU613 Wireless USB Adaptor has 3 status LEDs show the wireless linking status. Function Behavior Definition Power Dark Power Off Green Wireless adapter is ready Dark Wireless link has no data received Flashing Wireless link data received Dark Wireless link has no data transmitted Flashing...

  • Page 18: Chapter 2 Build Up Your Network - Step By Step

    Build up your network – step by step Chapter 2 Build up your network – step by step Below is a simple and typical network setup. We are going to lead you to setup your wireless network step by step from this simple network setup. Maybe you have more than one computer to share your broadband connection through the router, build up a server in your local network, or setup a network within the corporate network.

  • Page 19: Start From A Simple Network

    Build up your network – step by step Start from a simple network 2.1.1. Install your network adapter Before we go on to get all network components (broadband modem, WLAN router, and your computer) together, we have to make them network connectable.
  • Page 20 Build up your network – step by step Driver and Wireless LAN Utility Installation 1. Insert Blitzz NetWave Software and Utility CD into your CD-ROM drive. The installation shell will be running automatically. (If not, please run autorun.exe in the CD-ROM. Click on BWP612 Wireless notebook adapter product image.
  • Page 21 Build up your network – step by step 3. Click on the Windows version you have to install the driver and Wireless LAN Utility. 4. The install shell will start to install. Wireless Network Kit - User’s Manual...
  • Page 22 Build up your network – step by step 5. Click on Next to make sure you want to install driver and Wireless LAN Utility. 6. If you want to change the directory of Wireless LAN Utility, change it now. Click Next to continue. Wireless Network Kit - User’s Manual...
  • Page 23 Build up your network – step by step 7. Select a program folder or click Next directly to use default folder. 8. You have one more chance to check if all setup information is correct or not. Click Back to change your setup or click Next to continue. Wireless Network Kit - User’s Manual...
  • Page 24 Build up your network – step by step 9. Click Finish to complete on the software installation and restart your computer. Wireless Network Kit - User’s Manual...
  • Page 25 Build up your network – step by step Hardware Installation 1. Find an available Type II or Type III PCMCIA slot in your notebook computer. 2. With the PCMCIA adapter’s 68-pin connector facing the PCMCIA slot and its label facing up, slide the PCMCIA adapter completely into the PCMCIA slot. The PCMCIA slot allows “hot swap”...
  • Page 26 Build up your network – step by step BWU613 USB adapter Do not plug-in your BWU613 Wireless USB Adapter yet. Although, you can install the driver through traditional plug-and-play. We recommend you install driver and Wireless LAN Utility by following steps before hardware installation.
  • Page 27 Build up your network – step by step Driver and Wireless LAN Utility Installation 1. Insert Blitzz NetWave Software and Utility CD into your CD-ROM drive. The installation shell will be running automatically. (If not, please run autorun.exe in the CD-ROM. Click on BWU613 Wireless USB Adaptor product image.
  • Page 28 Build up your network – step by step 3. Click on the Windows version you have to install the driver and Wireless LAN Utility. 4. The install shell will start to install. 5. Click on Next to make sure you want to install driver and Wireless LAN Utility.
  • Page 29 Build up your network – step by step 6. If you want to change the directory of Wireless LAN Utility, change it now. Click Next to continue. 7. Select a program folder or click Next directly to use default folder. Wireless Network Kit - User’s Manual...
  • Page 30 Build up your network – step by step 8. You have one more chance to check if all setup information is correct or not. Click Back to change your setup or click Next to continue. 9. Click Finish to complete on the software installation and restart your computer.
  • Page 31 Build up your network – step by step Hardware Installation 1. Find an available USB socket in your computer. 2. Plug one flat end (USB type A) of USB cable into any USB jack on your computer. Plug the other end, square end (type B) of USB cable into USB socket on BWU613 Wireless LAN USB Adaptor.
  • Page 32 Build up your network – step by step Ethernet network adapter The BWA611 has also 4 local Ethernet ports which allow you to connect to local computers with Ethernet cable. Please follow your Ethernet card Attention user’s manual to install your card properly. Double check if your Ethernet network card is installed properly or not.

  • Page 33: Set Up Tcp/Ip To Auto Configuration

    Build up your network – step by step 2.1.2. Set up TCP/IP to auto configuration TCP/IP protocols are the foundation of the Internet communication. Whether you are browsing webs or checking e-mails, you need to set up TCP/IP Definition protocol. (See glossary on page 93 for detail) If your network adapter is newly installed, your TCP/IP protocol will be setup to auto configuration by default.
  • Page 34 Build up your network – step by step Protocol dialog box displays. 5. Click on Microsoft in the Manufacturers list box, and then click TCP/IP in the Network Protocols list box. 6. Click to return to the Network dialog box, and then click again.
  • Page 35 Build up your network – step by step Windows NT4.0 First, check for the IP protocol and, if necessary, install it: 1. In the Windows NT task bar, click the Start button, point to Settings, and then click Control Panel. 2.
  • Page 36 Build up your network – step by step Windows 2000 First, check for the IP protocol and, if necessary, install it: 1. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel. 2. Double-click the Network and Dial-up Connections icon. 3.
  • Page 37 Build up your network – step by step Protocol (TCP/IP), and then click 11. In the Internet Protocol (TCP/IP) Properties dialog box, click the radio button labeled Obtain an IP address automatically. Also click the radio button labeled Obtain DNS server address automatically. 12.
  • Page 38 Build up your network – step by step 8. If prompted, click to restart your computer with the new settings. Next, configure the PCs to accept IP information automatically: 9. In the Control Panel, double-click the Network and Dial-up Connections icon. 10.

  • Page 39: Connect To The Router

    Wireless connection with Blitzz WLU The Blitzz WLU (Wireless LAN Utility) will be installed automatically while you install the BWP612 and BWU613 driver. You can found Blitzz WLU icon ( will on the right hand side of start menu. Windows XP uses Windows XP has its built-in Wireless LAN Utility.
  • Page 40 2. Click on the Wireless Networks tab. Clear Use Windows to configure my wireless network settings check box. Click OK to release the control of wireless network. 3. Run the Blitzz WLU from menu and the Blitzz WLU icon ( ) will showup. Wireless Network Kit - User’s Manual...
  • Page 41 If you didn’t make your wireless link at the first time, try the following steps to search and link to base station: 1. Double click on Site Survey tab. The Blitzz WLU will look Quick Fix for all available wireless base stations (access points) in the area and list them on the table.
  • Page 42 Build up your network – step by step Click on Rescan button to look for all available wireless stations in your area. (If you still cannot have any station listed, check your BWA611. Is it powered on and working properly?) 2.
  • Page 43 Microsoft WLU. However, if you want to switch from Blitzz WLU to Microsoft WLU after you startup Blitzz WLU: right click on the Blitzz WLU icon ( ) and click Exit. The Microsoft WLU will take over the wireless management immediately.

  • Page 44: Establish Local Communication

    Build up your network – step by step 2.1.4. Establish local communication Until now, you should complete your physical connection. Let’s double check if your communication is okay or not. From your computer, open your web browser, type the following URL in the web address (or location) box, and press <Enter>: http://192.168.1.254 A login screen displays.

  • Page 45: Connect To The Internet

    Build up your network – step by step 2.1.5. Connect to the Internet Cable Modem connection If you have a cable modem connection, simply connect your cable modem Ethernet port and BWA611 Internet(WAN) port with an Ethernet cable. Double check if both the cable modem LAN and BWA611 Internet indicators are light or flashing.
  • Page 46 Build up your network – step by step Click Network Status > WAN IP Status. Then you can see the current Internet connection status. After the device is connected to the Internet Service, you will see IP, Subnet Mask, Gateway and DNS IP addresses on the table.
  • Page 47 Build up your network – step by step ADSL Modem connection If you have a ADSL connection, you need to know what type of ADSL connection you have and configure your BWA611. You can use the questionnaire below to determine which type of ADSL you have, or you can ask your ADSL service provider what type of ADSL you have.
  • Page 48 Build up your network – step by step Login to BWA611 configuration manager If you are using ADSL connection, you need to login to BWA611 to enter ADSL connection information to go on-line. From your computer, open your web browser, type the following URL in the web address (or location) box, and press <Enter>: http://192.168.1.254 A login screen displays.
  • Page 49 Build up your network – step by step ADSL PPPoE If you have an ADSL PPPoE connection, select PPPoE (DSL dynamic mode) and you will see the Global Port – DSL dynamic mode page Remove old PPPoE software from your computer if there is one installed.
  • Page 50 Build up your network – step by step Device Information Adapter Address: (Most users don’t need to change this setup. See FAQ for more detail.) If your ISP is asking a special MAC address to log in, please check on Modify and key-in your network card MAC address here.
  • Page 51 Build up your network – step by step Static DNS Server, Primary, Secondary: Check Static DNS Server if your ISP asked you to do so. Fill in correct DNS IP addresses in the primary and secondary DNS IP fields. Auto-disconnect: If your DSL service is charged by the time of connection, you probably want BWA611 disconnect your DSL service if there is no traffic pass through for amount of time.
  • Page 52 Build up your network – step by step ADSL Always-on with static IP(s) Select Static configuration and you will see the Global Port – Static mode page Select Static configuration Enter static IP information Also enter DNS information Remember to manually click save after you enter all...
  • Page 53 Build up your network – step by step Domain Name: Enter your domain name. Any name is acceptable. (Some ISP will ask to enter a special name to connect to network. Consult your ISP or network manager for detail.) IP Address IP Config: This is set to Static because Static configuration mode.
  • Page 54 Build up your network – step by step ADSL Always-on with dynamic IP(s) This setting is the same as cable modem configuration. Select Obtain configuration automatically. Click save and it’s done. Wireless Network Kit - User’s Manual...
  • Page 55 Build up your network – step by step Wireless Network Kit - User’s Manual...

  • Page 56: Appendix A Technical Specifications

    Appendix Appendix A Technical specifications BWA611 Wireless LAN Router with 4-port switch Data Rate: 11, 5.5, 2, 1Mbps auto adaptive Modulation: DSSS (BPSK, QPSK, CCK) WAN (Ethernet) Port: MDI/MDIX auto sense X 1 Interface: Interface: IEEE 802.3u (10/100Base-T) Connector: 8 pin modular (RJ-45) WLAN Interface: Port: 11Mbps wireless (2.4GHz) Interface: IEEE 802.11b...
  • Page 57 Appendix Supported protocols: TCP/IP, NAT, ARP, ICMP, DHCP client/server, PPPoE, PPP, PAP, CHAP, NTP, HTTP, TFTP, POP3 EMC Emission: FCC part 15, class A Power: Power input: 5VDC/ 2A Mechanical: Size: 6.3” (W) x 5.0” (D) x 1.1” (H) Net Weight: 9 oz Environmental: Operating temperature: 32°F ~ 122°F Humidity: 5 % ~ 95 % (non-condensing)
  • Page 58 Appendix BWA612 Wireless notebook adapter Data Rate: 11, 5.5, 2, 1Mbps auto adaptive Modulation: DSSS (BPSK, QPSK, CCK) WLAN Interface: Port: 11Mbps wireless (2.4GHz) Interface: IEEE 802.11b Antenna: Build-in diversity PCB patch antenna Computer Interface: Port: Card Bus Interface Interface: Type II PCMCIA Connector: 68-pin connecter Human Interface: LED Indicator: Link, Wireless activity...
  • Page 59 Appendix BWU613 Wireless USB adapter Data Rate: 11, 5.5, 2, 1Mbps auto adaptive Modulation: DSSS (BPSK, QPSK, CCK) WLAN Interface: Port: 11Mbps wireless Interface: IEEE 802.11b (2.4GHz) Antenna: omni directional antenna Computer Interface: Port: USB interface Interface: USB 1.1 Connector: USB type B Human Interface: LED Indicator: Power, TX, RX Coverage Area:...

  • Page 60: Appendix B Frequent Asked Questions

    Appendix Appendix B Frequent asked questions BWA611 Q: When should I modify the MAC address for global port settings? A: Some ISPs identify their clients by the accessing MAC address and the host names, therefore, entering these information is the process required to prove they are who they claim to be.
  • Page 61 Appendix Q: What is Dynamic DNS? A: The Dynamic DNS service, an IP Registry provides a public central database where information such as email addresses, hostnames, IPs etc. can be stored and retrieved. This solves the problems if your DNS server uses an IP associated with dynamic IP.
  • Page 62 Appendix is thus built. If the “primary” mail host goes down, instead of queuing up the mails in the unreliable host on the Internet, they get sent to the “secondary” or “backup” mail exchanger for delivery, until the primary mail server becomes functional again.

  • Page 63: Appendix C Troubleshooting

    Appendix Appendix C Troubleshooting This chapter is intended to help you troubleshoot problems you may encounter while setting up and using the BWA611 Wireless LAN Router. It also describes some common hardware and software problems and gives some suggestions to troubleshoot them. Refresh your IP address (MS Windows) Sometimes you will wonder what my computer’s IP is or you want to refresh your IP address.
  • Page 64 Appendix double check each workstation’s IP address for any duplicate IP. Can not access the Internet Check the physical connectivity of local network. Check if both the LEDs of Local and Global on the product’s front panel are lit. Make sure you are using the correct cables and the cables are connected to the network devices properly.

  • Page 65: Appendix D Driver Only Installation

    Appendix Appendix D Driver only installation BWP612 notebook adapter Windows 98 Second Edition 1. Insert the 11Mbps Wireless notebook adapter into a standard type II PCMCIA slot in your notebook. 2. Windows 98 will automatically detect the new hardware and prompt you to install the driver needed.
  • Page 66 Appendix 3. Select Search for the best driver for your device is using now and click Next. 4. Insert Wireless Driver and Utility CD and select Specify a location and click Browse to provide the path (e.g. D:\drv612\Win9xMe), then click Next.
  • Page 67 Appendix 5. Windows 98 will find your BWP612 Wireless notebook adapter. Now click Next. 6. Windows 98 will ask you to insert Windows CD. Please inset the CD and click OK. 7. Click Finish to complete the software installation. Wireless Network Kit - User’s Manual...
  • Page 68 Appendix 8. Click Yes to restart the computer. 9. Open Control Panel>System>Device Manager, and check Network Adapters to see if any error icon appears. If no, your BWP612 Wireless notebook adapter is properly installed. Wireless Network Kit - User’s Manual...
  • Page 69 Appendix Windows Millennium Edition 1. Insert the 11Mbps Wireless notebook adapter into a standard type II PCMCIA slot in your notebook. 2. Windows ME will automatically detect the new hardware and prompt you to install the driver needed. Select Search for the best driver for your device and click Next. Wireless Network Kit - User’s Manual...
  • Page 70 Appendix Insert Wireless Driver and Utility CD and select Specify a location and click Browse to provide the path (e.g. D:\drv612\Win9xMe), then click Next. Windows ME will find your BWP612 Wireless notebook adapter. Now click Next. Wireless Network Kit - User’s Manual...
  • Page 71 Appendix Click Finish to complete the software installation. 7. Click Yes to restart the computer. 8. Open Control Panel>System>Device Manager, and check Network Adapters to see if any error icon appears. If no, your BWP612 Wireless notebook adapter is properly installed. Wireless Network Kit - User’s Manual...
  • Page 72 Appendix Windows 2000 1. Insert the 11Mbps Wireless notebook adapter into a standard type II PCMCIA slot in your notebook. Windows 2000 will automatically detect the new hardware and prompt you to install the driver needed. 2. Select “Search for a suitable for my device automatically [recommended]”...
  • Page 73 Appendix 3. Insert BWP612 Software and Utility CD into your CD-ROM drive and check on the Specify a location, then click Next. 4. Click Browse or enter the proper directory on CD (e.g. E:\drv612\Win2kXP), then click OK. Wireless Network Kit - User’s Manual...
  • Page 74 Appendix 5. Windows 2000 will find BWP612 Wireless LAN Notebook Adaptor. Now click Next. 6. BWP612 driver is updated from time to time. Sometime, you may found the driver has no Microsoft digital signature. That’s fine, just click Yes to continue installation.
  • Page 75 Appendix 7. Click Finish to complete the software installation. 8. Open Control Panel>System>Device Manager, and check Network Adapters to see if any error icon appears. If no, your BWP612 Wireless notebook adapter is working well. Wireless Network Kit - User’s Manual...
  • Page 76 Appendix Windows XP 1. Insert the 11Mbps Wireless notebook adapter into a standard type II PCMCIA slot in your notebook. Windows XP will automatically detect the new hardware and prompt you to install the driver needed. Insert the BWP612 Software and Utility CD into your CD drive. Select “Install from a list or specific location [Advanced]”...
  • Page 77 Appendix 3. Windows XP will find BWP612 Wireless LAN notebook adaptor. Since the BWP612 driver will be updated to enhance performance frequently, sometimes you will see the Microsoft reminder as the screen below. Click Continue Anyway to continue 4. Click Finish to complete the software installation. Wireless Network Kit - User’s Manual...
  • Page 78 Appendix 5. You can keep go on to setup your network setups follow Windows XP’s instructions. Wireless Network Kit - User’s Manual...
  • Page 79 Appendix BWU613 USB adapter Windows 98 Second Edition 1. Insert the BWU613 Wireless LAN USB Adapter into an available USB port on your computer. 2. Windows 98 will automatically detect the new hardware and prompt you to install the driver needed. 3.
  • Page 80 Appendix 4. Insert Wireless Driver and Utility CD and select Specify a location and click Browse to provide the path (e.g. D:\drv613\Win9xMe), then click Next. 5. Windows 98 will find your BWU613 Wireless USB Adaptor. Now click Next. Wireless Network Kit - User’s Manual...
  • Page 81 Appendix 6. Windows 98 will ask you to insert Windows CD. Please inset the CD and click OK. 7. Click Finish to complete the software installation. 8. Restart the computer. Wireless Network Kit - User’s Manual...
  • Page 82 Appendix 9. Open Control Panel>System>Device Manager, and check Network Adapters to see if any error icon appears. If no, your BWU613 Wireless USB Adaptor is properly installed. Wireless Network Kit - User’s Manual...
  • Page 83 Appendix Windows Millennium Edition 1. Insert the BWU613 Wireless LAN USB Adapter into an available USB port on your computer. 2. Windows ME will automatically detect the new hardware and prompt you to install the driver needed. 3. Select Search for the best driver for your device and click Next. Wireless Network Kit - User’s Manual...
  • Page 84 Appendix 4. Insert Wireless Driver and Utility CD and select Specify a location and click Browse to provide the path (e.g. D:\drv613\Win9xMe), then click Next. 5. Windows ME will find your BWU613 Wireless USB Adaptor. Now click Next. Wireless Network Kit - User’s Manual...
  • Page 85 Appendix 6. Click Finish to complete the software installation. 7. Restart the computer. 8. Open Control Panel>System>Device Manager, and check Network Adapters to see if any error icon appears. If no, your BWU613 Wireless USB Adaptor is properly installed. Wireless Network Kit - User’s Manual...
  • Page 86 Appendix Windows 2000 1. Insert the BWU613 Wireless LAN USB Adapter into an available USB port on your computer. 2. Windows 2000 will automatically detect the new hardware and prompt you to install the driver needed. Select “Search for a suitable for my device automatically [recommended]”...
  • Page 87 Appendix 3. Insert BWU613 Software and Utility CD into your CD-ROM drive and check on the Specify a location, then click Next. 4. Click enter or Browse the proper directory on CD, then click OK. Wireless Network Kit - User’s Manual...
  • Page 88 Appendix 5. Windows 2000 will find BWU613 Wireless LAN USB Adaptor. Now click Next. 6. BWU613 driver is updated from time to time. Sometime, you may found the driver has no Microsoft digital signature. That’s fine, just click Yes to continue installation.
  • Page 89 Appendix 7. Click Finish to complete the software installation. 8. Open Control Panel>System>Device Manager, and check Network Adapters to see if any error icon appears. If no, your BWU613 Wireless USB Adaptor is working well. Wireless Network Kit - User’s Manual...
  • Page 90 Appendix Windows XP 1. Insert the BWU613 Wireless LAN USB Adapter into an available USB port on your computer. 2. Windows XP will automatically detect the new hardware and prompt you to install the driver needed. Insert the BWU613 Software and Utility CD into your CD drive.
  • Page 91 Appendix 3. Select the location where the corresponding driver is placed(e.g. E:\drv613\Win2kXP), then click Next. 4. Windows XP will find BWU613 Wireless LAN USB Adaptor. Since the BWU613 driver will be updated to enhance performance frequently, sometimes you will see the Microsoft reminder as the screen below. Click Continue Anyway to continue Wireless Network Kit - User’s Manual...
  • Page 92 Appendix 5. Click Finish to complete the software installation. 6. You can keep go on to setup your network setups follow Windows XP’s instructions. Wireless Network Kit - User’s Manual...
  • Page 93 Appendix Appendix E Glossary 100Base-T IEEE 802.3u standard for the use of Ethernet LAN technology over unshielded twisted pair wiring, running at 100Mbps. Access Point An inter-networking device that seamlessly connects wired and wireless networks. Ad-Hoc An Ad-Hoc wireless LAN, also called peer-to-peer network, is a group of computers each with wireless adapters, connected as an independent wireless LAN.
  • Page 94 Appendix Backbone The core infrastructure of a network. A portion of the network that transports information from one central location to another central location where it is off-loaded onto a local system. Base Station In mobile telecommunications, a base station is the central radio transmitter/receiver that maintains communications with the mobile radio telephone sets within range.
  • Page 95 Appendix Stands for “Extended Service Set.” More than one BSS can be configured as an Extended Service Set. Mobile users can roam between BSS in an ESS. Ethernet A popular local area data communications network protocol, originally developed by Xerox Corp., which accepts transmission from computers and terminals.
  • Page 96 Appendix Internet A set of networks connected together by routers. This is a general term, not to be confused with the large, multi-organizational collection of IP networks known as the Internet. An internet is sometimes also known as an internetwork. Internet address, IP address Any computing device that uses the Internet Protocol (IP) must be assigned an internet or IP address.
  • Page 97 Appendix Roaming A wireless client around an ESS and get the continuous connection to the Infrastructure network. PCMCIA Personal Computer Memory Card International Association, which develops standards for PC cards, formerly known as PCMCIA cards, are available in three "types" which are about the same length and width as credit cards, but range in thickness from 3.3 mm (Type I) to 5.0 mm (Type II) to 10.5 mm (Type III).
  • Page 98 Appendix provide WAN line support to the LAN devices they serve. They may also provide various management and monitoring functions as well as a variety of configuration capabilities. RTS Threshold Transmitters contending for the medium may not hear each other. RTS/CTS mechanism can solve this "...
  • Page 99 Appendix TELNET Internet standard protocol for remote terminal emulation that allows a user to remotely log in to another device and appear as if directly connected. Wide Area Network - A network that consists of nodes connected by long-distance transmission media, such as telephone lines. WANs can span a state, a country, or even the world.

  • Page 100: Appendix F Government Compliance Notices

    Appendix Appendix F Government compliance notices FCC compliance This equipment complies with Part 15 of the FCC Rules. On this equipment is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment. You must, upon request, provide this information to your telephone company.
  • Page 101 Appendix For the safety reason, people should not work in a situation which RF Exposure limits be exceeded. To prevent the situation happening, people who work with the antenna should be aware of the following rules: 2. Install the antenna in a location where a distance of 20 cm from the antenna may be maintained.
