Summary of Contents for BOCUMA SQUIVEL SV VCF BMA 005
- Page 1 BMA_005 ESQUIVEL SV VCF User's manual Título Subtítulo...
- Page 2 introducción E S Q U I V E L - S T A T E V A R I A B L E V O L T A G E C O N T R O L L E D F I L T E R Congratulations on your acquisition of ESQUIVEL, our voltage controlled variable state filter and our humble tribute to the of space-age pop, Juan García Esquivel, who was probably one of the first Mexican musicians to...
- Page 3 SPECS Y LAYOUT. E S Q U I V E L - S T A T E V A R I A B L E V O L T A G E C O N T R O L L E D F I L T E R Medida y formato: 14 HP EURORACK Consumo de poder: +/- 12V 12mA Estado variable LP, BP y HP con funcionamiento individual mediante el...
- Page 4 1. Cutoff control 2. Resonance control or "Q". 3.CV Inputs 1 and 2. 4. Status selector and output connector. 5. Input mixer, IN 1, IN 2 and IN 3.
- Page 5 QUICK START. Once you have installed your ESQUIVEL module in your rack you will be able to use it as follows: Connect an audio signal to any of the inputs on your mixer (5) and turn the corresponding level knob clockwise. Select the desired filter mode on the status selector switch (4), the output signal after the filter will be on this connector.
- Page 6 to finish... Our inspiration to create is you and all the musicians and sound artists who challenge the status quo to explore new horizons and, to do so, make use of technology and innovation. Esquivel takes his name from the master of space age-pop, who at the time made use of his background in electronic engineering to take his compositions to other destinations.
