- Page 1 LSI® SAS 9311-8i PCI Express® to 12Gb/s Serial Attached SCSI (SAS) Host Bus Adapter User Guide Version 1.3 March 2015 DB15-000903-03...
- Page 2 San Jose, CA globalsupport.pdl@avagotech.com www.lsi.com Avago, Avago Technologies, the A logo, LSI, Storage by LSI, and Fusion-MPT are trademarks of Avago Technologies in the United States and other countries. All other brand and product names may be trademarks of their respective companies.
-
Page 3: Functional Descriptions
LSI SAS 9311-8i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide Overview March 2015 ® ® SAS 9311-8i PCI Express to 12Gb/s Serial Attached SCSI (SAS) Host Bus Adapter User Guide Overview ® ® ® The LSI PCI Express... -
Page 4: Operating System Support
LSI SAS 9311-8i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide Operating System Support March 2015 SAS-3 Interface The LSI SAS 3008 controller chip contains the SATA+SAS functionality for the LSI 12Gb/s SAS HBA. The following table shows the LSI SAS 12Gb/s SAS performance. -
Page 5: Physical Characteristics
CR1 – Heartbeat LED J1 – SFF-8643 mini-SAS HD, internal, right-angle connectors Electrical Characteristics The power requirements for the LSI SAS 9311-8i HBA under normal operation are as follows: PCIe 12.0 V = 1.59 A Power values: ... -
Page 6: Lsi 12Gb/S Sas Hba Certifications And Safety Characteristics
Unpack the HBA, and inspect it for damage. Unpack the HBA in a static-free environment. Remove the HBA from the antistatic bag, and carefully inspect the device for damage. If you notice any damage, contact Avago or your reseller support representative. -
Page 7: Technical Support
LSI SAS 9311-8i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide Technical Support March 2015 Figure 2 Install an LSI 12Gb/s x8 HBA in a PCIe Slot Secure the HBA bracket to the system’s chassis. Install the bracket screw, if applicable, or engage the system retention mechanism to secure the HBA to the system’s chassis. -
Page 8: Revision History
Revision History LSI SAS 9311-8i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide March 2015 Revision History Version 1.3, March 2015 The following document change was made: Changed Solaris operating system support. Version 1.2, September 2014 The following document changes were made: Updated support contact information.
