Summary of Contents for Turbo-x DA-4060
-
Page 1: Front Page
INSTALLATION AND OPERATION MANUAL DIGITAL CLASS-D 4 CHANNEL AMPLIFIER DA-4060 DA-4120 DA-4240 DA-4350 DA-4500 1 / 11... -
Page 2: Important Safety Information
Important Safety Information Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 3: Safety Warning
Safety Warning WARNING! TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. -
Page 4: Table Of Contents
Contents Front Page ------------------------------------------------------------------------------------------------------------------------------------------ 1 Important Safety Information ---------------------------------------------------------------------------------------------------------------- 2 Safety Warning ---------------------------------------------------------------------------------------------------------------------------------- 3 Contents ------------------------------------------------------------------------------------------------------------------------------------ 4 Introduction ------------------------------------------------------------------------------------------------------------------------------------- 5 Front Panel ------------------------------------------------------------------------------------------------------------------------------------- 6 Rear Panel ---------------------------------------------------------------------------------------------------------------------------------- 7 Speaker Connection --------------------------------------------------------------------------------------------------------------------------- 8 Block Diagram ----------------------------------------------------------------------------------------------------------------------------------- 9 Specification ----------------------------------------------------------------------------------------------------------------------------------- 10 Service and Warranty -------------------------------------------------------------------------------------------------------------------- 11 4 / 11... -
Page 5: Introduction
Introduction Features: Switching power technology digital power amplifier ⚫ Class-D PA power amplifier of minimum power consumption ⚫ Less rack space and less heat generation ⚫ Four channel power amplifier into 19” rack mount unit ⚫ Rated power output at 120W, 240W, 350W to 500W by four channels ⚫... -
Page 6: Front Panel
Front Panel PROT Protection indicator will light on in orange once the amplifier comes into protection status. The protection maybe resulted from speaker line short circuit, speaker line open circuit, amplifier overload and inner working temperature over 55℃, this indicator give visually guidance ask for repair and It will light off once these failures been repaired. -
Page 7: Rear Panel
Rear Panel AC POWER CORD AC power cord for input from 110V to 230V, the power cord itself is auto-switching. 100V SPEAKER OUTPUT The speaker outputs shall be connected to 100V line loudspeakers, the negative end to the speaker negative end and the positive end to the speaker positive end. -
Page 8: Speaker Connection
Speaker Connection Before connecting speakers, disconnect the AC power cable. Note the proper connecting terminals as shown below. Make sure that the total impedance is not less than the rated impedance indicated. - Connecting 8-16Ω Speaker Systems When connecting conventional 4-16Ω speaker systems, connect the speaker’s positive (+) side to the terminal labeled 4-16Ω. Connect the speaker’s negative (-) side to the terminal labeled COM. -
Page 9: Block Diagram
Block Diagram 9 / 11... -
Page 10: Specification
Specifications Model DA-4060 DA-4120 DA-4240 DA-4350 DA-4500 Description Class-D Four Channel Power Amplifier Rated Power Output 4x60W 4x120W 4x240W 4x350W 4x500W Speaker Output 8Ω & 100V Frequency Response L/H Cut OFF 20Hz-20KHz (+1/-2dB) L/H Cut ON 80Hz-20KHz (+1/-3dB) Input 0.775V, 0dBu, balanced phoenix connector by four channels Input Impedance 10KΩ... -
Page 11: Service And Warranty
OVLAŠTENI SERVIS ZA REPUBILKU HRVATSKU: TURBO-X d.o.o., Kolodvorska 147, 10410 Velika Gorica, CROATIA Tel: +385-1-6256-400 Fax: +385-1-6256-399 www.turbo-x.hr servis@turbo-x.hr Specifications may change without pre-notice.
