Summary of Contents for enertik BC-FCH-68AWG
- Page 1 Horizontal FAN COIL Installation & Instruction Manual IMPORTANT NOTE: Thank you very much for purchasing our product. Before using your unit, please read this manual carefully and keep it for future reference.
- Page 2 INDEX...
- Page 3 1. Overview of the unit ........................ 1 1. Equipment acceptance and installing location ................ 2 2. Inspection preparation ......................2 3. Fixing ............................2 4. Unit installation ........................2 5. Water system pressure test ....................3 6. Check before operation ......................4 7.
- Page 4 The air conditioner unit cannot be installed in flammable and explosive environments, as well as in laundry rooms and saunas. 1. Overview of the unit Parameters: Model BC-FCH-68AWG High Air volume(m3/h) Middle High 3600...
- Page 5 1. Equipment acceptance and installing location The products have been inspected and tested before leaving the factory, and are packed in corrugated boxes. The whole unit should be kept in good condition when it arrives at the construction site by proper transportation. If there is obvious damage to the carton, please check the condition of the unit itself;...
- Page 6 (1) Waterway system The water supply and return of all units are supplied from the bottom to the top, and all water pipes must be installed in strict accordance with the engineering drawings. It is recommended to use flexible pipes for the water pipes connected to the unit, and the main water pipes must be equipped with supporting devices at intervals to bear the weight of the water in the pipes and the water pipes themselves.
- Page 7 Notice: The pressure test and commissioning of the system should be carried out under frost-free climate conditions (the minimum temperature is not lower than 0°C). Otherwise, the water in the coil (system) must be drained after the pressure test and commissioning, and the corresponding Antifreeze measures, otherwise the coil will be frozen and cracked.
- Page 8 must also be disinfected and sterilized regularly, at least twice a year, to prevent the growth of colds and other germs. (3) Dirty blockage of the surface cooler will seriously affect the cooling capacity. Use an elastic nylon brush to clean the dirt between the fins (please do not damage the fins), and then use a vacuum cleaner to suck off the dust on the surface cooler.
