Summary of Contents for California Air Tools CAT-33000
- Page 1 CAT-33000 GRAVITY FEED LVLP SPRAY GUN OWNER'S MANUAL WWW.CALIFORNIAAIRTOOLS.COM Customer Support 1-866-409-4581...
- Page 2 22psi Working air pressure (at the air cap): 9.6 psi Air consumption: 4.3 cfm Air connection: 1/4" NPS CALIFORNIA AIR TOOLS CUSTOMER SERVICE: Phone: 1-866-409-4581 Ext. 1 Online: WWW.CALIFORNIAAIRTOOLS.COM Do not return your item for service or parts to the...
-
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS... - Page 4 ASSEMBLY Hose connection is 1/4”; a hose of the same size will need to be attached to the Air Inlet Joint. Attached Cup by gently screwing on clockwise hand tight. Initially perform the following actions: a. Use the spanner wrench to tighten the fluid nozzle.
- Page 5 ADJUSTMENT...
-
Page 6: Operation
OPERATION TIP#1: Always keep gun at right angles of work; always move gun first, then trigger. TIP #2 Accurately adjusting your spray gun inlet pressure using a pressure regulator at the spray gun 1)"open" the air adjustment valve on the gun. 2) With your gun trigger depressed half way (air only) adjust your air inlet pressure regulator to the desired inlet pressure to obtain the desired air cap pressure based on the table to the right. -
Page 7: Troubleshooting
MAINTENANCE c) Lightly lube all moving parts with a non-petroleum based lubricant. Note: never use improper cleaning instruments as they may damage the part and adversely affect gun performance. Never immerse the gun in solvent. TROUBLESHOOTING Problem: Gun is leaking from fluid nozzle. Causes: Fluid nozzle is loose, foreign particles or dried paint is keeping needle from seating properly. -
Page 8: Parts List
PARTS LIST NOTE: Only Needle Kits are available for purchase. All other parts shown are for reference/maintenance only! - Page 9 This warranty does not transfer to subsequent owners. California Air Tools Inc. will repair or replace, at its option, any parts that are proven by an authorized service center to be defective in material or workmanship under normal use during the applicable warranty time period as stated below. This limited warranty covers the cost of the replacement parts and labor for all defects when installed by an authorized service center.
