- Page 1 X5003 DASH CAM A340D User's Manual Copyright © 2023 MASI AUTO CO., LTD. www.masigo.net...
- Page 2 Safety Precautions and Notice To ensure that the product is used correctly and safely, please read the instruction manual carefully before use. The precautions described in this manual are intended to ensure the safe and proper use of the product and to prevent injuries to yourself and others, or damage to property.
-
Page 3: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Product Overview
Product Overview Speaker: Audio output LED indicator: Steady red light: Power on Flash red light: Recording Steady blue light: The camera is connected to a power source Blue light off: Not connected to a power source Function buttons: There are 4 function buttons to operate the camera in different ways. 《At Recording Screen》... - Page 5 Open menu, and go through the video menu, system menu,and playback menu. Switch PIP display Turn off/on the microphone. Hold and press to enable Wi-Fi. File protected button. 《At Menu Screen》 → Video Menu → Resolution Video Length → Exposure →...
-
Page 6: System Icon
Power button: Hold to turn the camera on/off; Press once to turn off/on the screen, and the camera is on standby mode. X5003 features on a super capacitor, and must be connected to a power source for operation. Mini-USB power port: Plug the power cable into the USB port. -
Page 7: Getting Started
SD card. Don't forget backing up your memory card before reformat it. MASIGO does not guarantee the compatibility with memory card from all manufacture. - Page 8 Installation in your vehicle 【Installing the front camera】 【Installing the front and rear cameras】 Car Charger Rear camera cable Car Charger 1. Clean your windshield: Cleaning the inside and outside of the windshield with window cleaner before applying the adhesive. 2.
-
Page 9: Basic Operation
Basic Operation Turn on/off the camera ．Automatically The camera will automatically power on and start recording once received power. ．Manually Press and hold the power button ” ” for 3 seconds to turn on/off the camera. Select language, time zone, date time, daynight saving time and speed unit Go through the settings below for the first-time setup to select language, Time Zone, date time and Speed unit. -
Page 10: Playback Mode
Incident Recording: During continuous recording, if the camera detects a possible accidental collision, a 1 minute/3 minutes video footage (depending on the loop recording length selected) will be locked to prevent overwriting and saved in the "Event video" folder automatically. You can adjust the G- sensor level in the Video Menu Settings, with the default setting being low. - Page 11 1. Press and hold the camera Wi-Fi bu on ” ” to enable a Wi-Fi hotspot. 2. On your smartphone, select the Wi-Fi network name same as displayed on the camera MASIGO XXXXX-XXXX, and enter the Wi-Fi password “12345678”. 3. Run MASIGO Viewer 4.
-
Page 12: Camera Setting
Camera Setting Press Menu button ” ” once to access the Video setting, use the Up and Down button ” ” to scroll down the function, and press the ” ” button to enter the options screen. Description (*Factory default setting) Video Menu Front：4K 30fps / 2K 60fps / 1080P 120fps Resolution Front+Rear：4K 30fps + 1080P 30fps / 1080P 60fps + 1080P 60fps... - Page 13 This setting helps reduce light flicker. It may change if you are in a different regions. Default Settings Start up automatically with the factory default settings System Version Check the Firmware version. Note:You can also configure the camera settings via MASIGO Viewer APP on your smartphone.
-
Page 14: Warranty Terms
．Using the VLC media player to play videos on your computer. Warranty Terms Thank you for purchasing MASIGO dash cam. Should your product require warranty service, please contact us directly to determine the problem and the most appropriate solution for you. See details below MASI AUTO CO., LTD...
