  • Page 1 A 12 X E LEVATING YOUR S OUND US ER M AN UA L...
  • Page 2 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Avante Audio is under license. Other trademarks and trade names are those of their respective owners.

  • Page 3: Table Of Contents

    C O N T E N T S General Information Limited Warranty (USA Only) Safety Guidelines Overview Connections & Controls Installation DSP Operation Application Control Application Diagrams Frequency Charts Specifications Dimensional Drawings Components & Accessories | FCC Statement...

  • Page 4: General Information

    Please do not discard the shipping carton in the trash. Please recycle whenever possible. CUSTOMER SUPPORT AVANTE provides a customer support line to provide set up help, assist with any questions or problems that may arise during set up or initial installation, and for any service related issues. You may also visit us on the web at www.avanteaudio.com...

  • Page 5: Limited Warranty (Usa Only)

    L I M I T E D WA R R A N T Y ( U S A O N LY ) 1. ADJ Products, LLC hereby warrants, to the original purchaser, AVANTE products to be free of manufacturing defects in material and workmanship for a prescribed period of up to 3-years (1,095 days) from the original purchase date.

  • Page 6: Safety Guidelines

    This speaker is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. AVANTE is not responsible for injury and/or damages resulting from the misuse of this speaker due to the disregard of the information printed in this manual.
  • Page 7 S A F E T Y G U I D E L I N E S • POWER SOURCES: This product must be connected to a power supply only of the type described in these operating instructions, or as marked on the unit. This product is Country Specific. •...

  • Page 8: Overview

    O V E R V I E W Threaded Insert for M10 Eye Bolts Carrying Handle (Fly Points) ABS Enclosure Rotating Logo Menu Panel Control Module Power LED Indicator Threaded Insert for M10 Eye Bolts (Fly Points) Adjustable Tilt Pole Socket Footing Ridges Anti-Slip Rubber Feet Pole Socket...

  • Page 9: Connections & Controls

    C O N T R O L S A N D C O N N E C T I O N S LCD Display - DSP Parameters and Status DSP Edit Encoder / Button CH1 Mini Jack (3.5mm) Line Input CH1 Level CH1 RCA Line Input Bluetooth Indicator LED...

  • Page 10: Installation

    I N S TA L L AT I O N STANDARD SPEAKER STAND The A12X speakers can be pole mounted on a standard speaker stand (not included), or pole mounted on top of the A18S sub woofers using the included sub speaker poles. Additionally, the A12X speakers can be permanently installed using optional M10 Eye Bolts or optional Wall Mounts.
  • Page 11 I N S TA L L AT I O N Floor Monitor 45° A12X speaker has an integrated 45° angle back panel for use as floor monitor. Note that only one angled back panel has footing ridges to stabilize the speaker...
  • Page 12 I N S TA L L AT I O N Wall Mount Bracket (sold seperately) For permanent wall installations, attach the optional Wall Mount Bracket to a flat wall surface using appropriate hardware (not included). CONSULT A PROFESSIONAL INSTALLER BEFORE ATTEMPTING TO INSTALL WALL MOUNT BRACKETS! Place speaker onto the wall mount bracket by inserting speaker pole into the bottom mounting hole.
  • Page 13 I N S TA L L AT I O N Subwoofer Pole-Mounted Speakers 25.8” (655mm)
  • Page 14 I N S TA L L AT I O N Speakers can be tilted forward 7.5° to adjust for venue dependent acoustics. Rotating Avante Icon Speakers can be tilted forward 7.5° to adjust for venue dependent acoustics.

  • Page 15: Dsp Operation

    D S P O P E R AT I O N 1. Press encoder knob to access setting menus. 4. Rotate encoder knob to adjust setting to desired 2. Rotate encoder knob to scroll through setting selection. menus. 5. Push encoder knob to Save and Return. 3.
  • Page 16 D S P O P E R AT I O N Level 1 Level 2 Level 3 No Delay --> Delay 1M/3ft Delay --> 10M/33ft Delay...
  • Page 17 D S P O P E R AT I O N Level 1 Level 2 Level 3 Mix Out --> Output Link Out App Control App Control --> Control App Control On, TWS Off Used as a Secondary Speaker Streaming Off -->...
  • Page 18 D S P O P E R AT I O N Level 1 Level 2 Level 3 TWS Stereo On, Used As Left Channel TWS Stereo On, Used As Right Channel TWS Mono On --> Function Used As Secondary Speaker TWS Unlink TWS TWS Off...
  • Page 19 D S P O P E R AT I O N Level 1 Level 2 Level 3 Standby Off --> Standby Function Standby 2 Mins --> 30 Mins Auto Link Off --> Auto Link Auto Link On: TWS Starts After Power Front LED On -->...

  • Page 20: Application Control

    A P P L I C AT I O N C O N T R O L Entry Page Main page: adjust the volume of each Channel, or mute.
  • Page 21 A P P L I C AT I O N C O N T R O L Click EDIT above Channel 1. Channel 1 Page: adjust the volume and EQ of Channel 1. Note that the Master Volume can also can adjusted here.
  • Page 22 A P P L I C AT I O N C O N T R O L Click EDIT above Channel 2. Channel 2 Page: adjust the volume and EQ of Channel 2. Note that the Master Volume can also be adjusted here.
  • Page 23 A P P L I C AT I O N C O N T R O L Click EDIT above Master Channel Master Channel Page: adjust the volume, mode, Location, delay, and output mode of 2 channels.
  • Page 24 A P P L I C AT I O N C O N T R O L Click SCENES, located overhead right. Click Save to save a new setting about the volume, EQ, and mode.
  • Page 25 A P P L I C AT I O N C O N T R O L Name your new setting, then click OK to save, or Cancel to cancel. Click Load to use the chosen saved setting, or click Delete to delete the chosen setting.
  • Page 26 A P P L I C AT I O N C O N T R O L Bluetooth page: use True Wireless Stereo (TWS) function.
  • Page 27 A P P L I C AT I O N C O N T R O L Click Linked Speakers and wait for a moment. Adjust the volume of Channel 1 for two speakers, Channel 2 for each speaker, master Channel for two speakers.
  • Page 28 A P P L I C AT I O N C O N T R O L Stereo mode: Click Stereo Click Switch L/R to flip left and right channels.
  • Page 29 A P P L I C AT I O N C O N T R O L Mono mode: Click Mono. Click any blank part. Adjust the volume of each channel.
  • Page 30 A P P L I C AT I O N C O N T R O L Unlink: Click Unlink. Returns user to the Bluetooth link page.
  • Page 31 A P P L I C AT I O N C O N T R O L Click SETUP located overhead right. Config page: choose Standby time, Auto link, and Front LED.
  • Page 32 A P P L I C AT I O N C O N T R O L About page: lists current version and MANUAL.

  • Page 33: Application Diagrams

    A P P L I C AT I O N D I A G R A M S Multiple Input Options Two Daisy-Chained Loudspeakers...
  • Page 34 A P P L I C AT I O N D I A G R A M S Typical Stereo System...

  • Page 35: Frequency Charts

    F R E Q U E N C Y C H A R T S A12X - SPL VS. FREQ CHARTS SPL vs Freq dBSP L 20 H z 2: A12X - Normal+Pole 4: A12X - Club+Pole 3: A12X - Live+Pole...

  • Page 36: Specifications

    S P E C I F I C AT I O N S • Amp Power: 1200W Peak; 350W Class D (LF) + 50W Class AB (HF) RMS • Built-in Digital Signal Processing (DSP) with LCD screen, EQ & multiple presets. IOS APP for remote control of settings.

  • Page 37: Dimensional Drawings

    D I M E N S I O N A L D R A W I N G S 14.4 in (365mm) 14.0 in (355mm)

  • Page 38: Components & Accessories | Fcc Statement

    Z-M10-58-3 M10 EYE BOLTS - 3-Pack WMB001 AVANTE Wall Mount Bracket (2) F C C S TAT E M E N T This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
