Summary of Contents for Subaru Outback 2019
- Page 1 Quick Guide Quick Guide Outback 2019 2019 Love. It’s what makes a Subaru, a Subaru.
- Page 2 Guide is optional at extra cost. Specific options may be available only in combination with other options. Specific combinations of equipment or features may vary from time to time, and by geographic area. Subaru of America, Inc. reserves the right to change or discontinue at any time, without notice: Prices,...
-
Page 3: Table Of Contents
Table of Contents Getting Started 2–5 6–7 Instrument Panel Gauges 8–11 12–13 Personalize Controls 14–21 While Operating 22–23 24–25 Safety/In Case of Emergency Additional Information 26–28... - Page 4 Remote Keyless Entry Unlocking the Rear Gate Lock/Arm • Press the button to unlock the • Press to lock all doors and the rear rear gate. gate and activate the security alarm. • If any of the doors or the rear gate Panic Alarm are not fully closed, fi ve rapid chirps will sound and the hazard lights will...
- Page 5 Seating Power Driver’s Seat (if equipped) Do not adjust the seat while moving Seatback Move the switch in the Forward/Backward, corresponding direction to adjust Angle and Height the angle of the seatback. Move the switch toward the front or rear to move the seat forward Lumbar Support or backward.
- Page 6 Seating Seat Controls Do not adjust the seat while moving. Forward/Backward Pull up on the lever below the front of the driver’s seat to move the seat forward or backward. Raise/Lower Seat Cushion To adjust the height of the driver’s seat, pull up or push down the seat height adjustment lever, located on the lower left front of the seat.
- Page 7 Rear Seat Heater (if equipped) Press the rear seat heater switch. Each time you press the switch, the mode will change as follows: High, Low, Off. Folding the Rear Seat From Inside the Vehicle Push the release button on the top of the seatback that you want to fold down.
-
Page 8: Instrument Panel
Instrument Panel PAGE 14, 19 8-11 NUMBER... - Page 9 16-17...
-
Page 10: Gauges
Gauges Tachometer ECO gauge Outback 2.5 L Immediate Attention Caution Informational Trip meter reset button Temperature gauge Trip meter and odometer Seatbelt warning High beam indicator light Front passenger AT OIL TEMP seatbelt warning (Automatic Transmission) (Located on overhead console) SRS airbag system ABS warning Security indicator light... - Page 11 Speedometer Fuel gauge Vehicle Dynamics Control/ Vehicle Dynamics Control Hill holder operation Vehicle Dynamics Control OFF Turn signals CHECK ENGINE/ Front fog light indicator Malfunction indicator light (if equipped) Tire pressure warning light Headlight indicator light Front passenger airbag ON (Located on overhead console) Front passenger airbag OFF (Located on overhead console)
- Page 12 Gauges Tachometer ECO gauge Outback 2.5 L Premium Outback 2.5 L Limited Outback 2.5 L Touring Outback 3.6 L Limited Outback 3.6 L Touring Immediate Attention Caution Informational Trip meter reset button Temperature gauge Trip meter and odometer Trip meter and odometer Seatbelt warning High beam indicator light Front passenger...
- Page 13 Speedometer Fuel gauge Vehicle Dynamics Control/ Lane Departure Warning Vehicle Dynamics Control OFF light operation Hill holder Vehicle Dynamics Control OFF CHECK ENGINE/ Turn signals Malfunction indicator Front fog light indicator Tire pressure warning light light (if equipped) Front passenger airbag ON Headlight indicator light (Located on overhead console) Front passenger airbag OFF...
-
Page 14: Personalize
Personalize Tilt and Telescopic Steering Column Pull the lever down fi rmly to adjust the height and lengthwise position of the column; fi rmly push the lever back up to lock the column in place. Do not adjust while driving. Heated Steering Wheel (if equipped) To activate, pull the Heated Steering Wheel switch while the ignition is in the ON position. - Page 15 Power Exterior Mirrors Turn the knob to the “L” side to adjust the left-hand mirror or to the “R” side to adjust the right-hand mirror. Move the knob in the direction you want to move the mirror. Then return the knob to the neutral/center position. i/SET Combination Meter Display Controls (if equipped) Use the i/SET controls to display and switch selected items in the Combination...
-
Page 16: Controls
Controls Light Controls Push forward to change from low Turns on headlights, instrument beam to high beam. Pull the lever panel illumination, parking lights, back to center to return to low beam. tail lights and license plate lights. Push slightly up for lane change or fully up for right turn signal. - Page 17 INT. HIGH Windshield Wipers To turn on the wipers, press the wiper control lever down one level for intermittent, two levels for low, or three levels for high speed. Return the lever to the “OFF” position to stop the wipers. For a single wipe, move the lever up. To spray washer fl uid, pull and hold the lever toward you.
- Page 18 Controls Manual Climate Control (if equipped) Fan Speed Control Dial Temperature Control Dial Rotate the fan speed control dial to select Rotate the temperature control dial from one of four fan speeds. blue for cool, to red for warm. Rotate the dial all the way left for MAX A/C.
- Page 19 Dual Zone Automatic Climate Control System (if equipped) Automatic On and Off Air Flow Mode Selection Button This system automatically controls Press the button to select the outlet air temperature, fan speed, desired air fl ow mode. The selected air fl ow distribution, air inlet control, air fl ow mode –...
- Page 20 Please see your Owner’s Manual for programming instructions or visit www.subaru.com/homelink to view a how-to video.
- Page 21 Instrument Panel Switches (lower left) Please refer to your Owner’s Manual for details on these switches. Power rear gate switch (if equipped) Vehicle Dynamics Control OFF switch Blind Spot Detection/Rear Cross Traffi c Alert OFF switch (if equipped) Lane Departure Warning OFF switch (if equipped) Power rear gate memory switch (if equipped)
- Page 22 Controls Steering Wheel Audio Controls (if equipped) With any of the radio modes selected, press the left or right arrow button to toggle through your presets. In CD mode, press the buttons to skip forward or back a track. Push the switch up (+) to increase volume or down (–) to decrease volume.
- Page 23 Cruise Control To activate the cruise control, press the “ ” button. The indicator light on the To resume your speed after instrument panel will turn on. canceling, push the switch To deactivate cruise control, to the “RES” side. press the “ ”...
-
Page 24: While Operating
While Operating Electronic Parking Brake To apply, depress the brake pedal and pull up the parking brake switch. The brake system warning light on the instrument panel and the indicator light on the parking brake switch will illuminate. To release, make sure all doors are closed and your seatbelt is fastened, then gently push the accelerator pedal. - Page 25 Automatic Transmission Shift Mode The Continuously Variable Transmission (CVT) gives you ultimate control with two different driving modes: Normal Mode and Manual Mode. Normal Mode When the selector lever is in the “D” (Drive) position, the transmission is in Normal shift mode.
-
Page 26: Safety/In Case Of Emergency
Safety/In Case of Emergency Child Restraint System Your vehicle is equipped with Lower Anchors and Tethers for CHildren (LATCH). For maximum safety, fi rst carefully read the LATCH system instructions from the device manufacturer, as well as the installation instructions in your Owner’s Manual, to properly install the LATCH compatible restraint system. - Page 27 AWD system. A flatbed truck is the only recommended way to properly transport your AWD vehicle. If towing is necessary, it is best done by your Subaru Retailer or a commercial towing service. Subaru Roadside Assistance Subaru Roadside Assistance is free and standard on your vehicle.
-
Page 28: Additional Information
Additional Information Fuel For both the 2.5 liter 4-cyl. engine and the 3.6 liter 6-cyl. engine, use regular unleaded gasoline with an octane rating of 87 AKI or higher. Consult the Owner’s Manual for more detailed information. Fuel Capacity • 18.5 US gal (70 liters, 15.4 Imp gal) •... - Page 29 Engine Oil Use only the following oils: • API classification SN with the words “RESOURCE CONSERVING.” • Or ILSAC GF-5, which can be identified with the ILSAC certification mark (Starburst mark). - 2.5 L models use 0W-20 synthetic, replacement interval 6,000 miles under normal driving conditions.
- Page 30 Engine Compartment Please refer to your Owner’s Manual for more information. 2.5 L Engine Note: Callouts apply to both engines. Brake Fluid Reservoir Engine Coolant Reservoir Main Fuse Box Radiator Cap Windshield Washer Tank Engine Oil Dipstick Battery Air Cleaner Element Engine Oil Filler Cap 3.6 L Engine...
- Page 31 One Subaru Drive Camden, NJ 08103-9800 MSA5B1904A Issued June 2018 Printed in USA 06/18...
