Summary of Contents for chromagen DET600S
- Page 1 K K K K K K K C OOKER HOOD INSTRUCT ON MANUAL Read this manual carefully before operation Pictures in this manual are for reference only, the product in kind prevail. DET600S DET900S...
- Page 2 2 2 2...
-
Page 3: Table Of Contents
Contents Contents Contents..............Warnings..............Safety Warning............Notice of Installation..........Use..............8 Maintenance............Trouble Shooting..........Main Parameters..........Disposal.............. -
Page 4: Warnings
Contents Warnings This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 5: Safety Warning
Safety Warning The appliance is not intended for use by young children or infirm persons without supervisions. Young children should be supervised to ensure they do not play with the appliance. Plug the power cord to socket outlet with earthing continuity terminal. ... -
Page 6: Notice Of Installation
Notice of Installation It can not share the same air ventilation tube with other appliance such as gas tube, warmer tube, and hot wind tube. There will be hazard of underpressure, combustion impaired and harmful gases drawn back. The bending of ventilation tube should be ≥120°,parallel or above the start point/should be connected to the external wall. - Page 7 Fig.2 1 x Installation plate 7 x Plastic expansion pipes 2 x Chimney installation plates 7 x Screws(ST5*50) 6 x Screws(ST4.2*9.5) Fig.3...
- Page 8 Installation Accessories. See Fig.3. (Type and quantity of accessories is subject to actual demand.) Fix installation plate and extension chim ney installation plate, install the plastic expansion pipes of chimney installation plate on wall. See Fig.4. Fix the exhaust pipe and chimney on the main body, connect chimney installation plate and chimney.
- Page 9 Fig.6 Fig.7 Fig.8 7 X Screws(M5*50)
-
Page 10: Use
Speed adjustment. See Fig.9 Press Stop button, the motor will stop running. Press the Low (speed) button, the motor runs at low speed. Press the Mid (speed) button, the motor runs at mid speed. Press the High (speed) button, the motor runs at high speed. ... -
Page 11: Maintenance
Contents Maintenance Cleaning of the filters Removing the filters according to Fig.10. Put into a dishwasher with detergent, set the temperature below 60 degrees. Please do not use abrasive detergent for it will damage the hood. Make sure that the hood is shut off before cleaning. Fig.10 Fig.11 Replacement of the carbon filters (... -
Page 12: Trouble Shooting
Trouble Shooting Fault Cause Solution The blades are blocked. The capacitor is damaged. Replace capacitor. Light on, but motor The motor is damaged. Replace motor. does not work. The internal wiring of motor is cut off / disconnected. An unpleaseant smell Replace motor. -
Page 13: Main Parameters
Main Parameters 220-240V~50/60Hz Rated Power 333W Lighting Power 2 X 1.5W Motor Power 330W 150mm Diameter of air tube 800m /h ≤ 74dB The air flow parameter is tested under conditions of 230V 50Hz when the voltage is 220-240V ~ 50/60Hz and without carbon filters. Disposal Please dispose of it at your local community waste collection / recycling center and ensure it presents no danger to children... - Page 14 2 2 2...
- Page 15 2 2 2...
- Page 16 The manufacturer shall decline all responsibility if the foregoing recommendations and instruction regarding installation, maintenance and use are not observed and respected when using the cooker hood. 17 – 23 Redwood Drive, Dingley Village, VIC, Australia 3172 CHROMAGEN AUSTRALIA PTY LTD...
