- Page 1 Instruction Manual Automotive Equipment TYRE CHANGER TECO 28 Special Version 2.1 - December 2015...
- Page 2 (incluidos microfilmes y fotocopias). Las informaciones que se incluyen en este manual están sujetas a variaciones sin aviso previo. Elaborazione grafica e impaginazione fficio ubblicazioni ecniche User’s manual - TECO 28 special...
-
Page 3: Table Of Contents
MAINTENANCE .................... 21 ENVIRONMENTAL INFORMATION .............. 24 INFORMATION AND WARNINGS ABOUT OIL ..........25 RECOMMENDED FIRE-EXTINGUISHING DEVICES ........26 GLOSSARY ....................27 TROUBLE SHOOTING ................. 27 ELECTRICAL SYSTEM DIAGRAM ............... 28 PNEUMATIC SYSTEM DIAGRAM ..............31 User’s manual - TECO 28 special... -
Page 4: Introduction
The purpose of this manual is to furnish the owner and operator with a set of practical, safe instruc- tions on the use and maintenance of the TECO tyre changer. Follow all the instructions carefully and the machine will give you the efficient and long-lasting service that has always characterized TECO products, making your work considerably easier. -
Page 5: Transport, Storage And Handling
Failure to follow these recommendations may result in damage to the machine and put the operator’s safety at risk. Before moving the machine, refer to the HOISTING/HANDLING section. User’s manual - TECO 28 special... -
Page 6: Unpacking/Assembly
The installation site must be chosen in strict compliance with the relevant regulations regarding Safety in the workplace. IMPORTANT: for correct, safe use of the equipment, users must ensure a lighting level of at least 300 lux in the place of use. ® ® User’s manual - TECO 28 special... -
Page 7: Electrical And Pneumatic Connections
All operations required for the electrical connections of the equipment must be carried out exclusively by a qualified electrician. Before connecting the air supply system, make sure the machine is set up as in fig. 4: pedal totally downwards. ® User’s manual - TECO 28 special... - Page 8 The customer must provide an air cut-off valve upstream of the air treatment and regulating device supplied with the machine. WARNING Connection 1 should be considered as an emergency valve to disconnect the machine from the air line (fi g.6) User’s manual - TECO 28 special...
-
Page 9: Safety Regulations
- User must wear personal protective equipment such as gloves, safety footwear and goggles. WARNING When operating or servicing the equipment, tie back long hair and do not wear loose-fitting clothes, ties, necklaces, rings or wristwatches which could become entrapped by moving parts. User’s manual - TECO 28 special... -
Page 10: Description
- Operating pressure in bar; Serial No. - Machine serial number; EC - EC marking. Mod. Automotive Equipment TECO s.r.l. Via Pio La Torre 10 Ser. N. 42015 Correggio (R.E.) - ITALY tel. 0522/631562 - fax 0522/642373 Volt Year Weight Amp. -
Page 11: Technical Data
The permitted exposure levels may also vary according to the country. However, this information will enable machine users to make a more accurate assessment of hazard and risks. User’s manual - TECO 28 special... -
Page 12: Standard Accessories
8-11600005..........................PLS 2 (Pneumatic wheel lift complete with roller rest) SPECIFIED CONDITIONS OF USE The TECO tyre changers has been designed exclusively for mounting and demounting tyres, using the tools the machines are equipped with, following the instructions in this manual. WARNING Any other operation carried out on the machine is considered as improper use and shall be construed as negligence. -
Page 13: Main Operating Parts
14 Bead breaker 15 Grease container holder 16 Mounting head 17 Tyre lever 18 Air lubricator 19 Inflator pedal for t.i. version 20 Inflating unit 21 Air tank 22 Body 23 Tyre deflating push button User’s manual - TECO 28 special... - Page 14 User’s manual - TECO 28 special...
-
Page 15: Warning Signals
BODY BETWEEN THE BEAD BREAKER AND THE 000102800 WHEEL. 000103200 INFLATING GUN CONNECTION. DO NOT DIRECTLY CONNECT THE COMPRESSOR. (only on standard version) DANGER OF CRUSHING PARTS OF THE BODY BETWEEN THE BEAD BREAKER ARM AND THE MACHINE. 000102700 000103300 User’s manual - TECO 28 special... - Page 16 B. On these wheels the bead must first be broken in correspondence with the valve hole, on both the top and bottom sides of the wheel. Wheels with low pressure indicator system - fig.10-D. User’s manual - TECO 28 special...
-
Page 17: Use
(fig. 13). Acting on the turntable pedal (3 fig.9) closes the clamps and may be dangerous (danger of hand crushing). During rim clamping, do not keep the hands under the tyre. User’s manual - TECO 28 special... - Page 18 - If the wheel has an inner tube, remove it after swinging the horizontal arm + mounting bar in non-work position. - Repeat the above described procedures to take out the second bead. Then move the horizontal arm + mounting bar in non-work position and take the tyre off the rim. User’s manual - TECO 28 special...
- Page 19 - Place the tyre on the rim • Head positioning - Set the mounting bar in work position NB: The tool is already in the correct position for mounting the tyre, unless the type of rim has been changed. User’s manual - TECO 28 special...
-
Page 20: Inflation
- Lock the horizontal and vertical arms in the positions described on Fig.2.4. - Connect the Doyfe inflation chuck (32) on the air hose to the valve stem. - Inflate the tyre by using the inflaction gun User’s manual - TECO 28 special... - Page 21 For a correct functioning of the device, take care there are no plays between head and hexagonal bar. User’s manual - TECO 28 special...
-
Page 22: Maintenance
It only enables users to provide the technical assistance service with precise information in order to minimize delays. WARNING TECO declines all liability for claims deriving from the use of non-original spare parts or accessories. CAUTION Any operation intended to modify the setting value of the relief valves or pressure limiter is forbidden. - Page 23 • Clean with a dry cloth. Avoid contact with solvents. • Check the oil flow-rate through the transparent cover K (correct flow-rate: 1 drop of oil every 4 bead breaking cycles). Adjust if necessary by turning the set screw Y fig. 23. User’s manual - TECO 28 special...
-
Page 24: Environmental Information
Contain the spilt product from spreading using soil, sand or any other absorbent material. Degrease the contaminated area with solvents, taking care to disperse solvent fumes. The residual cleaning material must be disposed of as prescribed by law. User’s manual - TECO 28 special... -
Page 25: Glossary
Tubeless Inflator: An inflation system which simplifies inflating tubeless tyres. Bead: The edge of the tyre that remains in contact with the rim when the tyre is installed. Tubeless: A tyre without an inner tube.. User’s manual - TECO 28 special... -
Page 26: Trouble Shooting
Air gaskets worn. - Replace gaskets. - Replace bead breaker cylinder. Table top will not rotate in either direction Inverter faulty. - Replace inverter. Belt broken. - Renew belt. Gear unit broken. - Renew gear unit. User’s manual - TECO 28 special... - Page 27 The “Spare parts” handbook does not authorize users to carry out work on the machine with the exception of those operations expressly described in the user manual. It only enables users to provide the technical assistance service with precise information in order to minimize delays. User’s manual - TECO 28 special...
- Page 28 CONTATTI - Contacts ELEMENTI - Elements User’s manual - TECO 28 special...
- Page 29 CONTATTI - Contacts ELEMENTI - Elements User’s manual - TECO 28 special...
- Page 30 CONTATTI - Contacts ELEMENTI - Elements User’s manual - TECO 28 special...
- Page 31 VALVOLA AUTOCENTRANTE SELF-CENTERING CHUCK VALVE RACCORDO GIREVOLE ROTATING UNION CILINDRO AUTOCENTRANTE SELF-CENTERING CHUCK CYLINDER VALVOLA DI GONFIAGGIO INFLATING VALVE VALVOLA A MEMBRANA VALVE VALVOLA DI SICUREZZA SAFETY VALVE UNITA’ DI GONFIAGGIO INFLATE UNION BOX User’s manual - TECO 28 special...
- Page 32 EC DECLARATION OF CONFORMITY IN ACCORDANCE WITH DIRECTIVE 2006/42/EC Teco Srl Via Pio La Torre 10 42015 Correggio (RE) Italy, DECLARE UNDER OUR SOLE AND EXCLUSIVE RESPONSIBILITY THAT THE MACHINE: TYPE: Tyre chAnger MODEL: serial number SERIAL No.: TO WHICH THIS STATEMENT REFERS AND FOR WHICH WE HAVE PREPARED AND HOLD THE RELATIVE...
- Page 36 Automotive Equipment Teco Srl - Via Pio La Torre, n°10 42015 Correggio (RE) Italy www.teco.it - www.tecorus.ru www.youtube.com/user/TECOsrl Telephone: +39.0522.631562 Fax: +39.0522.642373 E-mail: teco@teco.it...
