Page 1 STREETEC autoleveling Air Suspension Control System English AN 1010 - EN - R1.0...
Page 2 STREETEC Autoleveling Air Suspension Control System English Installation Guide Version AN 1010 - EN - R1.0...
Page 3 Prologue Dear Customer, congratulations on the purchase of your STREETEC autoleveling. Read the following instructions carefully and follow them to prevent possible damage. We assume no liability for damage caused by disregarding the instructions and improper use. Scan the QR code to access the latest operating instructions...
Page 4: Table Of Contents
Safety instructions General information Basics Touchscreen valve 4 Water separator Pressure sensors Height sensors Installation Cable set Connection diagram Installation airlines Air line / fitting assembly Disassembling air line / fitting Autoleveling APP Quick Start Guide Settings Troubleshooting Component list Warranty Declaration of Conformity Notes on disposal Manufacturer information...
Page 5: Safety Instructions
• Work on electronic and pneumatic components of the vehicle as well as work on the STREETEC autoleveling must be carried out by trained specialist personnel. • Keep the housing and all components of the STREETEC autoleveling as dry and free of dirt as possible.
Page 6: Ecu
The ECU (Fig. 1) of the STREETEC autoleveling consists of a high-quality aluminum housing with a high-gloss acrylic glass cover. We recommend handling the ECU carefully during installation so as not The ECU must be fi rmly screwed into the vehicle. Otherwise, calibration may not be to impair its optical properties. carried out accurately and control problems may occur! 1.
Page 7 Technical data - ECU Dimensions - ECU Product details 124,5 mm 124,5 mm Product STREETEC autoleveling - ECU Item number 2013 0 0004 Dimensions (L x W x H) 124,5 mm x 107,5 mm x 60,5 mm Weight 363 g...
Page 8: Touchscreen
USB-C plug. In this case, the connection direction is irrelevant. The touch screen of the STREETEC autoleveling has numerous technical innovations that give the system a very special value! • The capacitive touchscreen works according to the same principle as a smartphone. Commands are only made via touch without pressure.
Page 9: Valve
In case of incorrect mounting, the proper pressures up to 14 bar and millions of switching function of the STREETEC autoleveling cannot be guaranteed. cycles. Everything is integrated in one compact unit. With an overall size of approx. 125 x 55 x 80 mm, the valve block is ideal for all air suspensions.
Page 10 Technical data - valve4 Dimensions - valve4 Product details Product STREETEC autoleveling - valve4 Items number 9909 2 0204 Dimensions (L x B x H) 52 mm x 123 mm x 75 mm Weight 1150 g Electrical details Rated voltage 123 mm Max.
Page 11: Water Separator
The air generation kit compressors absorb moisture from the outside air. This moisture thus enters 2. The water separator used in this system is a manually the air tank, where it settles. The STREETEC autoleveling system is supplied with a water separator vented water separator and must be emptied regularly.
Page 12 Technical data - Water separator Dimensions - water separator Product details 41 mm Product STREETEC autoleveling - Water separator Item number 9909 2 0363 Dimensions (L x W x H) 45 mm x 41 mm x 140 mm Weight 170 g G1/4“...
Page 13: Pressure Sensors
Pressure sensors Pressure sensors The pressure sensors (Fig. 13) of STREETEC autoleveling The sensor for the tank pressure can also be mounted in various ways: are extremely robust sensors for the automotive sector and are designed for a pressure range from 0 to 16 bar. They have 1.
Page 14 Technical data - Pressure sensors Dimensions - Pressure sensors Product details Product STREETEC autoleveling - pressure sensors Item number 9909 2 0204 Dimensions (L x W x H) 114,5 mm x 71 mm x 10,2 mm Weight 44 g Electrical details Nominal voltage max.
Page 15: Height Sensors
Height sensors Height sensors Height sensors (Fig. 18) should be installed with care. The goal is to use as much sensor range as possible to achieve Ideally, mount the sensors in the same place on the driver‘s and passenger‘s sides maximum accuracy of height regulation. However, the sensors of the vehicle in mirror image. This ensures that the sensor area is as equal as must always be operated within the approved operating range possible on each side.
Page 16 Height sensors Height sensors Selecting the sensor position Selecting the correct mounting hole for the coupling rod in the sensor arm. 1. Attach the sensor to the vehicle and place the sensor arm The maximum angle for the height sensor is 120 degrees. in the center position.
Page 17 Height sensors Height sensors 4. If you do not have a tap available for deburring the Adjusting the length of the coupling rod threaded rod, screw a nut onto the threaded rod before 1. Using a gear jack, move the suspension to the center cutting the rod.
Page 18 Technical data - Height sensors Checking the traverse path Product details Product STREETEC autoleveling - Height sensors 1. After you have installed the sensors at all four wheel positions, you can check the Item number 9909 2 0027 working area with the sensor tool in the control unit. Proceed carefully here so that...
Page 19: Installation Cable Set
• Connect the stripped compressor cables to the stripped compressor connection cables of the main harness; use the supplied shrink butt connectors for this purpose. Remove all fuses of the STREETEC autoleveling when bridging the vehicle or welding on the vehicle. Failure to do so could result in damage to the system.
Page 20 • Insert the supplied 40 A fuse into the fuse holder and close the flap of the fuse holder. compressors, a second power connection cable is required. Contact a STREETEC dealer to purchase the optional wiring harness for the second Fuse for connection cable switched positive from ignition start switch (red - 0.75 mm²) compressor (part number: 1160 00 00).
Page 21 • Route the display harness to the area of the vehicle where you want to use the display. • Connect the supplied USB-C cable for the display to the designated connector of the display harness and the display (bottom side) of the STREETEC autoleveling. • Connect the supplied warning buzzer to the display harness.
Page 22: Connection Diagram
Connection diagram RL/HL RR/HR FR/VR FL/VL OPTIONAL OPTIONAL TANK...
Page 23: Installation Airlines
Installation air line Installation air line The air lines can be routed in or under the vehicle. In any case, make sure that all air lines are Cutting the air lines tips & tricks! protected from abrasive edges and heat sources. Cutting the air lines: 1.
Page 24: Disassembling Air Line / Fitting
Assembly air line / fi tting Disassembly air line / fi tting 1. Cut the air line at right angles and free of burrs. Make sure that the air line has no sharp edges, 1. Make sure that there is no pressure on the 2. Push back the retaining element of the fi tting longitudinal grooves or other damage.
Page 25: Autoleveling App
Autoleveling APP Download the free app for the best autoleveling experience. The mobile app ‚STREETEC autoleveling‘ allows you to fully integrate your new autoleveling control with your mobile device. Simply download the free app to not only take full control of your air suspension, but also always have the latest fi rmware with updates directly from your app on your autoleveling.
Page 26 Quick Start Guide Quick Start Guide On the following pages, we will show you how to put the STREETEC autoleveling into operation and Language selection explain the most important functions. During the fi rst start-up, some basic settings have to be made, but all of them can be changed afterwards.
Page 27 However, the connection can of course be made at a later time via the smartphone app. Display when STREETEC autoleveling has Selection of whether height sensors are installed. successfully connected to the smartphone.
Page 28 Quick Start Guide Selection of the installed pressure sensor. Display when calibration has been successfully completed. The calibration of the STREETEC autoleveling Query whether the vehicle with STREETEC goes through 16 steps in which the vehicle autoleveling is used by different people.
Page 29: Quick Start Guide
Quick Start Guide Quick Start Guide Current vehicle Profile (P1, P2, P3) Selection of the fi rst user profi le height Display of user‘s initials Selection of the user profile or (Optional) vehicle height [14]. In the smartphone app, the profi les can also be assigned names and colors! Settings Tank pressure Bellows pressure front...
Page 30 Quick Start Guide Quick Start Guide Main screen Setting a new driving pressure (without height sensors) • Display, if Calibration has NOT been performed! • Setting each Wheel position → Convertible to axis-by-axis adjustment (17) User profi le selection Setting a new driving pressure (without height sensors) •...
Page 31 Quick Start Guide Quick Start Guide Setting of a new driving height (with height Manual adjustment with display of pressure and sensors) height (with height sensors) • Setting each Wheel position → Convertible to axis-by-axis adjustment (17) Setting of a new driving height (with height Leveling the vehicle sensors) New Setpoint...
Page 32 Quick Start Guide Settings Display after aligning the vehicle. General settings • Pressure unit (bar or psi) • Language • Enable or disable user profi les Compressor control • Tank pressure (10 to 14 bar) [recommendation max. 12 bar]. • Switch-on threshold/pressure drop, at which the compressor switches on •...
Page 33 Lock adjustability in case of travel detection by a • When pressure compensation is activated, STREETEC connected signal (e.g. speed signal). autoleveling attempts to regulate as small a pressure • Speed at which adjustability is deactivated (with difference as possible between the left and right sides...
Page 34 Settings Settings Display Calibration • Display brightness • Calibration of pressure/height control • Dimming of the display when the driving lights are • Calibration of the speed switched on • Brightness with dimmed display • Intensity of the haptic feedback of the touchscreen Reset •...
Page 35: Component List
9909 2 0029 STREETEC autoleveling - cable FR for height sensor (6 meter) 9909 3 0015 STREETEC autoleveling - pressure sensor mounting block fitting pack - 10 mm 9909 2 0030 STREETEC autoleveling - cable RL for height sensor (3.6 meter)
Page 36: Declaration Of Conformity
Declaration of Conformity Notes on disposal The STREETEC autoleveling complies with the essential requirements of the European and national radio equipment directive - 2014/53/EU Disposal note! Do not dispose of the device in household waste! Electronic devices must be The manufacturer / distributor disposed of in accordance with the directive on waste electrical and electronic equipment via the local collection points for waste electronic equipment..
Page 37: Manufacturer Information
Industriestraße 12 64739 Höchst im Odenwald A copy of the instructions can also be downloaded from our website: https://www.STREETEC.net/certification Do you need help? Contact the STREETEC / null-bar customer service department from Monday to Friday at +49 (0) 6163 - 939928.
Page 38 +49 (0)06163 939928 STREETEC GmbH Industriestraße 12 www.streetec.net D-64739 Höchst im Odenwald...
