- Page 1 PTZK-VB10 PTZK-VB6 PTZK-VB4 Pan-Tilt-Zoom Mounting Kit for VB Frames Series 2 INSTALLATION MANUAL 10 NEWTON PLACE HAUPPAUGE, NY 11788 USA (877) 685-8439 / (516) 671-7278 / FAX (516) 671-3362 sales@multidyne.com...
-
Page 2: Table Of Contents
DOCUMENT REVISIONS www.multidyne.com Table of Contents Table of Contents ............................. 2 Overview ............................3 PTZK-VBx content ..........................3 Installation ............................4 Contact Info .............................. 9 Document Revisions Revision Description Date Author Initial 5/6/2023... -
Page 3: Overview
PTZK-VBX CONTENT 1. Overview Multidyne Pan-Tilt-Zoom Mounting Kits use the Versatile LightBrix modular interface to securely attach a PTZ camera onto a VB enclosure, and to a tripod or ceiling (for a fixed installation). VB enclosures come in different sizes; currently PTZK-VB kits support VB4, VB6 & VB10 formats. Part numbers are: PTZK-VB10 (for VB10 enclosures) •... -
Page 4: Installation
INSTALLATION 3. Installation 3.1. PTZ Camera Preparation Most PTZ cameras are designed with mounting holes on the bottom side. The PTZK-VBx Camera Plate has been designed to accommodate most camera brands. The first step is to attach your camera to the PTZK-VBx Camera Plate. Screws for this are not included; you need to refer to your camera installation instructions, which specify the type of screws and maximum penetration allowed. - Page 5 INSTALLATION 3.2. Tripod Preparation Next is attaching the tripod platform plate to the PTZK-VBx Tripod/Ceiling Plate. Most tripod heads come with a sliding or quick-lock platform plate as shown on figure B below, and include the ¼-20 or 3/8-16 captive screws to attach the plate to your device. You will need nuts of the corresponding size* to fix the platform plate to the PTZK-VBx Tripod/Ceiling Plate as shown below.
- Page 6 INSTALLATION 3.3. Attaching the PTZ camera to the VB enclosure Place the PTZ camera assembly on top of the VB enclosure. Ensure that the connector side of the camera is on the same side as the connector side of the VB enclosure. Use eight of the sixteen 4-40 x 1.4in long pan head screws to attach them as shown on figure C.
- Page 7 INSTALLATION 3.4. Attaching the tripod plate to the VB enclosure Do the same thing with the tripod plate assembly and attach it to the other side of the VB enclosure using the remaining eight 4-40 x 1/4in long pan head screws. Figure D: Installing the PTZ camera on the VB enclosure Note: in the case of a ceiling installation, you perform the same assembly shown above, but upside- down.
- Page 8 INSTALLATION 3.5. Slide the PTZ/VB assembly on the tripod Once the PTZ/VB assembly is complete, slide the platform plate onto the tripod head rail and lock it in place. Figure E: Slide the PTZ/VB assembly on the tripod head...
-
Page 9: Contact Info
CONTACT INFO Contact Info For support, please contact us by email at support@multidyne.com...
