Summary of Contents for AQESO U87E
- Page 1 AQESO Upper Arm Electronic Blood Pressure Monitor Model:U87E User Manual...
-
Page 2: Table Of Contents
Table of Contents Introduction Safety Information Product Structure Battery Installation Setting Mode Proper Use of the Unit -Pre-measurement -Common factors of wrong Measurement -Fitting the cuff -Measuring procedure -Discontinuing a measurement -Memory-recall of measurements Reading Memory Record Memory -clear of Measurements Common Sense of Blood Pressure Exceptional Situations Care and Maintenance... -
Page 3: Introduction
Introduction Your new digital blood pressure monitor uses the oscillometric method of blood pressure measurement. This means the monitor detects your blood's movement through your brachial artery and converts the movements into a digital reading. An oscillometric monitor does not need a stethoscope, so the monitor is simple to use. -
Page 4: Safety Information
Safety Information To assure the correct use of the product, basic safety measures should always be followed including the warning and the caution listed in the instruction manual : Symbol descriptions The following symbols may appear in this manual, on the label, on the device, or on it's accessories. - Page 5 Safety Information Those who have arrhythmia, diabetes, blood circulation or apoplexy problem, please use under the physician's instruction. Contact your physician for specific information about your blood pressure. Self diagnosis and treatment which use measured results may be dangerous.Follow the instructions of your physician or licensed healthcare provider.
- Page 6 Safety Information Consecutive blood pressure measurements should be repeated after 1 minute pause or after the arm has been held up in order to allow the accumulated blood to flow away. If the arm circumference size is beyond the measuring range of CUFF, it can't be measured and used, then it will cause the blood flowing unsmooth and wrong measurement data.
- Page 7 Safety Information Do not use the equipment where flammable gas(such as anesthetic gas, oxygen or hydrogen)or flammable liquid(such as alcohol)are present. Do not touch the output of AC adapter and the patient simultaneously. Do not touch the live end of battery and the patient simultaneously when change the batteries.
-
Page 8: Product Structure
Product Structure Body Color changing LED light Air socket WHO indicator Setting button Memory button Start/Stop button Type-C socket LED Color Red LED Yellow LED 130~140 85~90 Green LED 08/27... - Page 9 Product Structure Display Year/Month/ User Date/Time Systolic blood pressure Blood pressure classification Diastolic blood pressure Irregular heart Memory symbol beat Pulse rate low battery symbol Pulse Memory times Cuff size and connection The accessories cuff is L size, for upper-arm circumference 22-42cm use.
-
Page 10: Battery Installation
Battery Installation Battery installation Remove the battery cover from the battery compartment at the back of the monitor, insert the battery. a)Remove the battery cover as picture showed. b)Insert 4 AAA powerful batteries into the compartment and ensure each battery is in the proper direction. Low battery and replacement When the low battery symbol display, you must replace with... - Page 11 Battery Installation Adapter usage(optional) 1.When optional AC adapter should comply with the requirement of IEC 60601-1:2005.Furthermore all configurations shall comply with the requirements for medical electrical systems(see IEC 60601-1-1 or clause 16 of the 3Ed.of IEC 60601-1,respective-ly).Anybody connecting additional equipment to medical electrical equipment configures a medical system and is therefore responsible that the system complies with the requirements for medical electrical systems.Attention is drawn to the fact that local laws take priority...
-
Page 12: Setting Mode
Setting Mode Note: ·Do not use batteries and the AC adapter at the same time. ·Only comes with a Micro USB charge cable. AC adapter is not included. ·When suddenly stop during measurement(like the plug off from the outlet by carelessness), it must be reinserted the plug into the unit, and restart the measurement. - Page 13 Setting Mode Note: If you need to reset the date and time, remove and re-install the batteries. Then set the date and time as above steps. Year setting Month setting Date setting Hour setting Minute setting 13/27...
-
Page 14: Proper Use Of The Unit
Proper Use of the Unit Measurement Pre-measurement ·Relax for about five to ten minutes prior to the measurement Avoid eating,drinking alcohol, smoking, exercising and bathing for 30 minutes before taking a measurement. All these factors will influence the measurement result. ·Remove any garment that fits closely to your upper arm. -
Page 15: Fitting The Cuff
Proper Use of the Unit Fitting the CUFF 1). Put the cuff on a table flatly with the velcro side down.Pass the end of the cuff through the metal loop so that a circle is formed. The velcro closer will now be facing outwards(ignore this step if the cuff has already been prepared). -
Page 16: Measuring Procedure
Proper Use of the Unit Measuring procedure: After the cuff has been appropriately positioned, the measurement can begin: 1). Press the START/STOP button, all symbols appear on the display, then the pump begins to inflate the cuff, the rising pressure in the cuff is shown on the display. -
Page 17: Memory-Recall Of Measurements
Proper Use of the Unit Memory-recall of measurements This blood pressure monitor automatically stores 2×99 sets measurements value, the oldest record will be replaced by the latest measurement value when more than 99 sets each user. Read memory record Press the button MEM when power off,the latest 3 times average value will be shown, press the button MEM again, the last measurement value will be shown, as well as subsequent measurements can be display one after the other by pressing... -
Page 18: Common Sense Of Blood Pressure
Common Sense of Blood Pressure About blood pressure •Blood pressure is the pressure exerted the arteries. •The systolic blood pressure value represents the blood pressure produced by contraction of the heart muscle. •The diastolic blood pressure value represents the blood pressure produced by relaxation of the heart muscle. - Page 19 Common Sense of Blood Pressure According to the blood pressure classification by the WHO/ISH. SYS lower than 100mmHg is considered as hypotension. Diastolic blood pressure (mmHg) Severe hypertension Moderate hypertension Mild hypertension High normal value Normal blood pressure Optimal blood pressure (target value) Systolic blood pressure...
-
Page 20: Exceptional Situations
Exceptional Situation Error indicators The following symbol will appear on the display when measuring abnormal. Symbol Cause Correction Weak signal or Wrap the cuff properly. pressure change Remeasure with correct way. suddenly When near cell phone or other high radiant device the External strong measurement will be failed. -
Page 21: Care And Maintenance
Care and Maintenance Care for the main unit and blood pressure monitor cuff Keep the unit in the storage case when no use. Clean the unit with soft dry cloth. Do not use any abrasive or volatile cleaners. Never immerse the unit or any component in water. -
Page 22: Specifications
Specification Description Automatic upper arm blood pressure monitor Display LCD digital display Measuring principle Oscillometric method Measuring localization Upper arm Measurement Pressure 0~299mmHg range Pulse 40~199 pulses/min Pressure ±3mmHg Accuracy Pulse ±5% of reading Pressure 3 digits display of mmHg Pulse 3 digits display indication... -
Page 23: Warranty Information
Warranty Information Statement The intended use: the unit is intended to be used by adults at home or medical center to measure blood pressure and pulse rate from the upper arm. The unit satisfies the requirements of EN ISO 81060-1 Part 1 Noninvasive sphygmomanometers, EN 1060-3:1997+ A2:2009 Non-invasive sphygmomanometers. -
Page 24: Emc Declaration
EMC Declaration IEC 60601-1-2: 2014 ME EQUIPMENT and ME SYSTEMS identification, marking and documents for Class B product Instructions for use The ME EQUIPMENT or ME SYSTEM is suitable for home healthcare environments and so on. Warning: Don’t near active HF surgical equipment and the RF shielded room of an ME system for magnetic resonance imaging, where the intensity of EM disturbances is high. - Page 25 EMC Declaration Technical description 1. All necessary instructions for maintaining BASIC SAFETY and ESSENTIAL PERFORMANCE with regard to electromagnetic disturbances for the excepted service life. 2. Guidance and manufacturer’s declaration -electromagnetic emissions and Immunity. Tabe 1 Guidance and manufacturer’s declaration - electromagnetic emissions Emissions test Compliance RF emissions CISPR 11...
- Page 26 EMC Declaration Tabe 2 Guidance and manufacturer’s declaration - electromagnetic Immunity IEC 60601-1-2 Immunity Test Compliance level Test level Electrostatic discharge (ESD) ±8 kV contact ±8 kV contactv ±2 kV, IEC 61000-4-2 ±2 kV, ±4 kV, ±8 kV, ±15 kV air ±4 kV, ±8 kV, ±15 kV air Power supply lines: ±2 kV Electrical fast transient/burst...
- Page 27 EMC Declaration Tabe 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Test Band Service Modulation Modulation Distance IMMUNITY Radiated RF Frequency (MHz) TEST LEVEL (MHz) (V/m) IEC61000-4-3 380 – 390 TETRA 400 Pulse (Test modulation 18 Hz specifications 430 – 470 GMRS 460, FRS 460 ±...
- Page 28 Upper Arm Electronic Blood Pressure Monitor 93%RH 10%RH...
