Pico Macom BPF Specifications

Headend & Electronics
60-Channel Range 54-408 MHz
(CATV 2-54, 95-99)
7-section bandpass filter design
ensures sharp skirt selectivity
and provides excellent picture
quality
Front panel adjustable Hi-Q
traps provide easy field sup-
pression of out of band carriers
for increased adjacent channel
performance
Compact and efficient design
enables single rack unit (1
height installation saving valu-
able rack space
Adjustable bandwidths for
worldwide applications
www.picomacom.com
408MHz Single-Channel Bandpass Filter
BPF
408MHz Single-Channel Bandpass Filter
The Pico Macom BPF is an extremely cost and space effective professional
grade single-channel bandpass filter. The BPF was designed to provide an
additional level of bandpass filtering when used in conjunction with Pico
Macom's XBS series of single channel amplifiers, especially in applications
where undesired adjacent channels are present. The high out-of-band signal
rejection eliminates cross modulation and overload distortion caused by strong
adjacent carriers entering an amplifier. Unwanted images caused by dual
amplifier processing of the same signal are also eliminated thereby further
reducing distortions and improving picture quality. Four front panel tunable
Hi-Q traps allow easy selection and suppression of adjacent carriers. The BPF
is useful also in eliminating unwanted conversion products resulting from
3 / ˝)
4
strong local signals entering the Pico Macom XUV channel converter thereby
achieving cost effective drop in expansion. Pico Macom backs up this product
with its industry leading 5-year limited warranty.
PICO MACOM, INC.
355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: 818-493-4433
BPF
355 A-59
Parkside
Rev. 12/02
