FlashPro2000 Flash Programmer
Multi-FPA API-DLL User's Guide
Software version 1-1
PM034A02 Rev.1
May-2009
Elprotronic Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlashPro2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Elprotronic FlashPro2000

  • Page 1 FlashPro2000 Flash Programmer Multi-FPA API-DLL User’s Guide Software version 1-1 PM034A02 Rev.1 May-2009 Elprotronic Inc.
  • Page 2 Limit of liability: In no event will Elprotronic Inc. be liable to you for any loss of use, interruption of business, or any direct, indirect, special incidental or consequential damages of any kind (including lost profits) regardless of the form of action whether in contract, tort (including negligence), strict product liability or otherwise, even if Elprotronic Inc.
  • Page 3 The software, firmware and related documentation (collectively the “Product”) is the property of Elprotronic or its licensors and is protected by copyright law. While Elprotronic continues to own the Product, You will have certain rights to use the Product after Your acceptance of this license.
  • Page 4 Therefore, you must treat the Product like any other copyrighted material. 3. Limitation of liability. In no event shall Elprotronic be liable to you for any loss of use, interruption of business, or any direct, indirect, special, incidental or consequential damages of any kind (including lost profits) regardless of the form of action whether in contract, tort (including negligence), strict product liability or otherwise, even if Elprotronic has been advised of the possibility of such damages.
  • Page 5 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications not expressly approved by Elprotronic Inc. could void the user’s authority to operate the equipment.
  • Page 6: Table Of Contents

    Table of Contents 1. Introduction ............. 8 2.
  • Page 7 F_Copy_Flash_to_Buffer ........69 FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 8: Introduction

    1. Introduction The FlashPro2000 adapter can be remotely controlled from other software applications (Visual C++, Visual Basic etc.) via a DLL library. The Multi-FPA - allows to remotely control simultaneously up to sixteen Flash Programming Adapters (USB-FPAs) significantly reducing programming speed in production.
  • Page 9 (FlashPro2000-FPA1.dll to FlashPro2000-FPA16.dll). The FlashPro2000-FPAsel.dll file is transparent for all API-DLL functions implemented in the single FPA API-DLLs functions. Desired destination FPA can be selected using the function F_Set_FPA_index( fpa );...
  • Page 10 Initialization and termination communication with the programming adapter, Programmer configuration setup, Programming report message, Code data and password data read from the file, Reset target device, Auto program target device ( erase, blank check, program and verify), CSM Password verification, FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 11 Selected part of memory segment read, CSM Password write. The FlashPro2000 Flash Programmer software package contains all required files to remotely control programmer from a software application. When software package is installed then by default the DLL file, library file and header file are located in: C:\Program Files\Elprotronic\C2000\USB FlashPro2000\API-DLL FlashPro2000-FPAsel.dll...
  • Page 12 All these files ‘as is’ should be copied to destination location, where application software using DLL library of the FlashPro2000 Flash programmer is installed. The config.ini file has default setup information. The config.ini file can be modified and taken directly form the FlashPro2000 Flash Programmer (GUI) application software.
  • Page 13: Getting Started

    The easy demo project MyFP2000Prg uses API-DLLs and files listed above is located in directory ...\Elprotronic\C2000\USB FlashPro2000\API-DLL-MyPrg\Cpp\MyFP2000Prg and are included for demonstration purposes only. The sample project can be opened by selecting the project file MyFP2000Prg.vcproj located in directory FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 14 FPAs are located in the FPA_SN_list[k] where k = 0 up to 15. Up to sixteen FPA SN can be located in this data block. SN list are located starting from FPA_SN_list[0]. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 15 UINT16 *data ); read_data_from_buffer( int source, long addr, long size, UINT16 *data ); See the MyFP2000PrgDlg.cpp file how to strat-up communication with FPA and how to use the API-DLLs instructions. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 16: Example With Api Dll

    Below is an example of the simplified (without error handling procedures) application program written in C++ that allows to initialize one FPA, and run an autoprogram with the same features like an autoprogram in the standard FlashPro2000 (GUI) software. 1. Download data to target device F_OpenInstancesAndFPAs( “*# *”...
  • Page 17: Example With Multi-Fpa Api Dll

    F_CloseInstances() function should be called as the last one after all functions are finished in similar way like the FlashPro2000 GUI software is opening once and closed at the end when job is finished. The startup initialization take few seconds (when F_OpenInstancesAndFPAs(..) and...
  • Page 18 Below is an example of the simplified (without error handling procedures) application program written in C++ that allows to initialize all dlls and FPA, and run an autoprogram with the same features like autoprogram in the standard FlashPro2000 application software. 1. Download data to all target devices (uses USB-FPAs) response = F_OpenInstancesAndFPAs( FPAs-setup.ini);...
  • Page 19 ..........} while(1); //make an infinite loop until last target device programmed ..............F_CloseInstances(); See source code in the DEMO program written in Visual C++, Visual Basic or LabView for more detail. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 20: List Of The Dll Instructions

    Code Files, which should be loaded before the encapsulated functions are used. To augment the functionality of the encapsulated functions, sequential functions can be executed immediately after to complete the programming process. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 21 Close Target Device instruction should be called. When communication is terminated, then sequential instructions can not be executed. Note: Inputs / outputs has been defined as INP_X, and LONG_X. Both of them are defined as 4 bytes long (see FlashPro2000-Dll.h header file ) #define INP_X _int32...
  • Page 22 FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 23: Multi-Fpa Instructions

    Note: Tracing is slowing the time execution, because all information passed from application software to API-DLL are recorded in the dlltrace.txt file. Syntax: void MSPPRG_API F_Trace_ON( void ); F_Trace_OFF F_Trace_OFF - Disable tracing, See F_Trace_ON for details. Syntax: void MSPPRG_API F_Trace_OFF( void ); FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 24: F_Openinstances

    MAX_USB_DEV_NUMBER = 16 Return value: number of opened instances F_CloseInstances F_CloseInstances - Close all active API-DLLs and free system memory. Syntax: INT_X MSPPRG_API F_CloseInstances ( void ); Parameters: void Return value: TRUE FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 25: F_Openinstancesandfpas

    Return value: number of opened instances 1. The FPA list in the string: String -> “*# SN1, SN2, SN3, SN4, SN5...” Where the SN1- FPA’s serial number that should be assigned to FPA-1 index FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 26 Last one will be any adapter USB-FPA not listed before. Initialization examples: F_OpenInstancesAndFPAs( “*# *” ); // only one any adapter F_OpenInstancesAndFPAs( snlist ); // hardcoded SN list 2.The FPA list in the configuration file: String -> “C:\Program Files\Elprotronic\FPAs-setup.ini” FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 27 F_OpenInstancesAndFPAs( “*# *” ); //DLL startup and FPA assignment //by default - FPA-1 is selected. //The F_Set_FPA_index(1) is not required. F_Initialization(); //FPA 1 initialization F_ReadConfigFile( filename ); //download configuration to DLLs. F_ReadCodeFile( filename ); //download code file to DLLs. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 28 //start autoprogram to all FPAs simultaneously. if( status != TRUE ) if( status == FPA_UNMATCHED_RESULTS ) // service software when results from FPAs are not the same else ..........} while(1); F_CloseInstances(); // release DLLs from memory FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 29: F_Set_Fpa_Index

    API-DLLx) can be read using the F_Set_FPA_index( 1 ), F_Set_FPA_index( 2 ) .., and F_Get_Word_from_Buffer(..). See below F_Set_FPA_index (ALL_ACTIVE_FPA); //select all available FPAs F_Memory_Read(); //simultaneous process for( fpa=1; fpa=fpa_max; fpa++ ) if( F_Set_FPA_index(fpa) == FPA_INVALID_NO ) continue; for(addr = addr_min; addr <= addr_max; addr++) data[addr][fpa-1] F_Get_Word_from_Buffer(addr); FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 30: F_Get_Fpa_Index

    FPA. Communication with target devices connected to selected FPA will be stopped. When the F_Set_FPA_index(0) will be used, then selected FPA will be ignored. Result will not be presented in the Status results (Status and F_LastStatus(..)). FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 31: F_Enable_Fpa_Index

    When function is transferred to all API-DLLs (when the fpa=0) then returned parameter (status) is the same as the returned value from the API-DLLs when the ALL returned values ARE THE SAME. If not, then returned value is FPA_UNMATCHED_RESULTS (value of the is minus 1). FPA_UNMATCHED_RESULTS FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 32: F_Multi_Dlltypever

    - FPA index of the desired status fpa index -> 1..16 Return value: Serial number of the selected FPA or FPA_INVALID_NO - if used fpa index is not activated or out of range. note: FPA_INVALID_NO -> -2 (minus 2)(0xFFFFFFFE) FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 33: Generic Instructions

    Multi-FPA functions. Syntax: MSPPRG_API LONG_X F_Check_FPA_access ( INT_X USB_index ); Parameters: Index: USB driver index from 1 to MAX_USB_DEV_NUMBER where MAX_USB_DEV_NUMBER = 16 Return value: 0 - FALSE >0 - Detected USB-FPA Serial Number FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 34: F_Initialization

    - ( 1 to 16 ) or 0 (ALL FPAs) executed sequentially. F_Initialization function should be called after the communication with the FPA adapter is established. To make a Multi-FPA software back compatible, the F_Initialization procedure is calling FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 35: F_Close_All

    To activate communication with the programmer when the function F_Close_All has been used the F_Initialization function must be called first. Syntax: MSPPRG_API INT_X F_Close_All( void ); FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 36: F_Setconfig

    Note: See theFlashPro2000-Dll.h header file for the list of the latest indexes, definitions etc. Syntax: MSPPRG_API INT_X F_SetConfig( INT_X index, LONG_X data ); Return value: 0 - FALSE 1 - TRUE -2 - FPA_INVALID_NO Example: ..........F_SetConfig( CFG_MICROCONTROLLER, MCU_Index ); ....... FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 37 CFG_VERIFYMODE CFG_FLASH_ERASE_MODE CFG_FLASH_NOT_ERASE_IFBLANK CFG_DONOT_OVERWRITE_OTP CFG_DEF_OTP_WRITE_EN CFG_DEF_OTP_START_ADDR CFG_DEF_OTP_STOP_ADDR CFG_DEF_FLASH_ERASE_EN CFG_DEF_ERASE_START_ADDR CFG_DEF_ERASE_STOP_ADDR CFG_RETAIN_DEF_DATA_EN CFG_RETAIN_START_ADDR CFG_RETAIN_STOP_ADDR CFG_FLASH_READ_MODE CFG_DEF_FLASH_READ_EN CFG_DEF_READ_FLASH_START_ADDR CFG_DEF_READ_FLASH_STOP_ADDR CFG_DEF_OTP_READ_EN CFG_DEF_READ_OTP_START_ADDR CFG_DEF_READ_OTP_STOP_ADDR CFG_CSMLOCK_PASSWORD_INDEX CFG_CSMLOCK_PASSWORD_ENABLE CFG_CLK_FERQ_IN_KHZ CFG_JTAG_CHAIN_POS CFG_JTAG_CHAIN_SIZE CFG_JTAG_IRSIZE_DEVICE_1 CFG_JTAG_IRSIZE_DEVICE_2 CFG_JTAG_IRSIZE_DEVICE_3 CFG_JTAG_IRSIZE_DEVICE_4 CFG_JTAG_IRSIZE_DEVICE_5 CFG_JTAG_IRSIZE_DEVICE_6 [ CFG_MICROCONTROLLER FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 38 0 - TMS320F240 1 - TMS320F242 2 - ..See the latest MCU list and indexes in the FlashPro2000 (GUI) software. Run software -> list available under pull down menu Setup-> MSP list Also the MCU index and MCU names can be taken from the instruction F_Get_Device_Info().
  • Page 39 Flash Start Address when the defined flash erase option is selected [ CFG_DEF_ERASE_STOP_ADDR 19 ] Flash End Address when the defined flash erase option is selected [ CFG_RETAIN_DEF_DATA_EN 20 ] Enable (1) / disable (0) [ CFG_RETAIN_START_ADDR 21 ] Retain Data Start Address FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 40 Enable (1) / disable (0) [ CFG_CLK_FERQ_IN_KHZ 32 ] External CLK frequency in kHz [ CFG_JTAG_CHAIN_POS 33 ] Devices position in the JTAG chain - from 1 to number of devices in the JTAG chain FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 41: F_Getconfig

    Index’s list - see F_SetConfig Return value: Requested setup parameter; 1 - TRUE -2 (0xFFFFFFFE) - FPA_INVALID_NO Example: ....... Interface = F_GetConfig( CFG_INTERFACE ); ....... F_Get_Device_Info F_Get_Device_Info - Get information related to selected microcontroller. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 42 The max size can be tested from the API-DLL, until device name is empty when the microprocessor index is incremented from the zero up to max value. In the example below is assumed that te max FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 43 //now you can read data from API-DLL ............get_devices_list( void n,k, p,st, index_bak, max_up_index; DEVICELIST tmp; *tmp.name = '\0'; tmp.index = 0; tmp.flash_start_addr = 0; tmp.flash_end_addr = 0; tmp.OTP_start_addr = 0; tmp.OTP_end_addr = 0; tmp.RAM_size = 0; FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 44 ) if( strcmp( DeviceList[n-1].name, DeviceList[n].name ) < 0 ) continue; st = TRUE; tmp = DeviceList[n-1]; DeviceList[n-1] = DeviceList[n]; DeviceList[n] = tmp; if( st == FALSE) break; Max_MCU_index = max_up_index; FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 45: F_Dispsetup

    REPORT_MESSAGE_MAX_SIZE is de fined in the FlashPro2000-dll.h and the value is 2000. Make REPORT_MESSAGE_MAX_SIZE sure to declare characters string length no less then 2000 characters. When F_ReportMessage is called then at the end the internal report message buffer in the programmer software is cleared.
  • Page 46: F_Getreportmessagechar

    0); UpdateWindow(); F_GetReportMessageChar F_GetReportMessageChar - Get one character of the the last report message from the programmer. VALID FPA index - ( 1 to 16 ) See comment for the F_ReportMessage function. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 47: F_Dlltypever

    Message = text; SetDlgItemText(IDC_REPORT, Message.GetBuffer(Message.GetLength())); CEdit* pEdit = (CEdit*) GetDlgItem(IDC_REPORT); pEdit->LineScroll(pEdit->GetLineCount(), 0); UpdateWindow(); F_DLLTypeVer F_DLLTypeVer - Get information about DLL software type and software revision. VALID FPA index - ( 1 to 16 ) FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 48: F_Configfileload

    The F_ConfigFileLoad function can download the programmer setup from the external setup file. Setup file can be created using standard GUI FlashPro2000 Flash Programmer software. When setup from the file is downloaded, then old configuration setup is overwritten. New setup can be modified using F_GetConfig and F_SetConfig functions.
  • Page 49: F_Reset_Target

    Parameter name and value must be separated by minimum one white character like space or tabulation. See the configuration file created by the FlashPro2000 software for details. Use the Notepad to open the configuration file..
  • Page 50: F_Get_Targets_Vcc

    - ( 1 to 16 ) Syntax: MSPPRG_API INT_X F_Get_Targets_Vcc( void ); Return value: INT_X - Vcc in milivolts e.g 3000 -> 3.0 V or (-1) if USB-FPA is not active. -2 (0xFFFFFFFE) - FPA_INVALID_NO FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 51: Data Buffers Access Instructions

    - all 16 bits width - Texas Instruments text format, Motorola *.s19 format and Intel *.hex format. When file is downloaded then contents of this file is analysed. Only code memory location valid for FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 52: F_Get_Codecs

    - Read code from internal code buffer and calculate the check sum. VALID FPA index - ( 1 to 16 ). Syntax: MSPPRG_API LONG_X F_Get_CodeCS( int index ); index - index of the desired code FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 53: F_Readpasswfile

    0 - FALSE 1 - TRUE -2 (0xFFFFFFFE) - FPA_INVALID_NO info is defined as follows: error -> INVALID_CODE_FILE OPEN_FILE_OR_READ_ERR PASSWORD_NOT_FOUND Example: st = F_ReadPasswFile( “c:\test\demofile.txt” ); if(( st & 1 ) == TRUE ) ....FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 54: F_Clr_Code_Buffer

    Code buffer location, but flag still will be set to used. Use the F_Clr_Code_Buffer() instruction to fully clear the Code buffer before writing the new data block. Syntax: MSPPRG_API INT_X F_Put_Word_to_Code_Buffer( LONG_X address, FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 55: F_Get_Word_From_Code_Buffer

    Parameters value: code address - valid Flash or OTP address Return value: 0x00 to 0xFFFF - valid code data -1 (0xFFFFFFFF) - code data not initialized on particular address -2 (0xFFFFFFFE) - FPA_INVALID_NO FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 56: F_Put_Word_To_Csm_Buffer

    Instruction allows to read or verify contents of the CSM Password buffer. Data returns value 0x0000 to 0xFFFF if in the particular Password buffer location the flag is set to used, otherwise return value -1 (minus one) if data is empty. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 57: F_Put_Word_To_Buffer

    FALSE - if address is not valid -2 - FPA_INVALID_NO. Example: ........for( addr = addr_min; addr<=addr_max addr++ ) st = F_Put_Word_to_Buffer( addr, data[addr] ); st = F_Copy_Buffer_to_Flash( addr_min, size ); ....F_Get_Word_from_Buffer FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 58 - ( 1 to 16 ) Syntax: MSPPRG_API BYTE F_Get_Word_from_Buffer( LONG_X address ); Return value: Requested word from the specified address of the Read Data Buffer, or negative value if address is invalid FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 59: Encapsulated Instructions

    - confirm if memory has been erase, - flash programming and verification, - flash memory check sum verification, - writing the CSM security password ( if enabled ). Syntax: MSPPRG_API INT_X F_AutoProgram( INT_X mode ); mode = 0; FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 60: F_Verify_Csm_Password

    F_Verify_CSM_Password( void ); Return value: 0 - FALSE (JTAG fuse blown or BSL password wrong) 1 - TRUE (valid access to target device) -2 (0xFFFFFFFE) - FPA_INVALID_NO or Status - see error list FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 61: F_Memory_Erase

    - ( 1 to 16 ) or 0 (ALL FPAs) executed simultaneously. Syntax: MSPPRG_API INT_X F_Memory_Blank_Check( void ); Return value: 0 - FALSE 1 - TRUE -2 (0xFFFFFFFE) - FPA_INVALID_NO or Status - see error list FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 62: F_Memory_Write

    F_Memory_Verify( INT_X mode ); mode = 0; mode = 1 and up - reserved Return value: 0 - FALSE 1 - TRUE -2 (0xFFFFFFFE) - FPA_INVALID_NO or Status - see error list F_Memory_Read FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 63: F_Write_Csm_Password

    To write the CSM security password, the flag CFG_CSMLOCK_PASSWORD_ENABLE in the configuration setup must be enable Syntax: MSPPRG_API INT_X F_Write_CSM_Password( void ); Return value: 0 - FALSE 1 - TRUE -2 - FPA_INVALID_NO. or Status - see error list FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 64: Sequential Instructions

    F_Open_Target_Device( void ); Return value: 0 - FALSE (communication failed) 1 - TRUE (communication is OK) 2 - JTAG security blown - communication failed -2 (0xFFFFFFFE) - FPA_INVALID_NO or Status - see error list FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 65: F_Close_Target_Device

    Status - see error list Example: See example above (F_Open_Target_Device). F_Segment_Erase F_Segment_Erase - Erase any segment of the TMS320Fxx Flash memory. VALID FPA index - ( 1 to 16 ) or 0 (ALL FPAs) executed sequentially. FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 66: F_Sectors_Blank_Check

    - ( 1 to 16 ) or 0 (ALL FPAs) executed sequentially. Parameters: start address stop address Syntax: MSPPRG_API INT_X F_Sectors_Blank_Check( LONG_X start_addr, LONG_X stop_addr ); Return value: 0 - FALSE 1 - TRUE FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 67: F_Write_Word_To_Ram

    - Read one word from RAM, registers, IO, OTP, Flash etc. VALID FPA index - ( 1 to 16 ) or 0 (ALL FPAs) executed sequentially. Read one word from any location of the target device. Parameters: address Syntax: FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 68: F_Copy_Buffer_To_Flash

    Function can also be used to writing longer data block, however for this purpose it is recommended to use an encapsulated function F_Memory_Write() described in this manual. The F_Copy_Buffer_to_Flash() (the same as the F_Memory_Write_Data() FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 69: F_Copy_Flash_To_Buffer

    1 - TRUE if data has been read successfully 0 - FALSE. -2 - FPA_INVALID_NO. or Status - see error list NOTE: Specified address in the temporary flash buffer is the same as a physical FLASH address. Example: ........FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
  • Page 70 = F_Copy_Flash_to_Buffer( 0x3F0000, 0x100 ); if( st == TRUE ) for( k = 0; k<100; k++ ) addr = k + 0x3F0000; data[k] = F_Get_Word_from_Buffer( addr ); else ........FlashPro2000 Multi-FPA API-DLL User’s Guide PM034A02 Rev.1...
