AquaLogic Inline Duo User Manual

Introduction

The AQUA Logic drinking water filters are developed by Innologic BV as commissioned by
www.ibota.org
the IBOTA Foundation (
drinking water treatment in disaster areas and every other situation where clean and safe
drinking water is not available. Components of these drinking water filters are being
produced in India as project for underprivileged young people. Your purchase contributes
to this project. Thank you.
The AQUA Logic Inline Duo is a water filter that can be mounted between the water
pipes of an existing water pressure system. The filter has a very low pressure drop,
making it very suitable for off-grid housing, for example, which are often equipped with
simple pressure pumps. The Inline Duo concept is designed for this growing group of
people who want to purify their own drinking water out of, for example, rainwater.
Applications are self-sufficient tiny-homes, off-grid houses, caravans, motorhomes,
yachts or situations where the regular water supply is not reliable due to various types
of pollution.
Read the entire user manual carefully before putting this filter into use.

Filter characteristics

1. Activated carbon cylinder with a pore size of 1 micron
The activated carbon consists of 100% organic material (coconut
shell) and has a very high adsorption capacity.
Activated carbon adsorbs odor, color and taste, metals such as lead,
as well as yeasts, chlorine, medicine residue and other chemicals.
2. Ultrafiltration membranes with a pore size of 0.03 micron
Filters: Pathogenic organisms: Log 6 bacterial reduction: >99.9999%
(including Cholera, Shigella, Typhus, Klebsiella Terrigena, Legionella
and e. Coli) and Cysts / Protozoa (including Giardia and
Cryptosporidium)
Micro- and Nano plastics from a size of 0.03 microns (300
nanometers)
This single filter is capable of producing safe and clean drinking water of high quality. The filter works without the addition of
chemicals and is made up of maintenance-free and corrosion-free parts.

Extensions for other water supplies

AQUA Logic - Inline PP - 10mcr - Sediment Filter:
If water other than 'clean' tap water is filtered, we recommend adding the
Inline PP filter to the system as a pre-filter. This 10 micron Polypropylene
Sediment filter extends the lifetime of other filter elements. Dirt can cause
the activated carbon cylinder and the ultra-membranes to become clogged
prematurely. When this happens, the water pressure of the water from the
tap will decrease.
AQUA Logic - Inline Backwash - 60 mcr - Sediment Filter:
When water is filtered from a source in which coarse contamination is visibly
present, an extra Backwash pre-filter can be helpful. A Backwash filter means
that the filter housing has a drain with a mounted ½ inch ball valve so that
the filter can be easily rinsed clean and the collected dirt can be flushed away
from the filter. The sediment filter cartridge, with a sieve perforation of 60 microns, filters the coarsest sediments such as sand
and mud from, for example, rainwater or other natural water. This will extend the lifespan of your appliances, pipes and water
filters.
Innologic B.V. - P.O. Box 207, 8180 AE Heerde, The Netherlands - +31 (0)578 611 654 - info@innologic.nl -
Inline Duo - Carbon + Ultra Full-Size Drinking Water Filter
User Manual
). IBOTA Foundation aims to provide filters for
www.aqualogicfilters.com
