Pico Macom PFR-2 Specifications

Fiber Optic
PFR
T
he Pico Macom models PFR-2 and PFR-4 professional series fiber optic receivers take an optical source from a forward trans-
mitter in the frequency range of 54~860MHz and convert to RF signals. The PFR series has one optical input and is available
in two and four-output versions. Employing state-of-the-art GaAs amplifier design, the PFR-2 and PFR-4 operate at a low
optical window with improved composite distortion performance. These optical receivers utilize a new low noise, impedance
matched, high efficiency 1310/1550nm broadband photodiode and advanced RF amplification circuitry to facilitate carriage of
critical upstream video, data, telephony and Internet traffic in an HFC broadband environment.
Features
• Available in 2 and 4 RF output configurations.
• Optical power monitoring.
• 54~860MHz bandwidth allows operation for current and
future CATV broadband services.
• Operates at a high 45dBmV RF output at an optical
wavelength of 1310/1550nm, providing excellent C/N ratio.

www.picomacom.com
Series
Series
Optical Forward Receivers
6260 Sequence Drive San Diego, CA 92121
Ph: 858-546-5050 Toll Free: 800-421-6511 Fax: 858-546-5051
• -20dB RF test point for convenient RF system monitoring.
• Low power consumption.
• Wide optical window -3dBm to 3dBm for improved system
performance.
• Adjustable equalization.
PICO MACOM
Rev. 9/07
