P.M. Tamson Instruments bv

van 't Hoffstraat 12

2665 JL Bleiswijk

THE NETHERLANDS

Thermometer man.docx Rev 1.02 UK "23

USER-

MANUAL

Thermometer

TT3

Tamson Instruments bv

T. 31 (0) 10 522 43 73

F. 31 (0) 10 521 19 41

www.tamson.com

info@tamson.com

VAT: NL 80 66 34 984 B01

Bank account no.: Rabobank 16 01 00 046

Chamber of commerce 27 16 95 41

IBAN Code: NL95 RABO 0160100046

Page

1/22

Table of Contents

Need help?

Do you have a question about the TT3 and is the answer not in the manual?

Questions and answers

Summary of Contents for PMT TT3

Page 1 USER- MANUAL Thermometer Tamson Instruments bv P.M. Tamson Instruments bv VAT: NL 80 66 34 984 B01 T. 31 (0) 10 522 43 73 van 't Hoffstraat 12 Bank account no.: Rabobank 16 01 00 046 F. 31 (0) 10 521 19 41 2665 JL Bleiswijk Chamber of commerce 27 16 95 41 www.tamson.com...
Page 2: Table Of Contents
GIVES PROBLEMS 13.3 ........................ 21 T LOAD DATA IN AMCOM EC DECLARATION OF CONFORMITY THERMOMETER TT3 ............... 22 Tamson Instruments bv P.M. Tamson Instruments bv VAT: NL 80 66 34 984 B01 T. 31 (0) 10 522 43 73 van 't Hoffstraat 12 Bank account no.: Rabobank 16 01 00 046...
Page 3: Safety And Warnings
SAFETY AND WARNINGS Make sure before installing or operating the equipment to read and understand all instructions and safety precautions listed in this manual. If there are any questions concerning the operation of the equipment or about the information given in this manual please contact your local dealer or our sales department first. Performance of installation, operation, or maintenance other than those described in this manual may result in a hazardous situation and may void the manufacturer's warranty.
Page 4: Precautions And Hazards
PRECAUTIONS AND HAZARDS Before attempting to operate the thermometer read all parts of this manual carefully to insure smooth operation and avoid damage to the equipment or its accessories. If a malfunction occurs, consult section "Trouble shooting”, page 21. If the problem persists email use our contact form at https://tamson-instruments.com/contact.
Page 5 temperature sensor silicone wire. Prevent temperatures higher than 200°C. Prevent high temperatures Keep the thermometer away from fluid. Keep the serial connector and sensor connector (PT100) Prevent away from water. Corrosion of the PT100 connector will water and moisture seriously influence the calibration. Keep sensor attached Keep sensor attached to thermometer.
Page 6: What Is What
What is what Connector temperature sensor Display Battery charge indicator Key: [Up] Key: [Down] Key: [Enter] Holster for PT-100 probe Foldable bracket to support upright use Charging Socket 5,0 x 2,1mm USB – “A” port female (for standard male type “A” connector) 7.1 Start Switch the thermometer on, press the enter Switch the thermometer off:...
Page 7: Menu Structure
7.2 Menu structure to step through menu Readout ↓ Switch Off ↓ Logging ↓ Clear Logs ↓ Sample time ↓ C,F,K,ADC ↓ Edit Date ↓ Edit Clock ↓ Battery ↓ Set Filter ↓ Baud Rate ↓ Readout If a menu item is selected and no key is pressed for six seconds, the reading will skip back to the temperature readout 7.2.1 Menu Item “Logging”...
Page 8: Menu Item "Sample Time
Pressing will now clear logs To safely skip: Do nothing and wait six seconds, you get back to the temperature reading Press to skip and the next menu item is visible It will take some time to erase the internal memory. The percentage clear memory is indicated incrementally.
Page 9: Menu Item "Edit Date
7.2.5 Menu Item “Edit Date” This will set the internal date from the real time clock Select with Press to set day and press to set month and press to set year and press Next menu item will be displayed 7.2.6 Menu Item “Edit Clock”...
Page 10: Menu Item "Set Filter
Replace the battery pack when after a full charge the thermometer can not be used for more than 8 hours Charging will take approximately 2 .. 2,5 hrs. When fully charged, the red charging LED will switch off 7.2.8 Menu Item “Set Filter“ The filter can be averaged using a mathematical moving average.
Page 11: Communication
Communication 8.1 Serial connect The Thermometer has a USB-A connector on the right side. Communication can be established when connecting thermometer to a PC or laptop using the USB connection. Standard a USB – A to A cable is supplied 8.2 Software Tamcom for Windows The thermometer can be connected to a Windows PC or laptop.
Page 12: Starting Tamcom
Thermometer detected on COM 5 8.4 Starting Tamcom When the thermometer is connected and the Tamcom software is started, it will automatically find the thermometer. Thermometer detected on COM 5 When detected, a list of measurements in memory is displayed. There are three options here: Clear memory (remove all) Select one of the measurements from memory.
Page 13: Zoom Function
8.4.3 Zoom function Use your right mouse button to select a specific part of the graph. Keep the button pressed and move button to the left or right. When released this part of the graph is zoomed in. Click the "bomb" icon to return to the full graph. Return from zoom Save data onto hard-disk Print data...
Page 14: Rs232 Commands
TT3 output is 29/03/23,0:52:20 &h32 39 2f 33 2f 32 36 2C 39 3A 35 32 3A 32 30 0D Leading zero’s are skipped in output from TT3 Tamson Instruments bv P.M. Tamson Instruments bv VAT: NL 80 66 34 984 B01 T.
Page 15 46 52 0A d0..d255 Read 256 byte flash page. nn = page address in decimal. data returned as 256 binary bytes, with no terminator. Note : if this command is used while logging is enabled, spurious results may be returned if the flash is busy with a write.
Page 16: Memory And Logging
10 Memory and logging 10.1 Memory The thermometer can save up to 16 sessions. A session can run until memory is full. The thermometer will stop logging data The session is ended when memory is full 10.2 Start logging temperature data A session can be started or stopped from the menu “Logging”...
Page 17: Change The Interval
10.3 Change the interval When logging with an one second interval this is 60 points per minutes 3.600 per hour 32.000/3.600 = 9 hours The table shows the total period available for logging using other sampling intervals Sample time Seconds hours of registration Clear memory with the menu option “Clear Logs”...
Page 18: Battery
10.4 Battery Charging the battery takes approximately two hrs. On a full charge the thermometer is capable to work sixteen hrs.* continuously. The thermometer can be connected permanently to the Battery sign, wall socket. However repeatedly cutting power will indicating low initiated forced charging and this may shorten the battery’s lifetime.
Page 19: Spare Parts List
11 Spare parts list Ordering code Image Description 10T6096 Works certificate -40 .. +150° 25T2310 PT100 24T0014 9V Adapter* 5,0x2,1mm 28T4189 Battery pack* 28T2039 USB A – A cable Tamson Instruments bv P.M. Tamson Instruments bv VAT: NL 80 66 34 984 B01 T.
Page 20: Dimensions
12 Dimensions Dimensions Remark Length [mm] Width [mm] Height [mm] Weight* 0.33 [kg] Power consumption Adapter 9V / 600mA Accuracy Resolution 0.001 [°C] Accuracy better than ±0.02 [°C] With calibration Linearity ±0.01 [°C] Temperature drift per year 0.001 [°C] per [°C] ambient 0.0005 [°C] Working condition (ambient)
Page 21: Trouble Shooting
13 Trouble shooting 13.1 Display shows strange characters Battery is below minimal operating voltage Recharge the battery. Display is dead Press enter Press Up Press down wait five seconds Press enter The thermometer starts up (2) Connect charger The unit will switch on, if not press 13.2 Communication via USB gives problems Baud rate incorrectly Use 57.600 for Tamcom...
Page 22: Ec Declaration Of Conformity Thermometer Tt3
14 EC DECLARATION OF CONFORMITY THERMOMETER TT3 Manufacturer: Tamson Instruments BV van 't Hoffstraat 12 2665 JL Bleiswijk The Netherlands Product: Thermometer Model: The products to which this statement relates, is manufactured and dully carried out in compliance with the provisions of Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility.
