200 0 W

D I GITAL

INVE RTE R

G EN ERAT OR

XTM2000DG

PLU 654248

IMPORTANT

PLEASE FILL SUMP WITH OIL

THIS 4 STROKE ENGINE DOES NOT CONTAIN ENGINE

OIL AND WILL NOT START UNTIL FILLED TO THE

CORRECT LEVEL

Oil type – 4 stroke fully synthetic motor oil, SAE 15W-40

(API SN Category). Oil Capacity - 400ml (Approximately)

Refer to page 8 and page 10 within the Instruction Manual for further details

CUSTOMER SERVICE: Mon - Fri 8.00am - 5.00pm (AEST)

Australia 1300 660 457 New Zealand 0800 474 876

04523 11/22

Table of Contents

Summary of Contents for XTM XTM2000DG

Page 1 (API SN Category). Oil Capacity - 400ml (Approximately) Refer to page 8 and page 10 within the Instruction Manual for further details CUSTOMER SERVICE: Mon - Fri 8.00am - 5.00pm (AEST) XTM2000DG Australia 1300 660 457 New Zealand 0800 474 876 PLU 654248...
Page 2: Table Of Contents
INTRODUCTION/GENERAL INFORMATION Secti o n P ag e Thank you for purchasing this generator which has passed Contents through our extensive quality assurance processes. Every Suggested Applications care has been taken to ensure that it reaches you in perfect Introduction condition.
Page 3: Warranty
LUBRI C AT I O N O F EN GIN E If a warranty fault appears within the warranty period, SMG reserves the right to replace or repair the product. Your engine comes with NO oil in the sump. You will need to In the event that SMG chooses to replace the product, add engine oil, refer to pages 8 and 10 for complete details this original warranty will expire at the original date.
Page 4 Wh at i s n o t c o ver ed any in-transit loss or damage. Assistance under the warranty will only be made available if the request is made to our • Commercial use of generator. customer service team on the contact numbers listed below •...
Page 5: Specific Safety Instructions
SPE CIF IC S A FE T Y I NST RU C TI ON S • Never operate the generator in damp, wet or flooded conditions. W A R NI NG ! • Before plugging appliances into the generator allow it to run up to full speed.
Page 6: Personal Safety
G EN E R A T O R ‘ EA R THI NG’ PER SONA L SA FETY Clot hing Always ensure that this generator is “Earthed” correctly before using. “Earthing” stake and wire has been supplied Do not wear loose clothing, jewellery or anything that could with this generator ensure it is used to ensure your safety, get caught in moving machinery.
Page 7 M AINTA I N Y O UR G ENER A TO R W ITH PRO TEC T POWER LEA DS FROM C AR E DAM AG E When not using your generator ensure the fuel cock is Always disconnect power cords from a power supply ‘OFF’.
Page 8: Electrical Information
I MP O R T AN T E LE CTRI C AL DA T A This generator is fitted with a sealed electrical connection socket that is compatible with the generator. If the electrical connection socket becomes damaged it must be replaced with a complete assembly that is identical to the original, and this must be replaced by an authorised service agent.
Page 9: Components & Controls
PIC. 1 SMART THROTTLE OUTPUT INDICATOR OVERLOAD ALARM LOW OIL ALARM RESET PUSH ON V AC V AC S PE C IFI C SA F E TY INSTR U C TI ON S 1. Low oil level indicator (yellow): this light is off when the 3.
Page 10: Operating Instructions
O PER A TI NG INST RU CTI ON S PIC. 2 U NPA CK I N G Carefully unpack your generator. This generator is heavy (20kg) and may require two (2) people to lift. Dispose of all packing material in an environmentally responsible manner. Oil Filler Cap Open carton, gently lift the generator clear of the carton and packaging, this may require 2 people.
Page 11 PIC. 5 PIC. 6 Earth Point G ENER A TOR ‘ E ARTHING’ Always ensure that this generator is “Earthed” BEFORE starting and using. PIC. 1. Ensure that engine is OFF when fitting the “Earth” stake and wire. 2. Attach the wire to the “Earth” point on the generator, see Pic.
Page 12 6. Hold down the generator firmly with one hand on the frame, then pull the recoil starter slowly until engaged, PIC. 9 then pull briskly, Pic. 9. This step may need to be repeated until generator engine starts, this can take up to about 12 pulls.
Page 13 U SIN G Y O UR G E NER ATO R PIC. 13 A C OU TLE T Your generator is equipped with a 230-240V AC power socket. This will run a range of devices providing they are within the limits of the generators output. NOTE: The peak (surge) power requirements of some devices e.g.
Page 14 U SIN G T HE AC O UTL E T PIC. 14 1. Check that the only illuminated light is the green output power. 2. Lift the flap and plug your appliance into the AC outlet socket on the face plate. 3.
Page 15 ST OR AG E DRA I NI NG THE FUEL TA NK If the generator is not to be used or is to be stored for more than one month the following storage procedure should be WAR NI NG! carried out. Drain all the fuel from the fuel tank (refer to Generator is heavy and may require 2 people page 18) and the carburettor (see below), ensure that all the to lift.
Page 16: Maintenance Chart
M AINTEN A NCE C HAR T Item Remark Pre-operation Initial 1 month or Every 3 month Every 6 month or Every 12 month check (daily) 6 hours or 12 hours 24 hours or 48 hours Check condition Spark plug Adjust gap and clean Replace if required Check oil level...
Page 17: Maintenance
MAI N TENANCE PIC. 16 C HE CKI N G/ CL E ANING THE AI R F I LT ER For proper performance and long life, keep air filters clean. 1. Remove access panel screws (2pcs) and then remove panel, note it is clipped in at the bottom 2.
Page 18 D R AINI NG E NG I NE OI L CLE ANI NG CLEANI NG TH E EXH AUS T PO RT & MUFFLER W A RN IN G ! Depending on the type of fuel used, the type and amount of oil used, and/or your operating conditions, the exhaust port Generator is heavy and may require 2 people to lift.
Page 19: Fault Chart
FAU L T CHART CORRECTIVE PROBABLE CAUSE CONDITION ACTION Fill sump with No Oil / Low Oil Level correct oil, See page 8 Loose Spark Plug Tighten Plug Loose Cylinder Insufficient Tighten Bolt Head Bolt Compression Damaged Gasket Replace Gasket FUEL SYSTEM PROBLEMS Insufficient Pulling Pull Recoil Quickly...
Page 20 F AUL T CHART CO NT IN U ED ACTION Trippedcircuit breaker Reset, refer page 14 Poor connection or faulty lead Check and repair Indicator light ON. No AC output Broken receptacle Faulty circuit breaker Consult Service Agent Indicator light OFF. Generator problem No AC output Output power too...
Page 21: Service Log
SER VI CE L O G This service is to be completed within 12 hours or 3 This service is to be completed within 24 hours or 6 months of purchase, which ever comes first. months of purchase, which ever comes first. REPLACE CHECK &...
Page 22 T his pag e has been left intentionall y blank...
Page 23: Specifications
S PEC I FIC A T I O NS Inverter generator................................XTM2000DG Engine type.............................Single cylinder, 4 stroke 78.5cc Engine speed................................3300-5100 r/min Oil tank capacity..................................400 mL Oil type..........4 STROKE FULLY SYNTHETIC MOTOR OIL, SAE 15W-40 (API SN CATEGORY) Fuel tank capacity..................................4.2L Fuel type............................Unleaded 91 Petrol - no ethanol Spark plug....................................A7RTC...
Page 24 Keep your purchase receipt, this will be required to make any claims under the 12 month warranty. Australia 1300 660 457 New Zealand 0800 474 876 XTM2000DG Manufactured in China for SUPER RETAIL GROUP LIMITED 6 Coulthards Ave, Strathpine. Queensland 4500, Australia...
