DS-TACHO-2

TECHNICAL REFERENCE MANUAL

DS-TACHO-2 V20-1

Table of Contents

Need help?

Do you have a question about the DS-TACHO-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for DEWESOFT DS-TACHO-2

Page 1 DS-TACHO-2 TECHNICAL REFERENCE MANUAL DS-TACHO-2 V20-1 1 ...
Page 2: Table Of Contents
9.2. General Safety Instructions 11 9.2.1. Environmental Considerations 11 9.2.2. Product End-of-Life Handling 11 9.2.3. System and Components Recycling 11 9.2.4. General safety and hazard warnings for all Dewesoft systems 12 10. Documentation version history 15 ...
Page 3: About This Document
Please read carefully! Hint It gives you a hint or provides additional information about a subject. Example Gives you an example of a specific subject. DS-TACHO-2 V20-1 3/15 ...
Page 4: Introduction
The sensor is housed in a threaded stainless-steel tube and supplied with a 90-degree mounting bracket and a 2.5 meter shielded cable. Common usage of the sensor is in a wide range of general purpose applications in relatively clean environments. DS-TACHO-2 V20-1 4/15 ...
Page 5: Specifications
Operating temperature 3-15VDC, 45mA Connector L1B7m connector for SIRIUS and DEWE-43 counter input Output signal Negative pulse input voltage (+V) to 0 Dimensions 74 mm length, 16mm diameter Cable length 2.5 meters DS-TACHO-2 V20-1 5/15 ...
Page 6: Operating Instructions
LED on-target indicator will blink at the input frequency rate when the sensor is properly aimed. NOTE : The green LED On-Target Indicator will blink on and off at slow speeds and remain on steady at high speeds. DS-TACHO-2 V20-1 6/15 ...
Page 7: Set Up In Dewesoft
DS-TACHO-2 TECHNICAL REFERENCE MANUAL 6. Set up in DEWESoft Connect the sensor to the counter input (ACC+, STG+, Multi, …) and enter the counter setup. Under the Basic application select Sensor (encoder, CDM, tacho…) mode. From the dropdown menu ...
Page 8: Measurement
7. Measurement Once the sensor is properly connected and defined in DEWESoft, it can be used for frequency measurements (for example: order tracking, balancing, basic RPM measurements, …). Example: in the order tracking setup you can directly select the tacho as a frequency channel. ...
Page 9: Warranty Information
8.2. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly. ...
Page 10: Printing History
When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo. ...
Page 11: Safety Instructions
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the product. Dewesoft GmbH assumes no liability for the customer’s failure to comply with these requirements. ...
Page 12: General Safety And Hazard Warnings For All Dewesoft Systems
REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to Dewesoft sales and service office for service and repair to ensure that safety features are maintained. ...
Page 13 This product has left the factory in safety-related flawlessness and in proper condition. In order to ● maintain this condition and guarantee safety use, the user has to consider the security advice and warnings in this manual. EN 61326-3-1:2008 DS-TACHO-2 V20-1 13/15 ...
Page 14 Devices and systems according to IEC 61508 or IEC 61511 which are considered as “operationally well-tried”, are excluded from the scope of IEC 61326-3-1. Fire-alarm and safety-alarm systems, intended for the protection of buildings, are excluded from the scope of IEC 61326-3-1. DS-TACHO-2 V20-1 14/15 ...
Page 15: Documentation Version History
DS-TACHO-2 TECHNICAL REFERENCE MANUAL 10. Documentation version history Revision Author Date Comment 1.0 DEWESoft d.o.o. 12/01/2018 Initial version DS-TACHO-2 V20-1 15/15 ...
