Summary of Contents for Atten ST-1509
- Page 1 ST-1509 User Manual...
- Page 3 Power cord Main host Soldering handle Iron stand Packing list: Main host + Soldering handle + Iron stand + Power cord + Manual...
- Page 4 ST-1509 150W T1.6A(230VAC) T3A(110VAC) 80℃~480℃/176℉~896℉...
- Page 5 (means:ST-1509 V0.1 version) 2.Enter standby mode standby (Default standby mode after 1 minute.) 3.Enter sleep mode (only after turning on the standby function) （Only when the standby function is on can it be used. By default, it will enter the sleep mode after 30 minutes.）...
- Page 8 5.Auto-standby function Under the STB menu, press "▲" and "▼" to set the standby parameters:Off/On Time:10~60 (default 1) minutes. the heater temperature is 150 ℃ under standby status. (diagram 1-14) open the auto standby function, and the standby time is 20 minutes. (diagram 1-15) turn off the auto standby function .
- Page 9 Under the H-L menu, press “▲”and “▼” button to set the upper lower temperature values and OFF. (diagram 1-19) It will alarm if upper temperature more than 20℃(68℉) and the lower temperature less than -20℃(68℉). (diagram 1-20) alarm function is OFF. The upper and lower temperature rang is 20℃...
- Page 10 E02:Sensor alarm(diagram 1-25) E03:Zero-cross detection abnormal alarm(diagram 1-26) E04:Abnormal temperature alarm E05:over-current protection E07:Short circuit of sensor E08:Abnormal soldering tip temperature E09:The soldering pen has been removed...
- Page 11 Product specification and model Y9150 N9100 Y9130 Model Y950 Voltage Power consumption Temperature range Cable material Heat-resisting silica gel Type of Integrated heating element heating core Temperature Thermocouple sensor Model of Y9150 Y950 Y9130 N9100 heating core series series series series Note: Replacing the handle or heater may cause temperature inaccurate, if the temperature is inaccurate, we suggest use the temperature...
- Page 12 Replacement of Heating Core of Y950 Handle Putting the handle into the stand slot to pull its integrated heater out, then put the integated heater in the hole of stand. Replacement of Heating Core of Y9130 and Y9150 Handles Putting the handle into the stand slot to pull its integrated heater out, then put the integated heater in the hole of stand.
- Page 13 Specification and model of integrated heating element Y950 series Beveled solder tip (type C) Figure Model T950-1.2C Figure Model Chisel solder tip (type D) T950-1.3D T950-2.2D T950-3.0D Cone solder tip (type I) Figure Model T950-0.5I Knife-shaped solder tip (type K) Figure Model T950-K...
- Page 14 Model Figure Chisel solder tip (type D) T9130-1.6D T9130-2.4D T9130-3.2D T9130-4.6D Cone solder tip (type I) Figure Model T9130-0.5I T9130-1.0I Knife-shaped solder tip (type K) Model Figure T9130-K Y9150 series Beveled solder tip (type C) Figure Model T9150-3C T9150-5C T9150-6.5C Chisel solder tip (type D) Figure Model...
- Page 15 CBN033049(B)
