363GB-12 (18, 24, 36, 42)
ADA Grab Bar Series
Operation & Maintenance Manual
Model Numbers
☐
363GB-12
12" Grab Bar for ADA Applications
☐
363GB-18
18" Grab Bar for ADA Applications
☐
363GB-24
24" Grab Bar for ADA Applications
☐
363GB-36
36" Grab Bar for ADA Applications
☐
363GB-42
42" Grab Bar for ADA Applications
Finish Options
☐
-STN
Satin Nickel finish
Note: Append appropriate -suffix to model number.
Dimensions
D D
FINISHED WALL
FINISHED WALL
Note: Dimensions subject to change without notice.
Duro
A A
B B
C C
E E
®
Specification
•
Supports up to 250 lbs.
•
1-1/2" bar diameter
•
3" flange diameter
•
Bar extends 1-1/2" from wall
•
Concealed mounting for a clean look
•
Meets WW-P-541/8B Federal Specification for
Manufacturing
•
Meets ADA load requirements when properly installed
•
Stainless steel construction
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
F F
G G
Measurements
A
1-1/2", 38 mm
13-1/4", 337 mm (363GB-12)
19-1/4", 489 mm (363GB-18)
B
25-1/4", 641 mm (363GB-24)
37-1/4", 946 mm (363GB-36)
43-1/4", 1099 mm (363GB-42)
12", 305 mm (363GB-12)
18", 457 mm (363GB-18)
C
24", 610 mm (363GB-24)
36", 914 mm (363GB-36)
42", 1067 mm (363GB-42)
D
Ø 1-1/2", 38 mm
E
(2x) Sq. 3-1/16", 78 mm
F
3-1/16", 78 mm
G
1/2", 13 mm
