FACEMI WALRUS AUDIO MIRA Manual

WALRUS AUDIO MIRA (Optical Compressor)
Item: 63611
•
• EAN: 810424034334
Packaging dimensions: 14.6 x 10.7 x 6.4 cm
•
Weight: 0.44 kg
•
Pictures | Translations
•
Need to know for Retailers
Studio-grade Optical Compressor
•
Lots of sustain with smooth attack
•
Extensive controls normally only found on studio units
•
Make-Up control to maintain unity levels after signal has been compressed
•
Blend control allows user to mix dry and affected signal
•
High Pass filter in the side-chain preventing bass frequencies 120Hz or below from engaging the
•
compressor as much as high frequencies.
Full Feature List
Studio-grade Optical Compressor
•
Controls: Threshold, Ratio, Make-up, Level, Attack, Release, Blend, Side-Chain High-Pass Filter, Bypass
•
Warm, analog optical compression with loads of sustain
•
• Extensive controls normally only found on studio units
Threshold sets volume-point at which the compressor starts to engage
•
Adjustable Ratio from 1:1 to 20:1
•
Make-up control to maintain unity level after signal has been compressed
•
• Level knobs sets overall output
Smooth attack and release
•
Blend control to mix dry and affected signal
•
Switchable 120 Hz High Pass filter in side-chain
•
• Great for Bass Guitar due to HPF- and Blend-feature
Runs internally at ±15VDC for higher headroom
•
Gain reduction LED illuminates when compression is applied
•
Top mounted Input & Output
•
True Bypass design
•
9-volt DC, Center Negative, 200mA minimum
•
Power Supply not included
•
Smoky grey die-cast enclosure with Cream, Orange, Red, and Dark Blue ink
•
Made in the USA
•
