Summary of Contents for EV-PEAK UD2
- Page 1 Instruction Manual Support LiPo/LiHv/Smart battery Shenzhen EV-PEAK New Energy Technology Co.,Ltd. Phone： +86(755)88848076 Email： www.ev-peak.com...
- Page 2 Preface Thank you for choosing EV-PEAK’ s smart fast charger; this operating instruction is designed to help you better install and use this product, so please read this instruction carefully before using it, and keep it in a safe place. The safety items mentioned in this manual are only a supplement to local safety regulations.
- Page 3 Part Name LED指示灯1.2.3 Wireless Charger Charge/Storage Button ON/OFF MICRO_USB 升级接口 Cooling Fan AC Input Balance Port Charing Port Indicator light description Fast charge mode White light is always on Medium charge mode Red light is always on Slow charge mode Yellow light is always on Product specification AC input Voltage...
- Page 4 Screen display instructions Charging status indicator arrow Automatic identification of working channels Battery percentage Charging time display Program error warning Bluetooth display input voltage display Error code display Temperature disp Cycle times display Battery type display Maintenance status indicator arrow Current and voltage display 1.In the error state - no current display.
- Page 5 Operation introduction Long press the "main switch key" to turn on/off Short press after power on to switch between fast charge/regular/slow charge mode The current mode can be viewed through the LED indicator Please refer to page 2 for LED indicator notes Long press the "charge button"...
- Page 6 1. UD2 battery connection schematic diagram, the battery can be connected to the charger, if the battery socket does not match, the battery can be connected through the transfer line. AS150U interface x4 MX3.0 balanced 2. First connect the power cord to the AC input port, and the other end to the AC power supply (100-240V, 50/60Hz),...
- Page 7 If the firmware of the charger needs to be updated, please pay attention to the firmware upgrade program that will be released on the EV-PEAK official website, and perform the firmware upgrade according to the following steps: 1.Visit EV-PEAK official website to download the latest firmware upgrade program(http://www.ev-peak.com/firmware) 2.Connect the charger, and use the USB cable to connect the firmware upgrade interface to the computer.
- Page 8 Package contains This product includes: UD2 smart balance charger x1 AC power cord x1 remote control software download link x1 after-sales service card x1 UD2- Smart Balance Charger AC power cord Remote control software After-sales service card After sales and warranty Thank you for purchasing the charger from our company.
