Summary of Contents for Foton Accessories Varanus
-
Page 2: Table Of Contents
The magical world of time-lapse will become more accessible to you. Owing to advanced algorithms, registration of dynamic time-lapse photos will be possible without complex calculations. We believe that your work with Varanus will give you unforgettable ex- periences, Foton Accessories Team... -
Page 3: Introduction
Introduction The presented multifunctional device is employed to make very smooth shots in motion, in all planes, in a constant mode (Video) or step mode (Time-lapse). The set is mounted on the Kameleon sliders (64, 94, 130 or 200 cm long). The driver precisely regulates the work of one or two motors, with the possibility of developing pictures. -
Page 4: Basic Functions
Stronger belt tension can only be used when working vertically. In that position you should increase the power to the value of 50 in Power Motor settings and possibly increase engine speed with the Speed knob. DC voltage supply must not be higher than 12 V. Exceeding this parameter will cause damage to the controller. -
Page 5: Drives Assembly
(Reset Menu) – resetting the menu. • (Save menu) – save individual settings in 10 memory banks (0-9). • Messages depending on the chosen function: (Go back?) – when engines are running, click [OK], then [M] – it gives the ability to •... - Page 6 5. Tighten the belt at the side regulated by its tension and do 1-2 turns with the knob so that the belt is not too tight. 6. In order to mount the panoramic drive, first mount the adapter with the distance case on the trolley plate with the inner 3/8’’...
- Page 7 8. If necessary, a controller holder or a monitor may be mounted: a) under the slider foot, b) by attaching to the plate with an internal ¼’’ or 3/8’’ thread under the slider. 9. Next, place the battery in the adapter with the power 10.
-
Page 8: Basic Functions Of Driver Buttons
Basic functions of controller buttons All device functions are controlled by two knobs and four buttons: [M], [OK], [+], [–]. Long press (hold) - change the motor A to B. Motor A (trolley slider) is the primary • motor. Short press (click) – go into/out of Menu (you can only go into the Menu when •... - Page 9 Manual track programming (for Video mode and Time-lapse) HOLD ≥ 1 sec. The easiest way to set the drive path is manually in the setting (see navigation scheme on the cover of this manual). When the route is not a programmed route “OK”...
-
Page 10: Detailed Description Of Work Modes
A detailed description of work modes Video Mode This mode is used to drive a camera in two directions and rotate the head in the panorama plane, with the function of smooth acceleration and deceleration of the motors. Driving can be automatic - the manually programmed memorized path between two points, or manual –... -
Page 11: Detailed Description Of Current Settings - Menu
(option “Go back?” - described above) and increase the pause parame- ter. Important! In the Time-lapse mode, exposure time (Exposure) in Varanus should be equal to or longer than in the camera. For shutter speed 1/10 or less, controller should be set at 0,100 s. In case of longer exposures, values set in controller and camera should be similar. - Page 12 the trolley is in the starting position. Pressing OK on the main screen will start driving. You can also edit the turn angle of the head in the horizontal plane with “RotationB: deg” option. RotationB – the angle to be turned by motor B in the panorama plane, measured in degrees.
-
Page 13: Available Options Of Advanced Settings - Settings
– a gradual acceleration / deceleration of the motor (1-15). Ramp It introduces softer and longer acceleration or braking. At every motor speed set, that time is proportionally corrected. – editing speed of the motors. The minimum value is 1, maximum 20. Turning Speed the potentiometer changes the value of speed. -
Page 14: Technical Specification
Technical Specification Min. speed in Video mode, horizontal movement: 0,12 mm/s Max. speed in Video mode, horizontal movement: 90 mm/s Min. rotation in Video mode, horizontal movement: 14 s Max. rotation in Video mode, horizontal movement: 320 s Max. load of the trolley, horizontal movement: 6 kg Max. - Page 15 SV-2 – double drive set (slide&pan), for Kameleon sliders Components: 1. Battery Adapter with a power cord. 2. Battery Charger for Sony NP-Fxxx (or equivalent). 3. AC Adapter 230/12 V. 4. Controller with the battery holder and battery adapter. 5. The movement motor (Slide). 6.
-
Page 16: Recommended Accessories
Components: 1. Battery Adapter with a power cord. 2. Battery Charger for Sony NP-Fxxx (or equivalent). 3. AC Adapter 230/12 V. 4. Controller with the battery holder and battery adapter. 5. Regulated tripod holder, for the controller or monitor (assembled on 5 ÷... - Page 17 KWCL-S1 - for Sony: Digi DSLR-A900, DSLR-A850, DSLR-A700, DSLR-A580, DSLR-A560, DSLR-A- 550, DSLR-A450, DSLR-A350, DSLR-A300, DSLR-A200, DSLR-A100, SLT-A99, SLT-A77 II, SLT-A77, SLT-A65, SLT-58, SLT-A57, SLT-A55, SLT-A37, SLT-A35, SLT-A33; Konica Minolta: Maxxum / Dynax / Alpha 7D, 5D; Dimage: A2, A1, 7Hi, 7i, 7, 5; KWCL-S2 - for Sony with socket Multi Terminal: A7, A7R, A7S, A58, A3000, A5000, A5100, A6000, RX10, RX100 II, RX100 III, HX300, HX50V, HX60V, NEX-3NL.
-
Page 18: Work Safety
13. Shutter release cord extension 14. Signal cords extensions for Drives 12. 360° Turntable for packshot (1,8 m) – symbol K22 – symbols: K23 (3 m) i K24 (6 m) photography, 50 cm – symbol: SVTZ ⌀ 16. A small bag (for SV1 set) 17. -
Page 19: Maintenance And Cleaning
The warranty is also invalid in the case of flooding, moisture, unauthorized attempts to repair and modification of mechanical damage incurred during transport or operation. The warranty service is Foton Accessories headquarters – Kalisz, Poland. We wish you a pleasant use! Foton Accessories Team...
