KneeRover Fusion All Terrain User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
KneeRover® Fusion All Terrain
User Manual

Advertisement

loading

Related Manuals for KneeRover Fusion All Terrain

Summary of Contents for KneeRover Fusion All Terrain

  • Page 1 KneeRover® Fusion All Terrain User Manual...

  • Page 2: Ongoing Maintenance

    We recommend saving the tools that are provided with your KneeRover® product, as you may need them to provide ongoing maintenance. With rou- tine use, nuts and bolts on the KneeRover® knee walker can become loose. To ensure safe operation of your KneeRover® scooter, it is important to period- ically inspect for loose nuts and bolts and re-tighten as appropriate.
  • Page 3 KneeRover® Fusion All Terrain - Tools & Parts List: The following tools and parts are included with your KneeRover® Fusion. Please follow assembly instructions for your specific KneeRover® model, using the tools and parts provided. Assembly videos for your KneeRover® model can also be found at: https://kneerover.com/pages/assembly-video...
  • Page 4 KneeRover® Fusion All Terrain Set Up Instructions: Please follow the step by step instructions on the following pages to properly assemble your KneeRover® scooter. The diagram below identifies the key components of the scooter to aid with assembly. Visit https://kneerover.com/pages/assembly-video for assembly videos.
  • Page 5 Step 1: Install Front Axle Please take your time to carefully complete all steps before operating your new KneeRover® scooter. First, place the front axle with 12” wheels under the scooter frame, ensuring the round bolts by the wheels are facing up. Align the axle and frame holes, insert front axle bolts and tighten completely using the allen wrench provided.
  • Page 6 Step 3: Install Steering Column Raise the steering column up by pushing the clamp lever to the left allowing the column to raise all the way up (Left Photo). Raise the clamp lever upward in to the “U” slot and tighten by turning it clockwise (Right Photo). Finally, push clamp lever down firmly to secure the steering column.
  • Page 7 Step 4: Handle Bar Assembly Please make sure the brake line is not twisted and the brake handle is facing forward. Insert the handle bar into the steering column (Left Photo). Raise the handle bar to a comfortable position and insert the height adjustment knob into the hole and tighten (Right Photo).
  • Page 8 Step 5: Assemble and Install Offset Knee Platform The knee platform is designed to be used with the right or left leg. It is very important that the knee platform is set up for the proper leg as this offset is designed to help the rear wheels stay free from the pushing leg during use.
  • Page 9 Step 6: Install the Fusion Cover Starting with the right side cover, place the cover over the rear axle (Top Left Photo) and feed the brake cable into the rear of the cover. Place the front of brake cable between the steering column and the steering bracket (Top Right Photo).
  • Page 10 Brake and Parking Brake Operation Your KneeRover® knee walker comes equipped with a brake lock/parking brake. To engage the brake, squeeze the brake lever on the handle bar. To apply the parking brake, squeeze brake handle firmly and while holding the brake handle press the silver button to engage the lock.

  • Page 11: Warranty

    What is Covered? While the frame is covered for the life of the KneeRover®, some parts of the scooter are subject to normal wear and tear and depending on the use, may not last the lifetime of the scooter. The applicable warranty coverage for all parts are listed below.
  • Page 12 KneeRover® Knee Walker Safety Instructions: The following safety instructions and warnings are provided to educate the user on how to safely operate a knee walker. Knee Walkers are mobility devices designed to provide increased mobility during recover from foot/ankle/lower leg surgery or injury.
  • Page 13 Only use accessories and replacement parts authorized by the KneeRover® brand. Accessories designed by other manufacturers have not been tested by KneeRover® and are not recommended for use with KneeRover® products. As a reminder, this is a mobility / walking aid, not a recreational device.
  • Page 14 SAFETY INSTRUCTIONS FOR OPERATING KNEE WALKER: As with any new physical activity, practice and common sense are necessary for successful use of the knee walker. Before operating the knee walker at normal walking speed, practice maneuvering and making turns at slow rates of speed to get familiar with the knee walker and how to best maintain balance.
  • Page 15 DO NOT operate on inclines above 15 degrees (slight incline). Use Extreme Caution when operating the knee walker on any slopes, as there is risk of losing balance. It is best to avoid slopes. Only mount or dismount your knee walker on a level surface. DO NOT attempt to reach for objects while the knee walker is in motion.
  • Page 16 Amazon or eBay, we would greatly appreciate a review once you’ve had a chance to use your new KneeRover® scooter. We hope we’ve earned a 4 or 5 star review - if not, please give us the opportunity to help you before leaving a review.
