- Page 1 Freezer - Fridge / User Manual RFF334SL...
- Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................8 1.3 Electrical information (For UK type plug) ................8 1.4 During Usage........................9 2 DESCRIPTION OF THE APPLIANCE ............11 2.1 Dimensions ........................12 3 USING THE APPLIANCE ................13 3.1 Information on Less Frost Technology ................13 3.2 Thermostat Setting .......................13 3.3 Temperature Settings Warnings ...................13... -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 5 natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
- Page 6 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 7 To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...
-
Page 8: Installation Warnings
1.2 Installation warnings • Clearance of at least 150 mm is required at the top of your appliance. Do not place Before using your fridge freezer for the first anything on top of your appliance. time, please pay attention to the following •... -
Page 9: During Usage
• Do not re-freeze thawed frozen food. This may cause health issues such as food poisoning. Old and Out-of-order Fridges • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. - Page 10 Notes: • Please read the instruction manual carefully before installing and using your appliance. We are not responsible for the damage occurred due to misuse. • Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to resolve the problems that may occur in the future.
-
Page 11: Description Of The Appliance
2 DESCRIPTION OF THE APPLIANCE This appliance is not intended to be used as a built-in appliance. Lamp cover Thermostat knob A) Refrigerator compartment B) Freezer compartment 1) Turbo fan * 2) Wine rack * 3) Refrigerator shelves 4) Chiller * 5) Crisper cover 6) Crisper 7) Freezer room cover * / Upper drawer... -
Page 12: Dimensions
2.1 Dimensions Overall dimensions 1860 the height, width and depth of the appliance without the handle. Overall space required in use 981,6 Space required in use 1243,5 2010 the height, width and depth of the appliance including the handle, plus the space necessary for free 744,1 circulation of the cooling air, plus the height, width and depth of the... -
Page 13: Using The Appliance
3 USING THE APPLIANCE the refrigerator compartment. If required, change the temperature setting. • It is not recommended that you operate 3.1 Information on Less Frost your fridge in environments colder than Technology 10°C in terms of its efficiency. Thanks to the wrap around evaporator, •... -
Page 14: Accessories
SN (extended temperate): This 3.4.3 The Freezer Box refrigerating appliance is intended to be The freezer box allows food to be accessed used at ambient temperatures ranging from more easily. 10 °C to 32 °C. The Turbo Fan (if available) Do not block the air inlet and outlet openings when storing food, otherwise air circulation provided by the turbo fan will be... -
Page 15: The Chiller Shelf (In Some Models)
3.4.4 The Chiller Shelf (In some models) humidity rate to be controlled, to increase the life of food within. The dial, located behind the shelf, must be opened if any condensation is seen on the glass shelf. 3.4.6 Adjustable Door Shelf (In some models) Six different height adjustments can be made to provide storage areas that you... -
Page 16: Food Storage
4 FOOD STORAGE products and clean any leakages on the shelves. • Do not put food in front of the air flow 4.1 Refrigerator Compartment passage. • To reduce humidity and avoid the • Consume packaged foods before the consequent formation of frost, always recommended expiry date. -
Page 17: Freezer Compartment
temperature and that the contents have Maximum How and where to Food deteriorated. storage time store • The storage life of frozen food depends Bottled Until the on the room temperature, the thermostat products expiry date On the designated e.g. milk recommended setting, how often the door is opened, door shelf... - Page 18 The table below is a quick guide to show you the most efficient way to store the major food groups in your freezer compartment. Maximum storage time Meat and fish Preparation (months) Steak Wrap in foil 6 - 8 Lamb meat Wrap in foil 6 - 8 Veal roast...
-
Page 19: Cleaning And Maintenance
Maximum storage time Vegetables and Fruits Preparation (months) Strawberry and Wash and hull 8 - 12 Blackberry Cooked fruits Add 10 % of sugar to the container Plum, cherry, sourberry Wash and hull the stems 8 - 12 Maximum storage time Thawing time at room Thawing time in oven (months) -
Page 20: Defrosting
5.1 Defrosting process. Remove all dislodged frost from the cabinet floor. It is not necessary to Defrosting the Refrigerator switch off the appliance for the removal Compartment of thin frost. • For the removal of heavy ice deposits, disconnect the appliance from the mains supply, empty the contents into cardboard boxes and wrap in thick blankets or layers of paper to keep cool. -
Page 21: Shipment And Repositioning
6 SHIPMENT AND • After defrosting is complete, clean the inside of the appliance with a solution REPOSITIONING of warm water and a little bicarbonate of soda, then dry thoroughly. Wash all 6.1 Transportation and Changing removable parts in the same way and Positioning reassemble. -
Page 22: Before Calling After-Sales Service
7 BEFORE CALLING AFTER- may cause more noise for a short time when it is first activated. SALES SERVICE Bubbling noise and splashing occurs: Due to the flow of the If your refrigerator is not working properly, there may be a minor problem. Check the refrigerant in the tubes of the system. -
Page 23: Tips For Saving Energy
8 TIPS FOR SAVING ENERGY 9 TECHNICAL DATA 1. Install the appliance in a cool, well- The technical information is situated in ventilated room, but not in direct sunlight the rating plate on the internal side of the and not near a heat source (such as a appliance and on the energy label. -
Page 24: Information For Test Institutes
7 or 10 years, based on the type of component, from the placing on the market of the last unit of the model. Visit our website to: Republic of Ireland & Northern Ireland www.nordmende.ie Great Britain www.nordmende.co EN - 24... - Page 25 EN - 25...
- Page 26 EN - 26...
- Page 27 EN - 27...
- Page 28 52335328...
