This manual contains important information concerning the
installation and operation of the crusher listed above.
Read manual thoroughly and keep for future reference
INSTRUCTIONS
2760 Ridgeway Court
800-444-4351
Made in the USA
Page 1 of 8
Model: HCR2
Walled Lake, MI 48390-1662 USA
Fax 248 960-7109
e-mail: info@herkules.us
Part# 1002442-03
05/08/07
Advertisement
Table of Contents
Related Manuals for HERKULES HCR2
Summary of Contents for HERKULES HCR2
- Page 1 Part# 1002442-03 05/08/07 Model: HCR2 This manual contains important information concerning the installation and operation of the crusher listed above. Read manual thoroughly and keep for future reference INSTRUCTIONS Herkules Equipment Corporation 2760 Ridgeway Court Walled Lake, MI 48390-1662 USA...
-
Page 2: Table Of Contents
Serial Number PATENT NUMBERS Model Number This product has patent protection under one or more of the following patent numbers: 7070167, 5485860, 5193561, 5174317 Purchase Date 4960142, 4793369, 1299468 and Patents Pending website: www.herkules.us 1002742 Distributor Page 2 of 8... -
Page 3: Warnings
FAILURE TO HEED THE FOLLOWING WARNINGS MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE. Herkules will not be held responsible for any personal injury and/or property damaged caused due to owner/operator failure to follow the warnings and cautions listed in this manual. -
Page 4: Model Information (List Of Models With Descriptions And Data)
Total weight 275 Ibs. DESCRIPTION Model HCR2 is a production crusher capable of crushing four 1-gallon cans or seven 1-quart cans or one 5-gallon can. The crusher provides the following features: • Powerful 3.75 ton cylinder crushing plate assures the force necessary to do the job when crushing up to 7 quart cans. -
Page 5: Installation
Figure 1 INSTALLATION See Figure (1). Install the crusher as follows. A. The HCR2 should be set on a sturdy bench or table strong enough to support its weight. We recommend that the unit be lagged or bolted down. B. Connect the supplied pressure regulator/filter and oiler assembly to the 3/8"... -
Page 6: Inspection
INSPECTION Prior to operation a visual Inspection shall be made. Check crusher for leaks, worn or missing parts. Periodically check oil level in oiler. DO NOT RUN WITHOUT OIL. Any crusher that appears to be damaged in any way, is badly worn or operates abnormally shall be removed from use until repairs are made. -
Page 7: Maintenance
Apply motor oil to door latch pivot points on a regular basis to prevent latch from binding. REPAIR No service parts are available for this can crusher. Special tools and procedures are required for repair. If repair is required, contact Herkules Equipment Corporation Customer Service, (800-444-4351) for your nearest authorized service center. Cylinder... - Page 8 SERVICE PARTS Cylinder #008-604 Pilot Valve #10060 Ram Plate #10055 Crusher Chamber #12036 Page 8 of 8...
