- Page 1 S SERIES CLEAN BENCH Models：VS-840K、VS-840K-U、VS-1300L、VS-1300L-U HS-840、HS-840-U、HS-1300、HS-1300-U OPERATION, MAINTENANCE & SERVICE INSTRUCTION...
-
Page 2: Table Of Contents
FOREWORD We are grateful for you to be our customer sincerely and believe this product will improve your technical environment, and will have good effect on improving the products quality. Please read the instruction to understand this product well in order to make this product run most effectively. - Page 4 Spare Parts HS-840 / 840-U 1 piece VS-840K / 840K-U Pre-filter HS-1300 / 1300-U 2 piece VS-1300L /1300L-U SUZHOU ANTAI AIRTECH CO. LTD NO. 2 WEIXIN RD. SUZHOU INDUSTRIAL PARK SUZHOU, P. R. CHINA 215122 HOT LINE: 0512-65315246 FAX: 0512-62793212 S-1512-⑥EN...
-
Page 5: Product Intro & Precautions
1. PRODUCT INTRO & PRECAUTIONS ⑴. Characteristics: S Series Clean Bench （ herein after briefly called Clean Bench ） is a kind of general-purpose air purifying equipment that provides local high cleanliness work environment. It is mainly used in medical institutions, and also industries and scientific laboratories such as electron, national defense, precision instrument &... - Page 6 ◆ Electrical Safety Precautions: Please locate the product on its place before wiring and power on. Make sure the rated voltage and frequency of the product conform with the input power specifications to avoid damaging the electric units and causing fire. This product must be reliable grounding to ensure its safe use.
-
Page 7: Specifications
◆ Description of Label: ● Company Logo of SUZHOU ANTAI AIRTECH Co. Ltd Caution Label ● Pay attention to dangers that might happened during operation ● Pay attention to the electric components inside. 2. SPECIFICATIONS Model VS-840K HS-840 VS-1300L HS-1300... -
Page 8: Structure Characteristic
3. STRUCTURE CHARACTERISTIC As shown in Fig.1 & 2, the clean bench consists of the body case, HEPA filter, air supply fan unit, working table and control panel etc. The body of the case is made of thin steel plate and its surface is sprayed with lacquer. 1. -
Page 9: Work Principle
The clean bench uses fan with variable air volume system, by switching the fan speed to keep the average air velocity in ideal range; therefore prolong the service life of HEPA filter. 4. WORK PRINCIPLE The flow type of the Series VS Clean Bench is vertical laminar flow, and Series HS Clean Bench adopts the horizontal laminar flow type. -
Page 10: Operation
6. OPERATION ⑴ Setting of Control Panel: Air Velocity Indicator Air Velocity Indicator Fan Button (with light) Fan Button (with light) Light Button (with light) Light/Sterilizing Button (With light) FIG.3： SCHEMATIC OF CONTROL PANEL As shown in the Fig 3, there are buttons on the panel: Fan Button (with light), Light Button (with light), Light/Sterilizing Button (with light), and LED Air... - Page 11 ◆ Press repeatedly may operate the on/off of fluo. light. Press Press ◆ Press repeatedly may operate the on/off of fluo. light and UV light. Press Press Press ⑵ Operation: Before Leaving factory, fan has been set in “STD” mode. ◆...
- Page 12 ◆ Normal Operation: During normal operation, press the Light/Sterilizing Button to turn on the light and keep the fan running at medium speed (STD mode). User also can switch the fan speed to high speed or low speed by pressing Fan Button repeatedly as per need.
-
Page 13: Troubleshooting
7. TROUBLESHOOTING Problem Cause Remedy ⑴. No power connection. ⑴. Connect to the power supply reliably. Inoperative buttons on ⑵ . Faulty circuit board or ⑵ Check the wiring and fuse or replace control panel control panel. the faulty one if necessary. ⑴. -
Page 14: Maintenance
3.Frame of Pre-filter FIG.4：SCHEMATIC DIAGRAM OF PRE-FILTER REPLACEMENT OF S SERIES CLEAN BENCH 2) In general, once every two months, test the air velocity in the working area by Hot-bulb anemometer. If air velocity is not in conformity with the requirements of specifications, switch the Fan to high speed state. - Page 15 While installation, open the back cover of the case of Series HS Clean Bench as shown in Fig.5, open the top cover of the case of Series VS Clean Bench as shown in Fig 6. The arrow mark on HEPA filter must be the same as the airflow direction of the air outlet.
-
Page 16: Attached Drawings
20W×② 30W×① 30W×② 4-65W× V1-2 Starter 4-40W×① 4-40W×② 4-65W×① 4-65W×② ② EL1-2 Fluo. Light 18W×① 18W×② 18W×① 30W×① 30W×② 30W×① UV Light 20W×① 30W×① Boat Switch R221-22C-18A×① Elec. Wire RVV-3×0.75×① with Plug FIG.7： ELECTRICAL DIAGRAM OF S SERIES CLEAN BENCH...
