- Page 1 Flap Turnstile Operation Manual 30E USER MANUAL Ravel Movement Control Pvt. Ltd.150-A, Electronics Industrial Estate, Perungudi, Chennai – 600 096. Phone: +91 44 2496 1004 Email: info@ravelmovement.com...
-
Page 2: Dear Customer
Dear Customer! Thank you for choosing our Intelligent brushless Retractable Flap Barrier RMC-PRS-56E-PUN. Please follow the instructions given in the Manual carefully, and this quality product will provide many years of trouble-free use. Assembly and Operation Manual (hereinafter-the Manual) for the Retractable... -
Page 3: Warranty
Retractable Flap Barrier Operation Manual The product is equipped with sophisticated technology. To ensure a safe and reliable operation and to ensure the safety operation, the operation manual is provided with special precautions for the operation of the system. It is recommended that the user read carefully the operation manual prior to application of the equipment, otherwise, your right may be infringed due to an improper application of the equipment. -
Page 4: Safety Notes
Retractable Flap Barrier Operation Manual The electrical power used in this equipment is at a voltage high enough to endanger life. Before carrying out maintenance or repair, you must ensure that the equipment is isolated from the electrical supply and tests made to verify that the isolation is complete. -
Page 5: Installation Safety Requirements
Retractable Flap Barrier Operation Manual electric characteristic, otherwise, damage to the equipment and other equipment of the user may be resulted. ◼ The equipment is not equipped with explosion-proof design, and it is not allowed to apply the equipment to an environment with danger of inflammable or explosion. -
Page 6: Product Description
Retractable Flap Barrier Operation Manual 4. Product Description 1. Standard Feature & Function Specifications ◼ Fast identity authentication technology to accurately and efficiently identify IC cards, ID cards, magnetic cards or barcode cards. ◼ DC brushless motor is maintenance-free and new digital positioning. ◼... - Page 7 Retractable Flap Barrier Operation Manual output interfaces, which facilitates integration of the system with other devices. ◼ Remote control and management is available. ◼ Super combination ability, different styles, series channel products can be combined without affecting system performance. ◼ Powerful system capacity expansion, new products can be added at any time.
-
Page 8: Specifications
Retractable Flap Barrier Operation Manual 4.2 Customized Features & Functions ◼ Alternative Materials, Finishes and Custom Design ◼ Usage Counter function ◼ Remote-Controlled Button ◼ Access Control,Biometrics System Integration 4.3 Specifications ◼ Framework: 304# Stainless Steel (default),201# or 316# (optional) ◼... - Page 9 Retractable Flap Barrier Operation Manual flush mounted, or rack mounted. There is an output to interlock the read facilities. 5 Equipment Definition 1. Term Definition of Entry & Exit Entry: the direction way passing through the barrier passage from outside the control area and into the area controlled by the product.
- Page 10 Retractable Flap Barrier Operation Manual Fig. 1 The dimensions of Retractable Flap Barrier...
-
Page 11: Installation Details
Retractable Flap Barrier Operation Manual Equipment Assembly Installation Instruction 1. Installation Details Caution! Follow the safety requirements during the installation (see clause 3) Correct turnstile installation provides its functionality and lifetime. Please carefully study and follow the installation instructions. Caution! The manufacturer shall not be liable for any damage caused as the result of improper installation and declines any claims arising thereof in case if the installation is not done in compliance with the instructions provided in this... - Page 12 Retractable Flap Barrier Operation Manual tube, and bury them to the corresponding positions with concrete; Move each cabinet to the respective installation position, and align with each ground screw bolt; Fig. 2 Ground Foot Installation Foundation Diagram Notes: (1). AC220V power supply line pipe: use RVV3*1.0 power supply cable. Check the system composition and operation mode, and carry out the next operation after confirming the above check;...
- Page 13 Retractable Flap Barrier Operation Manual (10). After a certified check of status and function adjustment, fasten the ground screw nuts. 6.3 Equipment composition and basic working principle 6. 3. 1 product structure The product structure is mainly composed of two parts: mechanical system and electronic control system;...
- Page 14 Retractable Flap Barrier Operation Manual from the same direction; ● Sound and light alarm device: send an alarm prompt signal to illegal traffic personnel; ● Limit switch: the position at which the gate is controlled to rotate; ● Voice version: make corresponding voice prompts according to the instructions issued by the main control board;...
- Page 15 Retractable Flap Barrier Operation Manual continuously sends a signal to the main control board until the pedestrian completely passes the channel; the main control board sends a letter to the counter. No., the counter will automatically add 1, complete the pass. 4) If the pedestrian reads the invalid card, the system prohibits pedestrians from passing (normally open mode, the gate will be closed;...
- Page 16 Retractable Flap Barrier Operation Manual 7. Debugging Introduce Once the mechanical and electrical installation of the turnstile has been completed, it can be put into service. 1. Checking the wiring connection Please carefully check all wiring are correctly connected according to diagram, check connectors are not loose;...
- Page 17 Retractable Flap Barrier Operation Manual avoid accident of personnel injury. 8. Parameter setting of Main Controller Board Example of menu settings: Power on---R U N 0---S E T---P 0 0---I N C---L P 0 1---S E T--- 0 0 1 ---I N C---0 0 2 ---S E T---L P 0 1---P 0 0 ---S E T---R U N 0 Note : : S E T key is function key...
- Page 18 Retractable Flap Barrier Operation Manual 1 Entering and exiting menu settings The basic method for entering and exiting the menu while the system is running (LED is shown as 'RUNX') is (button and display digital tube position Figure A- 1) Press SET to enter the menu function setting status and display ‘P00’ 2) Press the INC key to increase the system function number to the desired function number (the system function number is incremented by 1 each time the INC key is pressed)
- Page 19 Retractable Flap Barrier Operation Manual operation modes are available. ● 000: Two-way control of entry and exit, both access and exit are required to read the card. ● 001: The entrance is controlled, the exit is free, the entrance needs to read the card, and the exit can be accessed without reading the card;...
- Page 20 Retractable Flap Barrier Operation Manual ● 02: Alarm for the buzzer. LP04: default LP05: default LP06: Pass time The value is 3-60, in seconds LP07 : Signal effective time The value is 10-50 in seconds LP08: device address The value is 0-255; LP09: extraordinary delay time The value is 0-60;...
- Page 21 Retractable Flap Barrier Operation Manual Refer to the slave control panel display (CLO2) when adjusting this parameter; The value is 0-50; dP06 : Gate open 2 Fine adjustment Refer to the slave control panel display (OPE2) when adjusting this parameter; the host display (OU01);...
-
Page 22: Frequently Asked Questions
Retractable Flap Barrier Operation Manual NP01: Device type selection 00: blocking; 01: logic to determine the Retractable Flap Barriers; 02:; 03:; 04: single Retractable Flap Barriers; 05:; NP02: Parameter recovery When the display shows ‘NP02’, press SET to enter and display the P-H value. Press and hold INC when you need to restore the default value. - Page 23 Retractable Flap Barrier Operation Manual installing the magnet. The size of the gap between the magnet and the limit plate should be about 5 mm. The magnet has N/S pole magnet fixed and the corresponding limit will not be bright. ) 2, the main and auxiliary machine communication line connection, (the channel installation must ensure a motherboard a sub-board (the main board marked with Z, the sub-board marked with F) main board can be set by NP09)
- Page 24 Retractable Flap Barrier Operation Manual 4, NP02 recovery parameters (both main and sub-boards are required) 5, through the actual situation setting NP07 set the motor's forward and reverse (main and auxiliary boards are required) 6, automatic shutdown of power failure 3．...
- Page 25 Retractable Flap Barrier Operation Manual First check the reduction ratio of the entire system and then set the value of the corresponding NP08. The NP08 setting method is as follows: This value is calculated as the motor gearbox reduction ratio * output gear reduction ratio / 15 (system default motor selection 30 ratio) Set the door opening angle by adjusting the values of DP06 and DP07.
- Page 26 Retractable Flap Barrier Operation Manual 1. The value of DP08 is set too large. 12. When the arm is illegally pushed, the device will automatically restart without returning. Solution: Whether to install the battery (when the arm is illegally pushed, the current of the locked motor will increase, and the power will automatically protect.
-
Page 27: Warranty Card
Retractable Flap Barrier Operation Manual 【 WARRANTY CARD】 1. Please keep this card with reasonableness, and show it when maintaining it. 2. This card will be invalid if without the signature or stamp of the designated dealer. 3. This card will be regarded as invalid if it has not been filled in details three guarantees and acknowledgment of receipt. - Page 28 Retractable Flap Barrier Operation Manual...
