INSTRUCTION MANUAL
MUX-2A-QAM
ASI Multiplexer
Model
MUX-2A-QAM
Status
Active
Obsolete
©2012 Blonder Tongue Laboratories, Inc. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of their respective owner.
Stock No.
Description
6505
ASI Multiplexer
Date
August 29, 2012
Jan. 20, 2012
(800) 523-6049 • (732) 679-4000 • FAX: (732) 679-4353
Document No.
Issue No.
651227400B
651227400A
One Jake Brown Road
Old Bridge, NJ 08857-1000 USA
www.blondertongue.com
Author
2
KK
1
KK
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blonder tongue MUX-2A-QAM
Summary of Contents for Blonder tongue MUX-2A-QAM
- Page 1 Status Date Document No. Issue No. Author Active August 29, 2012 651227400B Obsolete Jan. 20, 2012 651227400A ©2012 Blonder Tongue Laboratories, Inc. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of their respective owner.
- Page 2 We recommend that you write the following information in the spaces provided below. Purchase Location Name: Purchase Location Telephone Number: MUX-2A-QAM Serial Number: The information contained herein is subject to change without notice. Revisions may be issued to advise of such changes and/or additions.
-
Page 3: Table Of Contents
MUX-2A-QAM Instruction Manual Table of Contents SECTION 1 – GENERAL & SAFETY INSTRUCTIONS ....................... 4 SECTION 2 – PRODUCT SUMMARY ..........................6 2.1 REVISION HISTORY & REASON ............................ 6 2.2 PRODUCT APPLICATION & DESCRIPTION ........................6 2.3 PRODUCT SPECIFICATION ............................8 SECTION 3 – INSTALLATION & POWER-UP ........................9 3.1 UNPACKING ................................. 9 3.2 INSTALLATION ................................9 3.3 POWER-UP .................................. -
Page 4: Section 1 - General & Safety Instructions
➥ U nplug the unit from the AC power outlet before cleaning. Use only a damp cloth for cleaning the exterior of the unit. ➥ D o not use accessories or attachments not recommended by Blonder Tongue, as they may cause hazards, and will void the warranty. - Page 5 ❏ The unit exhibits a distinct change in performance. ➥ When replacement parts are required, ensure that the service technician uses replacement parts specified by Blonder Tongue. Unauthorized substitutions may damage the unit or cause electrical shock or fire, and will void the warranty.
-
Page 6: Section 2 - Product Summary
The data rate can be up to 38.8 Mbps for transmission in a single 6 MHz, QAM 256 channel or higher with QAM 512 and 1024. The MUX-2A-QAM supports standard EIA CATV, IRC, HRC and Broadcast channel plans in the 54 – 864 frequency range. All channel frequency information, with appropriate FCC offsets, is pre-programmed and tuned electronically via... - Page 7 MUX-2A-QAM Instruction Manual Description: Below are the front and rear pictures of the unit: [1] & [2] LCD SCREEN & KEY-PAD: The LCD has 2 lines, each capable of displaying 16 characters. The key-pad has 5 push-down buttons used to navigate between menus and to program unit information.
-
Page 8: Product Specification
8 MUX-2A-QAM Instruction Manual 2.3 Product Specification INPUT OUTPUT Connectors Connector: 1x “F” Female ASI: 2x BNC Female QAM Modulation Modes: 16, 32, 64, 128, 256, 512, and 1024 Emergency Alert System 1x BNC Female (EAS) DVB Symbol Rate: Variable; 1 to 7 MSymbols/sec (MBaud) Standard: DVB-ASI;... -
Page 9: Section 3 - Installation & Power-Up
3.2 Installation The MUX-2A-QAM multiplexer is designed to be installed in a standard 19-inch (480 mm) rack (EIA 310-D, IEC 60297, and DIN 41494 SC48D). To install the encoder, secure its front panel to the rack by inserting four machine screws, with cup washers, through the four mounting holes in the front panel. -
Page 10: Section 4 - Configuration
10 MUX-2A-QAM Instruction Manual Section 4 – Configuration 4.1 General Configuration and monitoring of the unit is accomplished by utilizing the front-panel LCD and Key-pad. Configuration of the unit is accomplished from the five push-down buttons on the front-panel key-pad: t (L), u (R), p (UP), q (DN), and Enter. - Page 11 MUX-2A-QAM DIAGRAM #1 Instruction Manual Input Module Menu QAM Menu RF Output Menu MUX Output Menu (see section 5 for more detail) (See section 6 for more detail) (See section 7 for more detail) (See section 8 for more detail) RF OUTPUT MENU QAM MENU MUX OUTPUT MENU...
-
Page 12: Quick Configuration Modules
12 MUX-2A-QAM Instruction Manual 4.2 Quick Configuration 1. Connect the ASI input cables. Please pay attention to the maximum input bandwidth that the unit and input modules can handle. A more detailed guide to maximum input bandwidth and output bandwidth limitations can be found in Section 10. -
Page 13: Section 5 - Input Menu
Stream Absent If an input stream is present, the MUX-2A-QAM will automatically scan and lock to the input stream. Programs, along with their program numbers, will be displayed on the LCD. Major/Minor channel numbers and station call letters are also displayed when present. -
Page 14: Input Menu: "Pid Offset" Parameter
SOME TV SETS WILL REQUIRE RE-SCANNING IN ORDER TO DISPLAY THE REVISED CHANNEL NUMBER ASSIGNMENTS. NOTE: The CVCT Mode allows the MUX-2A-QAM to set each virtual channel assignment as a one-part three-digit integer channel number (major) only for CATV applications (ie:“570”) compared to the ATSC broadcast two-part format having major and minor channels (ie:“17-3”). -
Page 15: Section 6 - Qam Menu
MUX-2A-QAM Instruction Manual Section 6 - QAM Menu 6.1 General The “QAM MENU” allows you to configure the QAM output of the unit. The seven (7) possible configurable parameters shown in Section 4.1 are explained in detail in this section. However, the following two status messages are applicable when you are in the "QAM MENU":... -
Page 16: Qam Menu: "Baud Rate" Parameter
16 MUX-2A-QAM Instruction Manual 6.5 QAM Menu: “Baud Rate” Parameter Baud Rate (or modulation rate) is the number of distinct symbol (or signaling) changes made to the QAM output transmission medium per second. The measurement unit is typically in Mega Bauds (MBd) which is synonymous to Mega symbols per seconds (Msps). -
Page 17: Section 7 - Rf Output Menu
MUX-2A-QAM Instruction Manual Section 7 - RF Output Menu 7.1 General The “RF OUTPUT MENU” allows you to configure the RF output of the unit. The three (3) possible configurable parameters shown in Section 4.1 are explained in detail in this section. However, the following status messages are applicable when you are in the "RF OUTPUT MENU":... -
Page 18: Section 8 - Mux Output Menu
The MUX-2A-QAM default setting is “No”. When this mode is enabled (yes selected), major and minor channel numbers and names can be added or edited under the MUX Output / Program # ( Section 8.9) menu. The MUX-2A-QAM creates and maintains the CVCT (cable virtual channel table) and MGT (master guide table) in this mode. -
Page 19: Mux Output Menu: "Factory Default" Parameter
MUX-2A-QAM Instruction Manual 8.6 MUX Output Menu: “Factory Default” Parameter Allows you to erase all current configuration values and restore to factory default values shown in Section 4.1. To restore all configurations values to the factory default, follow these steps: 1. Using the t (L) or u (R) buttons scroll to the “MUX OUTPUT MENU”. See Section 4.1 for details. -
Page 20: Mux Output Menu: "Program #X" Parameter
Instruction Manual Section 9 - Emergency Alert System (EAS) The MUX-2A-QAM EAS feature allows all program streams to be replaced by an EAS broadcast when activated. An ASI input is required for EAS. The ASI format must be a single stream standard definition program (typically <=5.5 Mbps data rate) with MPEG 2 or 4 audio/video encoding. -
Page 21: Section 10 - Frequently Asked Questions
QAM 256. Question: What happens when more than 12 input programs are presented to an input? Answer: The additional programs are not recognized by the MUX-2A-QAM and cannot be multiplexed to the QAM output. Question: What is the maximum number of multiplexed programs and the maximum output data rate? ... - Page 22 Frequently Asked Questions (continued) Question: What happens if a programmed, operational MUX-2A-QAM loses power? Answer: The unit has a non-volatile memory that stores all of unit settings so that it can resume normal operation after going through its reboot sequence. Currently, PIDs are not stored in non-volatile memory. Use the PID offset feature on inputs having the same program numbers as another input.
-
Page 23: Appendix A: Measuring The Qam Output Signal Level
MUX-2A-QAM Instruction Manual Appendix A: Measuring the QAM Output Signal Level To ensure that the QAM output power level indicated on the LCD screen is indeed accurate, you can also measure the true equivalent signal level for the QAM carrier using the CW (Carrier Wave) signal. The unit is capable of supplying the CW signal which simplifies the measurement process because the output level does not need to be adjusted for the bandwidth setting limitations of the spectrum analyzer. - Page 24 Limited Warranty Blonder Tongue Laboratories, Inc. (BT) will at its sole option, either repair or replace (with a new or factory reconditioned product, as BT may Blonder Tongue Laboratories, Inc. (BT) will at its sole option, either repair or replace (with a new or factory reconditioned product, as BT may determine) any product manufactured by BT which proves to be defective in materials or workmanship or fails to meet the specifications which...
