Summary of Contents for Ingco AG23508
- Page 1 Angle Grinder Angle Grinder AG23508 UAG23508 AG23508-1 UAG23508-1 AG23508-6 AG23508S-2 AG23508.1 AG23508.8 AG23508E...
- Page 2 English Page 3-19...
- Page 3 3|English The symbols in instruction manual and the label on the tool Double insulated for additional protection. Read the instruction manual before using. CE conformity. Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
- Page 4 4|English GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
- Page 5 5|English a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.
- Page 6 6|English and must be repaired. c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
- Page 7 7|English Additional Safety Warnings S S a a f f e e t t y y i i n n s s t t r r u u c c t t i i o o n n s s f f o o r r a a l l l l o o p p e e r r a a t t i i o o n n s s Safety Warnings Common for Grinding, Sanding, Wire Brushing, Polishing or Abrasive Cutting- Off Operations: a) This power tool is intended to function as a grinder, sander, wire brush, polisher or cut-off...
- Page 8 8|English and excessive accumulation of powdered metal may cause electrical hazards. o) Do not operate the power tool near flammable materials. Sparks could ignite these materials. p) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in electrocution or shock.
- Page 9 9|English e) Always use undamaged wheel flanges that are of correct size and shape for your selected wheel. Proper wheel flanges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off wheels may be different from grinding wheel flanges. f) Do not use worn down wheels from larger power tools.
- Page 10 10|English Residual risks Even when the power tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise in connection with the power tool’s construction and design: a) Health defects resulting from vibration emission if the power tool is being used over longer period of time or not adequately managed and properly maintained.
-
Page 11: Specifications
Grinding spindle thread 5/8˝-11 Disc diameter 230mm 9˝ 230mm 230mm Wire brush diameter 150m 5-7/8˝ 150mm 150mm Packed by plastic case(Only for AG23508-1, UAG23508-1, AG23508.1) Model No. AG23508.8 (BS Plug) AG23508E AG23508-1 UAG23508-1 AG23508.1 Rated power input 2350W 2350W 2350W 2350W... -
Page 12: Specific Safety Rules
12|English 10. Dress properly. Do not wear loose clothing or Service jewelry. Contain long hair. Keep your hair, 23. Tool service must be performed only by clothing, and gloves away from moving parts. qualified repair personnel. Service Loose clothes, jewelry, or long hair can be caught maintenance performed by unqualified personnel in moving parts. -
Page 13: Functional Description
13|English flawed, it will likely separate during this test. Use only flanges specified for this tool. Symbols Be careful not to damage the spindle, the The followings show the symbols used for tool. flange (especially the installing surface) or the ･... - Page 14 14|English For continuous operation, pull the switch trigger and Switch handle mounting positions then push in the lock button, and then relese the switch trigger. 1. Motor housing To stop the tool from the locked position, pull the switch 2. Handle trigger fully, then release it.
-
Page 15: Operation
15|English For tool with clamp lever type wheel guard 1. Lock nut wrench 2. Shaft lock 1. Bearing box 2. Wheel guard 3. Nut To remove the wheel, follow the installation procedure in reverse. OPERATION 1. Nut WARNING: It should never be necessary to force the tool. The •... -
Page 16: Maintenance
16|English Operation with wire cup brush (optional can shatter during use and guard helps to reduce accessory) chances of personal injury. Unplug tool and place it upside down allowing easy 1. Wire cup brush access to spindle. Remove any accessories on spindle. 2. - Page 17 If you decide to use your INGCO grinder with approved accessories which you purchase from your INGCO distributor , be sure to obtain and use all necessary fasteners and guards as recommended in this manual. Your failure to do so could result in personal injury to you and others.
-
Page 18: Exploding View
18|English EXPLODING VIEW AG23508,UAG23508,AG23508-1,UAG23508-1 AG23508-6,AG23508S-2,AG23508.1,AG23508.8,AG23508E Exploding view... -
Page 19: Spare Part List
19|English SPARE PART LIST AG23508,UAG23508,AG23508-1,UAG23508-1 AG23508-6,AG23508S-2,AG23508.1,AG23508.8,AG23508E Spare Part List No. Exploding view No. Exploding view Special Spanner 30 6201 Bearing Pressure Plate 31 Press Plate of Bearing Grinding Wheel 32 Screw M4×10 Pressure Plate 33 Rotor Guard 35 629 Bearing Screw M8×30... - Page 20 INGCO TOOLS CO.,LIMITED www.ingco.com MADE IN CHINA 1218.V12 AG23508 UAG23508 AG23508-1 UAG23508-1 AG23508-6 AG23508S-2 AG23508.1 AG23508.8 AG23508E...
