- Page 1 USER MANUAL Longo programmable controller LPC-2.A04 Analog Output module Version 1 SMARTEH d.o.o. / Poljubinj 114 / 5220 Tolmin / Slovenia / Tel.: +386(0)5 388 44 00 / e-mail: info@smarteh.si / www.smarteh.si...
- Page 2 Longo programmable controller LPC-2.A04 Written by SMARTEH d.o.o. Copyright © 2005, SMARTEH d.o.o. User Manual Document Version: 001 March 31, 2006...
- Page 3 24 months is valid from the date of sale to the end buyer, but not more than 36 months after delivery from Smarteh. In case of claims within warranty time, which are based on material malfunctions the producer offers free replacement. The method of return of malfunctioned module, together with description, can be arranged with our authorized representative.
- Page 4 Longo programmable controller LPC-2.A04 Longo programmable controller LPC-2.A04 1 DESCRIPTION...................1 2 FEATURES..................2 3 INSTALLATION..................3 3.1 Connection scheme example............3 3.2 Mounting instructions..............5 3.3 Module labeling................6 4 TECHNICAL SPECIFICATIONS..............7 5 CHANGES ..................8 6 NOTES...................9...
- Page 5 Longo programmable controller LPC-2.A04 1 DESCRIPTION LPC-2.A04 is an eight analog outputs module. Outputs can be individually set as current or voltage mode with correspondent jumper. In current output mode module generates 0 .. 20 mA, if configured as voltage output mode it generates 0 .. 10 V on the port.
- Page 6 Longo programmable controller LPC-2.A04 2 FEATURES Figure 1: LPC-2.A04 analog module. Table 1: Technical data 8 analog outputs Voltage / current output range: 0 .. 10 V / 0 .. 20 mA @ ±1 % / ±1 % accuracy of full scale value...
-
Page 7: Installation
Longo programmable controller LPC-2.A04 3 INSTALLATION 3.1 Connection scheme example Figure 2: Connection scheme example LED1... - Page 8 Longo programmable controller LPC-2.A04 Table 1: Outputs set as voltage set as current analog out 0 .. 10 V OUT1.1 (Q) analog out 0 .. 20 mA OUT1.2 (┴) analog out 0 .. 10 V OUT2.3 (Q) analog out 0 .. 20 mA OUT2.4 (┴)
-
Page 9: Mounting Instructions
Mounting instructions: 1. Switch OFF main power supply. 2. Mount LPC-2.A04 module to the provided place inside an electrical panel (DIN EN50022-35 rail mounting). 3. Mount other LPC-2 modules (if required). Mount each module to the DIN rail first, then attach modules together through K1 and K2 connectors. -
Page 10: Module Labeling
Label 2 description: 1. S/N:MC3-S9-0500000190 is the serial number. MC3 – short product name, • S9 – user code (test procedure, e.g. Smarteh person xxx), • 0500000190 – year and current stack code, • 05 – year (last two cyphers), •... -
Page 11: Technical Specifications
Longo programmable controller LPC-2.A04 4 TECHNICAL SPECIFICATIONS Table 5: Technical specifications Power supply from internal BUS Number of analog outputs Connection type screw type connector for stranded wire 0.75 to 2.5 mm Max. power consumption Max. current consumption 20 mA per output Analog output accuracy of the full <... - Page 12 Longo programmable controller LPC-2.A04 5 CHANGES The following table describes all the changes to the document. Date Description 31.3.2006 The initial version, issued as LPC-2.A04 module UserManual.
- Page 13 Longo programmable controller LPC-2.A04 6 NOTES...
