Olimpia splendid SITALI CXOM 180 Installation, Use & Maintenance Manual

Table of Contents
  • Table of Contents
  • Avvertenze E Precauzioni
  • Informazioni DI Prodotto
  • Generale
  • Dimensioni E Peso
  • Connessioni Delle Tubazioni
  • Spazio Richiesto
  • Etichetta Dati
  • Trasporto E Stoccaggio
  • Installazione
  • Rimozione Dell'imballo
  • Dove/Come Installarlo
  • Installazione a Soffitto
  • Collegamenti Elettrico
  • Messa in Servizio
  • Settaggio Velocità Dei Ventilatori
  • Prima DI Avviare Il Sistema
  • Funzionamento
  • Funzionamento a 3 Velocità con Comando Remoto COMANDO-S (Accessorio Su Richiesta)
  • Funzionamento Anti-Frost
  • Funzionamento Bypass
  • Manutenzione Ordinaria E Straordinaria
  • Lista Componenti
  • Descrizione Dei Componenti
  • Manutenzione Ordinaria
  • Manutenzione Straordinaria
  • Risoluzione Guasti
  • Smaltimento E Riciclaggio

Advertisement

Available languages

Available languages

Quick Links

SITALI CXOM 180
2
MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE
I
15
INSTALLATION, USE AND MAINTENANCE MANUAL
GB
Olimpia Splendid SpA
Via Industriale 1/3, 25060 Cellatica (BS)
www.olimpiasplendid.it - info@olimpiasplendid.it
I dati tecnici e le caratteristiche estetiche dei prodotti possono subire cambiamenti. Olimpia Splendid si riserva di modificarli in ogni momento senza preavviso.
