OPERATOR'S MANUAL
4 - TIER METAL WIRE SHELVING UNIT
23.6" W x 14" D x 47" H
USE PRECAUTION
For your safety
CAUTION: Read and follow all Safety Rules and Operating instructions before first use of this product.
NOTE: Ensure all components are present. If any components are missing, do not proceed with
Assembly. Please send an email to service@greatstartools.com or call 877- 876-7562.
SAVE THIS MANUAL FOR FUTURE REFERENCE
INSTRUCTION
EYE PROTECTION
MANUAL
Must be worn
Read and understand
W082095AE
PROTECTIVE GLOVES
Must be worn when
assembly
Distributed by:
Hangzhou GreatStar Industrial Co., Ltd.
No.35 Jiuhuan Road, Jiubao Town,
Hangzhou 310019, China
www.greatstartools.com
MADE IN CHINA
Advertisement
Table of Contents
Related Manuals for WorkPro W082095AE
Summary of Contents for WorkPro W082095AE
- Page 1 W082095AE OPERATOR'S MANUAL 4 - TIER METAL WIRE SHELVING UNIT 23.6" W x 14" D x 47" H USE PRECAUTION INSTRUCTION EYE PROTECTION PROTECTIVE GLOVES For your safety MANUAL Must be worn Must be worn when Read and understand assembly CAUTION: Read and follow all Safety Rules and Operating instructions before first use of this product.
- Page 2 TABLE OF CONTENTS Safety Information ------------------------------------------------------------------------- Specifications ------------------------------------------------------------------------------ Package Contents ------------------------------------------------------------------------- Assembly ----------------------------------------------------------------------------------- Cleaning and Maintenance ---------------------------------------------------------------- Customer Service -------------------------------------------------------------------------- FOR YOUR SAFETY: CAREFULLY READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USE. SAFETY INFORMATION WARNING! DO NOT let children climb on or play with the unit. ...
- Page 3 PACKAGE CONTENTS Ensure all components are present. If any components are missing, do not proceed with assembly. Please send an email to service@greatstartools.com or call 877- 876-7562. TOOLS REQUIRED (NOT INCLUDED): Rubber Mallet Protective Gloves DESCRIPTION DESCRIPTION Shelf x 4 Foot Leveler x 4 Threaded Post Jointer Top Post (with Post...
- Page 4 ASSEMBLY NOTE: Discard the black plastic spacers. These are used to separate the shelves for shipping purposes. Assemble on a flat surface. A piece of cardboard is recommended to keep the product from being scratched during assembly. Two people are recommended for assembly. ...
- Page 5 ASSEMBLY STEP 2: FIRST AND SECOND SHELF ASSEMBLY Attach four plastic sleeves (F) to the appropriate bottom posts (C) one in each post. Ensure the arrows on the plastic sleeves should point upwards. The plastic sleeves must be at the same height for each post to ensure the shelf sits on the sleeves levelly.
- Page 6 ASSEMBLY STEP 3: TOP POST ASSEMBLY Screw four top posts (B) into four bottom posts(C) tightly together clockwise. Top Post Bottom Post Fig. 4 PART DESCRIPTION Top Post Bottom Post...
- Page 7 ASSEMBLY STEP 4: THIRD AND FOURTH SHELVES ASSEMBLY Repeat the step 2 to install the third and fourth. Place cardboard over the corners of each shelf and gently tap down with a rubber mallet (or similar tool) until the shelf is level. Shelf Plastic Sleeves Fig.
- Page 8 ASSEMBLY STEP 5: S HOOK ASSEMBLY Place four S hooks (G) on the shelves at your desired position as you need. S Hook Fig. 6 PART DESCRIPTION S Hook CLEANING AND MAINTENANCE Wipe with a dry cloth as needed to remove dust and dirt. ...
