Summary of Contents for Samsung HT-E456K
- Page 1 HT-E450K HT-E453K HT-E453HK HT-E445K HT-E456K Digital Home Entertainment System user manual Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Code No. AH68-02443U...
-
Page 2: Safety Information
Safety Information Safety Warnings TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates “dangerous voltage” CAUTION : TO PREVENT ELECTRIC This symbol indicates important inside the product that presents a risk of... -
Page 3: Precautions
Precautions • Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product. • Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (7.5~10cm). •... -
Page 4: Cautions On Handling And Storing Discs
• This product uses some software programs which are distributed under the OpenSSL Project. Licence Copyright © 2012 Samsung Electronics Co., Ltd. All rights reserved. Copy Protection • Dolby and the double-D symbol are registered trademarks of Dolby • Many DVD discs are encoded with copy protection. -
Page 5: Table Of Contents
Contents SAFETY INFORMATION Safety Warnings Precautions Accessories Cautions on Handling and Storing Discs Licence Copyright Copy Protection Icons that will be used in manual GETTING STARTED Disc Types and Characteristics Description Front Panel Rear Panel Remote control CONNECTIONS Connecting the Speakers Connecting the Video Out to your TV Connecting Microphone Connecting the FM Antenna... - Page 6 Contents Disc Playback BASIC FUNCTIONS Audio CD(CD-DA)/MP3/WMA Playback JPEG File Playback Using the Playback Function Sound Mode Listening to Radio ADVANCED FUNCTIONS USB Function USB Recording Troubleshooting OTHER INFORMATION Language code list Specifications OpenSSL License • Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
-
Page 7: Getting Started
Getting Started Icons that will be used in manual Disc Types and Characteristics Make sure to check the following terms before Region Code reading the user manual. Icon Term Definition The product and the discs are coded by region. These regional codes must match in order for the disc to play. - Page 8 Getting Started CD-R MP3 Discs Disc types that can be played • Only CD-R discs with MP3 files in ISO 9660 or Joliet format can be played. Disc Types & Recorded Disc Max. Playing Time • MP3 file names should contain no blank spaces Mark (Logo) Signals Size...
- Page 9 DVD±R/±RW, CD-R/RW Discs higher than 48khz or 320kbps, you may experience shaking on the screen during playback. • Software updates for incompatible formats are not • Sections with a high frame rate might not be played supported. while playing a DivX file. (Example : QPEL, GMC, resolutions higher than •...
- Page 10 Getting Started Notes on USB connection 14) Supported file formats Supported devices: USB storage media, MP3 Still Format Music Movie Picture player, digital camera File name DivX 1) If a folder or file name is longer than 10 characters, it may not properly display or File .MP3 .WMA...
-
Page 11: Description
Description Front Panel 5V 500mA MIC 1 AUX IN 1 MIC 2 DISC TRAY Insert disc here. AUX IN 1 CONNECTOR Connect external components such as an MP3 player. DISPLAY Displays the playing status, time, etc. OPEN/CLOSE BUTTON ( Opens and closes the disc tray. The mode switches as follows : FUNCTION BUTTON ( DVD/CD ➞... -
Page 12: Rear Panel
Getting Started Rear Panel SPEAKERS OUT VIDEO AUX IN 2 FM ANT HDMI OUT FA NET (Only For Service) OPTICAL DIGITAL SURROUND SUBWOOFER SURROUND AUDIO IN FA NET (Only for Service) Used for the service repair. The fan always revolves when the power is on. Ensure a minimum of 10cm of clear COOLING FAN space on all sides of the fan when installing the product. -
Page 13: Remote Control
Remote control Tour of the Remote Control This is mode selection button. FUNCTION SOURCE Press to select TV's video mode. Turn the product on and off. Set a Sleep time to shut off the product. If you want to change to TV mode, press the TV button. - Page 14 The remote control may not work or some operations 18, 40 Zonda Mitsubishi/ may not be possible with some brands of TVs. 18, 40, 59, 60, 75 Dongyang 03, 54 The remote control will work on a Samsung TV by default. English...
-
Page 15: Connections
Connections This section involves various methods of connecting the product to other external components. Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Connecting the Speakers Position of the product Place it on a stand or cabinet shelf, or under the TV stand. - Page 16 Connections Speaker Components HT-E450K CENTER FRONT SURROUND SUBWOOFER Speaker Components Assembled Speakers HT-E453K HT-E453K (L) (R) CENTER SPEAKER SURROUND CENTER FRONT STAND SPEAKER FRONT SURROUND CABLE SUBWOOFER SCREW (5×15): 8EA STAND BASE SUBWOOFER SPEAKER SPEAKER HT-E453HK HT-E453HK STAND BASE ...
- Page 17 CENTER SPEAKER FRONT STAND (L) (R) CENTER SUBWOOFER FRONT SURROUND SUBWOOFER STAND BASE SURROUND SPEAKER SPEAKER HT-E456K HT-E456K (L) (R) SPEAKER CABLE SCREW (5×15): 16EA CENTER SPEAKER FRONT STAND (L) (R) CENTER FRONT/SURROUND SPEAKER SUBWOOFER STAND BASE SUBWOOFER...
-
Page 18: Connecting The Speakers
Connections Installing the Speakers on the Half Tallboy Stand * HT-E453HK only - Front Speakers 1. Stretch out the speaker cables as shown and arrange it through the hole of the stand base . 2. When done, use the stand driver to tighten the stand nut as shown. 3. -
Page 19: Connecting The Video Out To Your Tv
HDMI FUNCTION HDMI Auto Detection Function If your TV is samsung TV and it supports CEC function.The product's video output will automatically change to HDMI mode when connecting an HDMI cable while power is on. • HDMI (High Definition Multimedia Interface) •... -
Page 20: Connecting Microphone
Anynet+ is a function that enables you to control other Samsung Devices with your Samsung TV's remote control. Anynet + can be used by connecting this product to a SAMSUNG TV using a HDMI Cable. This is only available with SAMSUNG TV's that support Anynet+. -
Page 21: Connecting The Fm Antenna
Connecting the FM Antenna FM Antenna (supplied) SPEAKERS OUT VIDEO AUX IN 2 FM ANT HDMI OUT OPTICAL DIGITAL SURROUND SUBWOOFER SURROUND AUDIO IN 1. Connect the FM antenna supplied to the FM Antenna jack. 2. Slowly move the antenna wire around until you find a location where reception is good, then fasten it to a wall or other rigid surface. - Page 22 Connections Connecting Audio from External Components SPEAKERS OUT White White VIDEO AUX IN 2 FM ANT HDMI OUT FA NET (Only For Service) OPTICAL DIGITAL SURROUND SUBWOOFER SURROUND AUDIO IN Audio Cable (not supplied) If the external analog Optical Cable component has only one (not supplied) Audio Out, connect either...
-
Page 23: Setup
Setup Before Starting (Initial Settings) Setting the Setup menu The access step may differ depending on the selected 1. Press the POWER button when it is plugged in menu. The GUI (Graphical User Interface) in this TV for the first time. manual may differ, depending on the firmware version. -
Page 24: Display
• TV : Select if connected to a TV via HDMI. (Samsung products only) BD Wise is Samsung's latest inter-connectivity Video Out Signal feature. When you connect Samsung products with BD-Wise to each other via HDMI, the optimum Different countries apply different TV standard. resolution will be set automatically. -
Page 25: Audio
Adjusting Front/Surround Bal. Audio You can select between 0 and -6. Speaker Setting The volume decreases as you move closer to –6. Adjusting Center/Surround/Subwoofer Level Speaker Size The volume level can be adjusted in steps from +6dB to –6dB. You can set the Speaker Size of the Center and Surround ... -
Page 26: Drc (Dynamic Range Compression)
Setup Test Tone Ideal Center Speaker placement Settings Speaker Setting Speaker Size Sound Edit Delay Time Test Tone : On ► Ideal Surround " Select ' Return Speaker placement mMove " Select ' Return Place all speakers within this circle. Use the Test Tone feature to check the speaker Df: The distance from Front Speaker connections. -
Page 27: Speaker Selection
Speaker Selection ✎ NOTE The audio signals transmitted over the HDMI Cable When Anynet+ (HDMI-CEC) is Off, the Audio can be changed Home Theater/TV Speaker. Return Channel function is not available. • Home Theater : Video is transmitted over the ... -
Page 28: Language
Setup Change Password Language Select Change and enter the 4-digit password to set You can select the language you prefer for on-screen the parental lock using the number buttons on the menu, disc menu, etc. remote control. Select the language for the on-screen Settings Language displays. -
Page 29: Basic Functions
Basic Functions Audio CD(CD-DA)/MP3/WMA Playback Disc Playback 1. Press the OPEN/CLOSE () button. 2. Place a disc gently into the tray with the disc's label facing up. 3. Press the OPEN/CLOSE () button to close Track01 the disc tray. 1/17 ✎... - Page 30 Basic Functions JPEG File Playback Using the Playback Function Images captured with a digital camera or camcorder, or Forward/Reverse Search JPEG files on a PC can be stored on a CD and then played back with this product. dBAD 1. Insert a JPEG disc on the disc tray. 2.
- Page 31 Step Motion Play Using the Title Menu Press the PAUSE button repeatedly. For DVDs containing multiple titles, you can view the • The picture moves forward one frame each time title of each movie. the button is pressed during playback. TITLE MENU During playback, press the TITLE ✎...
- Page 32 Basic Functions CD/MP3 Repeat Displaying Disc Information 1. During the CD/ MP3 playback, press the REPEAT button repeatedly to select the repeat mode you want. 2/20 (Repeat Off Repeat Track Repeat All 0:05:21 Random Repeat Section A-B) 1/1 EN AC3 5.1 1/1 EN Change Select...
- Page 33 3. Press the ◄► buttons to select the desired TOOLS menu subtitle language. Title( ) : To access the desired title • Depending on the languages on a DVD disc, when there is more than one in the disc. a different subtitle language is selected each For example, if there is more than one time the button is pressed.
- Page 34 Basic Functions SLEEP GIGA You can set the time that the Home Cinema will shut The GIGA Sound Function amplifies bass and improves bass itself off. twice as much for you to appreciate powerful real sound. The GIGA Sound feature will be applied only to the Press the SLEEP button.
- Page 35 DSP (Digital Signal Processor)/EQ Dolby Pro Logic II Mode • DSP (Digital Signal Processor) : DSP modes have You can select the desired Dolby Pro Logic II audio mode. been designed to simulate different acoustic environments. • EQ : You can select POPS, JAZZ , ROCK, or USER Press the PL II button.
- Page 36 Basic Functions 5. Press the TUNER MEMORY button again. Listening to Radio • Press the TUNER MEMORY button before Using buttons on the Remote Control number disappears from the display. • Number disappears from the display and the 1. Press the FUNCTION button to select FM. station is stored in memory.
-
Page 37: Advanced Functions
Advanced Functions USB Function USB Recording While playing CD-DA (Compact Disc Digital Audio) Playing Media Files using the using the USB Recording function or listening to the FM USB Host Feature radio or receiving audio source from an external device, you can record the audio source in the USB memory. -
Page 38: Other Information
Refer to the chart below when this product does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the product, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom Check/Remedy I cannot eject the disc. -
Page 39: Language Code List
Symptom Check/Remedy • The product is not working. • Press and hold the STOP () button on the remote control for longer than (Example: The power goes out or 5 seconds with no disc (reset function). the front panel key doesn't work or a strange noise is heard.) Using the RESET function will erase all stored settings. -
Page 40: Specifications
Input sensitivity (AUX)800mV *: Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate. - Design and specifications are subject to change without prior notice. - For the power supply and Power Consumption, refer to the label attached to the product. - Page 41 HT-E453K 5.1ch speaker system Speaker system Front Surround Center Subwoofer Impedance 3 Ω 3 Ω 3 Ω 3 Ω Frequency range 140Hz~20KHz 140Hz~20KHz 140Hz~20KHz 20Hz~160Hz Output sound pressure level 86dB/W/M 86dB/W/M 86dB/W/M 88dB/W/M Rated input 167W 167W 165W 167W Speaker Maximum input 334W 334W...
- Page 42 Other Information HT-E456K 5.1ch speaker system Speaker system Front Surround Center Subwoofer Impedance 3 Ω 3 Ω 3 Ω 3 Ω Frequency range 140Hz~20KHz 140Hz~20KHz 140Hz~20KHz 20Hz~160Hz Output sound pressure level 86dB/W/M 86dB/W/M 86dB/W/M 88dB/W/M Rated input 167W 167W 165W...
-
Page 43: Openssl License
OpenSSL License The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org. - Page 44 OpenSSL License Copyright remains Eric Young's, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used.
- Page 45 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Contact Center Contact Center Area Web Site Area Web Site ` North America 0700 Samsung (0700 726 Serbia www.samsung.com...
