GATE ALARM
Installation Instructions
MODEL GAPT-2
MEETS UL 2017
GATE ALARM
SENSOR
SWITCH
LED
PASS THRU
SENSOR
SWITCH
MAGNET
HORN
SENSING
WIRES
F igure 1
The horn is 85dB at 10 feet
IMPORTANT
READ THOROUGHLY BEFORE USING ALARM
The product has been designed to aid in the detection of unwanted
intrusions into unsupervised areas. POOLGUARD GAPT-2 IS A
SAFETY ALARM SYSTEM AND NOT A LIFE SAVING DEVICE. It
should be used in conjunction with the safety equipment currently in use
and should not affect existing safety procedures.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Poolguard GAPT-2
Summary of Contents for Poolguard GAPT-2
- Page 1 READ THOROUGHLY BEFORE USING ALARM The product has been designed to aid in the detection of unwanted intrusions into unsupervised areas. POOLGUARD GAPT-2 IS A SAFETY ALARM SYSTEM AND NOT A LIFE SAVING DEVICE. It should be used in conjunction with the safety equipment currently in use...
- Page 2 When the alarm sounds, the LED will flash once every second. D. Reassemble the gate alarm with the assembly screw. NOTE: Once the battery is installed the alarm may sound accidentally until the sensors are connected properly. INSTALLING POOLGUARD GATE ALARM (FIGS. 1 & 2) F igure 2...
- Page 3 INSTALLING GATE SENSOR (FIG. 1) The Poolguard Gate Alarm is activated by a sensor which consists of two parts. One part contains the sensor magnet. The sensor switch is permanently connected to the sensing wire that comes from the Poolguard Gate Alarm.
- Page 4 OPERATING YOUR GATE ALARM (FIG. 1) The POOLGUARD GATE ALARM uses two delay modes which allow the user to exit and enter the gate without the alarm sounding. These two modes are explained below. A. FIRST DELAY MODE: When the gate is opened the alarm automatically goes into the first delay mode which gives you 7 seconds after the gate is opened to push the pass thru switch.
- Page 5 WARRANTY AND REPAIRS POOLGUARD is sold with a limited warranty to cover defects in parts and workmanship for one year from date of purchase. (Retain proof of purchase). If Poolguard exhibits a defect, please call our Customer Service department at 1-800-242-7163.
- Page 6 • Do not permit bottles, glass, or sharp objects to be used around the pool. • Ask your pool dealer how you can improve your pool safety––they will be glad to assist you. • Above all: remember that common sense, awareness, and caution will allow you to enjoy your pool. www.poolguard.com...
- Page 7 Poolguard’s Family of Products Helps Protect Your Family! www.poolguard.com...
- Page 8 “SAFETY BUOY” ABOVE GROUND POOL ALARM WITH REMOTE RECEIVER IN GROUND POOL ALARM WITH REMOTE RECEIVER DOOR ALARM DOOR ALARM WITH TRANSMITTER www.poolguard.com...
