GETTING STARTED

REAR PANEL

HDMI IN
Inputs digital video and audio
signals simultaneously using an
HDMI cable. Use when
connecting a supported
external device.
AUX IN
Connect to the Analog output
of an external device.
DC 24V (Power Supply In)
Connect the DC power adaptor
to the power supply jack, and
then connect the AC power
adaptor plug to a wall outlet.
When disconnecting the power cable of the AC power adaptor from the wall outlet, pull the plug.
●
Do not pull the cable.
Do not connect this unit or other components to an AC outlet until all connections between
●
components are complete.
Connect USB devices such as
MP3 players here to play files
on the devices.
Connect to the digital (optical)
HDMI OUT (TV)
Outputs digital video and audio
signals simultaneously using an
HDMI cable.
8
(USB Port)
OPTICAL IN
output of an external device.
