KING COBRA
INFORMATION
OPERATING
INSTRUCTIONS
CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTION MANUAL
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Before each use, remove the spray tool from the hose, and check to make sure the spray nozzles are securely
tightened to the spray tool. A loose nozzle could fl y off during use.
3. Keep machine from rain and snow, extremes in temperatures, and store in a heated location. Use the ma-
chine indoors. Do not use outdoors.
4. Never allow the spray to remain fi xed in one spot.
5. Use approved chemicals only. NO SOLVENTS.
6. Wear gloves or use rags when removing quick disconnects to prevent burns.
7. Never use water above 130º F/54º C in the solution tank.
1200 PRO Model 120V
®
&
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
MODEL: KC-1200-500-S
2/08 revised 9/10 FORM NO. 56041961

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KING COBRA 1200 PRO 120V and is the answer not in the manual?

Questions and answers

Related Manuals for ServiceMASTER Clean KING COBRA 1200 PRO 120V

Summary of Contents for ServiceMASTER Clean KING COBRA 1200 PRO 120V

  • Page 1 KING COBRA 1200 PRO Model 120V ® INFORMATION & OPERATING INSTRUCTIONS MODEL: KC-1200-500-S CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THIS INSTRUCTION MANUAL IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage. 2.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS: This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offi ces other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your KING COBRA-1200 PRO for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts. CLEANING SOLUTIONS: Select a proper pre-spray for the surface to be cleaned, and apply the pre-spray.

  • Page 4: Know Your Machine

    KNOW YOUR MACHINE Vacuum Hose Wand Holder Connection Switches Hoses Recovery Tank 1200 PSI Quick Latch Disconnect Auto-fi ll Solution Hose Tank Connector 500 psi Wheel Pressure Adjust Base Knob Compartment Vacuum Hose 500 psi 500 psi 1200 psi Quick Disconnect Connection Gauge Gauge...

  • Page 5: Switch Plate

    SWITCH PLATE U.S. PRODUCTS 1200 P.S.I. HEAT This green light will turn on when the two power cords are plugged into separate circuits. Try different outlets with one cord until you can get a green light, otherwise a circuit breaker in the wall may trip. This switch allows you to select either the 1200 psi pump without heat or the 500 psi pump and heat.
  • Page 6 REFER TO THE DIAGRAMS ON THE PREVIOUS PAGE SET-UP and OPERATION 1200 PSI HIGH PRESSURE WASHER Before each use, inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Make sure the hoses are in good condition and the spray nozzle(s) is tight. 2.
  • Page 7 OPERATION OF THE 1200 PSI PUMP CONTINUED: 9. Your machine has two solution outputs. The solution output for the 1200 psi pump is a quick disconnect located just below the fi ll hole on the holding tank, on the front face of the machine (the 500 psi outlet is a quick disconnect on the end of a short length of hose, on the front of the base section of the machine).
  • Page 8 AUTO-FILL Operation: • Attach a 3/4” garden hose to the auto fi ll valve, and connect the other end of the hose to your water source. • Make sure the fl oat that hangs from the auto fi ll valve into the tank is free of obstruction and can move freely. •...
  • Page 9 AUTO-DUMP Operation: Before each use: if necessary, unscrew the stainless steel fi lter at the bottom of the recovery tank and clean it. Also make sure the fl oat in the recovery tank is clean. • Attach a 3/4” garden hose to the dump pump outlet fi tting on the back of the base of the machine. Refer to illustration below.
  • Page 10 revise 9/10 26 27 to item the complete assembly 111A 135A 10 - FORM NO. 56041961...
  • Page 11 revise 9/10 ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION 1303 Switch Plate SYP1 Priming hose, for 500 psi Light, green, 1200 psi pump Louver, 3”, includes screws Light, red, heat FP534 Hose, heater to outlet Light, green, dual circuit Hose Assembly, 32”, bypass 56220001 Switch, 3-way;...

  • Page 12: Specifications

    SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Vacuum: 7.2” 3-stage, 140” of water lift VAC Shutoff: Ball Float Pump: Positive displacement, fully adjustable 0-500 psi & Positive displacement, 1200 psi, 2.2 gpm Heat: 2000 Watts, adjustable up to 212 °F Capacity: 16 gallon solution tank; 14 gallon recovery tank Cords: Two, detachable 12/3, hospital grade plugs Size:...
