Technical Specifications - Philips AZ1301 Specifications

CD Soundmachine Dynamic Bass Boost

Technical specifications

Sound
• Loudspeaker Enhancement: Piezo
• Loudspeaker types: 2-way Bass Reflex Speaker
• Output power (RMS): 2X1.2W
• Sound Enhancement: Dynamic Bass Boost
• Sound System: Stereo
• Speaker diameter: 4"
• Volume Control: Volume Control up/down
Loudspeakers
• Built-in speakers: 2
• Finishing: Metal
• Loudspeaker types: Loudspeakers
Audio Playback
• Playback Media: CD, CD-R, CD-RW
• Disc Playback Modes: Fast Forward/Backward,
Next/Previous Track Search, Repeat Play, Shuffle
Play
• Loader Type: Top
• Programmable Tracks: 15
Tuner/Reception/Transmission
• Antenna: AM Antenna, FM Antenna
• Auto digital tuning
• Tuner Bands: AM, FM
Date of issue 2005-11-29
Version: 4.0
12 NC: 9073 101 01326
Connectivity
• Headphone: 3.5 mm
Convenience
• Display Digits: 6
• Display Type: OLED
Accessories
• Included Accessories: AC Power Cord, User
Manual, Warranty certificate
Dimensions
• Packaging dimensions (W x H x D):
470 x 275 x 210 mm
• Product dimensions (W x H x D):
400 x 243 x 169 mm
• Weight: 2.9 kg
• Weight incl. Packaging: 3.7 kg
Power
• Battery Type: LR14
• Battery Voltage: 1.5 V
• Mains power
• Number of batteries: 6
•
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2005 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
AZ1301/17
Product highlights
Digital tuning with presets
Autostore programming
Autostore Programming is a convenient feature that
allows you to tune in to your favorite stations and set
station presets by simply pressing a button. Autostore
Programming does away with the hassle of manual
radio station tuning and setting of presets. A built-in
electrical circuit automatically scans local radio station
frequencies, locks on to the strongest radio station
signals, and assigns them to specific presets.
CD shuffle/program/repeat
CD-Rewritable Compatible
CD-Rewritable Compatible means that your audio set
can play both CD-Recordable (CD-R) and CD-
Rewritable (CD-RW) discs. CD-R discs are recordable
once and can be played on any audio CD player while
CD-RW discs can be recorded and rewritten multiple
times and can only be played back on compatible audio
CD players. The laser pick-up and CD decoder circuitry
of CD-RW compatible players are specially designed to
read the special audio CD-RW phase-change recording
layer, ensuring you can always play your home-recorded
discs on your audio CD system.
15-track CD programmable
Dynamic Bass Boost
Dynamic Bass Boost maximizes your music enjoyment
by emphasizing the bass content of the music
throughout the range of volume settings - from low to
high – at the touch of a button! Bottom-end bass
frequencies usually get lost when the volume is set at a
low level. To counteract this, Dynamic Bass Boost can
be switched on to boost bass levels, so you can enjoy
consistent sound even when you turn down the volume.
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep bass
experience from a compact loudspeaker box system. It
differs from a conventional loudspeaker box system in
the addition of a bass pipe that is acoustically aligned to
the woofer to optimize the low frequency roll-off of the
system. The result is deeper controlled bass and lower
distortion. The system works by resonating the air mass
in the bass pipe to vibrate like a conventional woofer.
Combined with the response of the woofer, the system
extends the overall low frequency sounds to create a
whole new dimension of deep bass.
Two-Way Speaker System
Two-Way Speaker System recreates the ambience and
atmosphere of a recording studio in your living room
through accurate stereo imaging. Simply "You Are
There!". To reproduce the full audio frequency band,
conventional speakers need large and small cones to
reproduce low and high frequencies respectively. Often
sound quality is compromised in favor of smaller design.
By using a woofer to reproduce bass to mid frequencies
and a tweeter for mid to high frequencies, the Two-Way
Speaker System seamlessly plays back the full audio
frequency with much less inter-modulation distortion.
Stereo headphone socket
