Page 3
HIGH FIDELITY MUSIC STREAMER Introduction We appreciate your purchase of Eversolo DMP - A6 all-in-one streamer. As a hi-res DAC streamer with great performance and craftsmanship, DMP-A6 can not only play and manage various high-resolution local music well but also embeds various third-party high-resolution music streaming services, such as Tidal, Qobuz, Highresaudio, Amazon Music, WebDAV, and UPnP, etc.
Page 4
HIGH FIDELITY MUSIC STREAMER Specifications Body Material Aluminium alloy Display 6.0" LCD touchscreen ES9038Q2M*2 Audio Processor XMOS XU316 Storage 4G DDR4 +32G eMMC SSD Protocol M.2 (NVME PCIe3.0)2280 protocol, up to 4TB USB Ports USB3.0*2 Ethernet RJ-45(10/100/1000Mbps) WiFi 2.4G+5G DAC Decoding Support DSD512 stereo, PCM 768KHz 32Bit, MQA DSD(DSF,DFF,SACD ISO Support DST up to DSD512), Music file formats...
Page 5
HIGH FIDELITY MUSIC STREAMER Hardware SSD Installation SSD isn't included in the device, a SSD can be installed manually after you receive the parcel if required. M.2 (NVMe PCIe3.0) 2280 protocol SSDs up to 4TB is supported. How to install SSD: 1.
Page 6
HIGH FIDELITY MUSIC STREAMER 5. To better support song transferring, it is advised to choose an external storage device as the music directory. Go to "Settings >Transfer", and click " " to select the inserted external storage device. The system will automatically create the "EversoloMusic" folder, where the music files will be stored.
Page 7
HIGH FIDELITY MUSIC STREAMER Rear Panel ⑫ ⑬ ④ ⑥ ⑩ ① ② ③ ⑤ ⑦ ⑧ ⑨ ⑪ Descriptions: ① Power on/off ② Gigabit Ethernet network socket ③ HDMI audio only output: support DSD output ④ USB 3.0 OTG: Connect External storage device or PC transfer (Defined in "Settings-General-USB OTG port") ⑤...
Page 8
HIGH FIDELITY MUSIC STREAMER Front Panel Indicator light Knob Controls Rotate : Adjust volume Short press: Power on/Power off/Reboot/ Timed shutdown / Screen off Long press: Power off Volume Control: The knob can be turned clockwise to turn up the volume and counterclockwise to turn down the volume when the device is playing music.
Page 9
HIGH FIDELITY MUSIC STREAMER Power on / off Power on: press the knob once to turn it on when the device is powered off. Power off/reboot: short press the knob to see a pop-up menu and select power off or reboot; long press for 3 seconds to power off.
Page 10
HIGH FIDELITY MUSIC STREAMER Basic Operation Home Screen Status bar Music player entrance Play/pause Previous track Next track Home Back Function entrance Status Bar: input/output connection, network status, storage device, volume, and currently playing song. Click input/output/network/storage device icons to access quick settings, click the song info bar to enter into Music Player.
Page 11
HIGH FIDELITY MUSIC STREAMER Music Player DMP-A6 Music Player allows to play lossless music from SSD, hard drive, NAS and streaming services app. Click "Music player entrance" to enter into Music Player interface and see currently playing tracks, progress and control icons. Favorites Play queue Playback...
Page 12
HIGH FIDELITY MUSIC STREAMER Network Connection Make sure to connect the network for DMP-A6, both Ethernet and WiFi are supported. Access into “Settings > Network > WiFi”. Music Library The music library allows you to manage and categorize local music. Click “Add Library” to add music from local SSD, external storage devices, SMB, and NFS.Or click on the hover window of hidden menu on the left and select "Library".
Page 13
HIGH FIDELITY MUSIC STREAMER DMP-A6 will categorize the added music files by track, artist, album etc. “My” will show recently playing records, playlists added according to personal preferences, and quick access to favorite tracks, artists, and albums. Page 13...
Page 14
HIGH FIDELITY MUSIC STREAMER Music Service It includes streaming services, music apps, music cloud drivers and music connect. Log in your account to play music from third-party apps. Note: *More music apps will be available for download, please check the official website for firmware updates.
Page 15
HIGH FIDELITY MUSIC STREAMER File Manager File Manager is used to managing files in local storage, SSD, removable storage devices, NFS, and SMB in the same network. Click " " to copy, paste, and delete etc. The device enables to copy files from external storage device to SSD conveniently. Go to Files Manager and select the music file in the storage device and click "...
Page 16
HIGH FIDELITY MUSIC STREAMER Inputs/Outputs Choose inputs and outputs based on how the actual device is connected. Note: * all digital input connections only support output audio by analogue output, not digital output. Apps You can view, install and uninstall third-party apps. To install third-party apps, firstly download the APK file and copy it to a removable hard drive, insert the hard drive into this device and find APK file in File Manager, then install it by one click.
Page 17
HIGH FIDELITY MUSIC STREAMER CD Playback and Ripping By connecting with a USB CD-ROM, the device can both play music from CD and rip music files from CD. CD ripping instructions: Apps > CD > Click “ ” to start CD ripping. Click "...
Page 18
HIGH FIDELITY MUSIC STREAMER System Settings System settings include audio settings, display settings, network settings, general settings, song transfer and system upgrade. The settings allow you to change the filtering characteristics of the RCA/XLR outputs, the audio format output from the HDMI/Optical/ Coaxial/DAC, and the formats supported by MQA.
Page 19
HIGH FIDELITY MUSIC STREAMER CHARACTERISTICS FILTER IMPULSE RESPONSE CHARACTERISTIC Distance Edge Fast Roll-Off, Low order reverb, Linear Phase Neutral natural Filter Slow Roll-Off, Low order reverb, Linear Phase Mid far Sharp accurate Filter Fast Roll-Off, High order reverb, Minimum Mid close Neutral mellow Phase Filter Slow Roll-...
Page 20
HIGH FIDELITY MUSIC STREAMER Display Settings In "Display" menu, there are some sub-menus for screen brightness adjustment, screensaver setting and screensaver modes. Screen brightness: adjust brightness level of the screen display. Knob brightness: adjust the brightness for the light surrounding the knob. Screensaver: screensaver will be displayed without operation for a certain time.
Page 21
HIGH FIDELITY MUSIC STREAMER Network Settings Access "Settings > Network > Phone Control", and scan QR code to download "Eversolo Control" APP. Or download and install the APP on the official website and manual. Mobile Phone Controlling APP Please make sure the mobile phone is on the same network with the device, then open the APP, select "DMP-A6"...
Page 22
*Android (for mobile phones only) and IOS(both iphones and iPad) apps both can be downloaded on Quick Start Guide. *IOS apps can be also downloaded by searching "Eversolo Control" in the "App Store". Language Access into “Setting > General > language” to choose menu language.
Page 23
HIGH FIDELITY MUSIC STREAMER Transfer Access“Settings > Transfer” to transfer songs from computer to this device according to the description. Make sure computer and the device are on the same network, choose a path to save songs in Music Directory. Page 23...
Page 24
USB Update Download Eversolo DMP-A6 firmware to a USB stick, insert USB stick into the USB-A type port on the device, access "Settings > About > Version", click "USB Update" to update firmware and wait for the device to reboot automatically.
Page 25
HIGH FIDELITY MUSIC STREAMER Connection and Setting The DMP-A6 has USB audio, HDMI audio, Coaxial and Optical digital audio outputs, as well as RCA single-ended and XLR balanced analogue outputs. USB Output Use a USB audio cable to connect the device’s USB audio output to the external DAC's USB input.
Page 26
HIGH FIDELITY MUSIC STREAMER SPDIF (Coaxial/Optical) Output Use a Coaxial/Optical cable to connect the device’s Coaxial/Optical output to the AV receiver input, then go to "Home screen > Source > Internal Player > SPDIF". Coaxial/Optical cable DAC/AVR Note: *Optical and coaxial outputs support up to stereo PCM 192KHz 24Bit, DSD64 Dop, MQA format.
Page 27
HIGH FIDELITY MUSIC STREAMER Notes: *Two sets of RCA and XLR connectors can output separately or simultaneously. It is recommended to choose XLR in priority for noise suppression and signal completeness. *XLR and RCA separate outputs are available to be selected to minimize the possibility of signal interference caused by simultaneous RCA and XLR outputs.
Page 28
HIGH FIDELITY MUSIC STREAMER Notes: *It is needed to install drives for Windows, please refer to Downloads section in this manual below. *Enable "EVER SOLO DMP-A6" as your computers’ sound output device as follows: Windows: After downloading and installing the driver, follow the setting on computer "Control Panel >...
Page 29
HIGH FIDELITY MUSIC STREAMER Bluetooth Input This device has built in Qualcomm flagship QCC5125 Bluetooth audio receiver module, which supports lossless audio protocols SBC/AAC/aptX/aptX LL/aptX HD/LDAC. It can be used as a high quality Bluetooth decoder to pair with different mobile devices. Go to "Settings >...
Page 30
*It is recommended to scan the QR code with a mobile phone browser. Special Note: In order to improve the user experience, Eversolo will update firmware from time to time. Therefore, this product manual may differ from the actual setting menus of the product.
