Summary of Contents for artisan ARTP-PB

  • Page 2: California Proposition 65 Warning

    CALIFORNIA PROPOSITION 65 - WARNING The burning of gas cooking fuel generates toxic by-products, which are on the list of substances which are known by the State of California to cause cancer or reproductive harm. California law requires businesses to warn customers of potential exposure to such substances. To minimize exposure to these substances, always operate this unit according to the use and care manual, ensuring you provide good ventilation when cooking with gas.

  • Page 3: General Safety Precautions

    Artisan A division of Superior Equipment Solutions, Inc. 1085 Bixby Drive ™ City of Industry, CA. 91745 Ph.: (888) 383-8800 Fax: (323) 726-4700 3020914 Web: www.artisangrills.com GENERAL SAFETY PRECAUTIONS: DANGER WARNING IF YOU SMELL GAS: DO NOT STORE OR USE GASOLINE OR OTHER FLAMMA-...
  • Page 4 READ THIS CARE AND USE MANUAL CAREFULLY AND COMPLETELY BEFORE USING YOUR POWER BURNER TO REDUCE THE RISK OF FIRE, BURN HAZARD OR OTHER INJURY. KEEP THIS MANUAL FOR FUTURE REFERENCE. When properly cared for, your ™ Power Burner will give safe, reliable service for many years.
  • Page 5 Never lean over a hot pot or pan while operating Power Burner. • (Safety, cont.) When lighting a burner, always pay close attention to what you are doing. Be certain you are de- • pressing the correct igniter button labeled for the burner you intend on using. When using the Power Burner do not touch the Power Burner grate or immediate surrounding area •...

  • Page 6: Built-In Models

    This appliance should NOT be located over, under or next to unprotected combustible construction. ASSEMBLY: BUILT-IN MODELS: To locate your Artisan™ Power Burner into your Non-combustible enclosure, complete the following steps: 1. Remove all packaging materials 2. Install and secure the body of the Power Burner to your counter’s enclosure.

  • Page 7: Electrical Requirements

    The burner should not rock side-to-side nor top-to-bottom if properly installed. If excessive burner movement is present, reseat burner or contact your authorized service provider. ELECTRICAL REQUIREMENTS: The ARTP-PB Power Burner is equipped with a high output electrical ignition system and accent lights on the front panel of the unit.
  • Page 8 LP GAS CONNECTION TO LP TANKS: Your Artisan™ Power Burner for use with LP gas comes equipped with its own regulator, which MUST NOT be removed. There is also a secondary high capacity, hose/regulator assembly for connection to a standard 20 Lb. LP cylinder. The LP gas pressure regulator and hose supplied with this unit must be used without alteration.
  • Page 9 Ensure that the service pipe supplying the Power Burner is fitted with a shut off valve conveniently positioned and easily accessible as an emergency gas shutoff. Your Artisan™ Power Burner for use with Natural Gas comes equipped with its own regulator which MUST NOT be removed.

  • Page 10: Leak Testing

    LEAK TESTING: GENERAL: Although all gas connections on your Artisan™ Power Burner are leak tested at the factory prior to ship- ment, a complete gas tightness check must be performed at the installation site due to possible mishan- dling in shipment, or excessive pressure unknowingly being applied to the unit.

  • Page 11: Before Testing

    BEFORE TESTING: Make sure that all packing material is removed from the Power Burner. • Make sure the burner tie-down straps are removed from the unit. • Do not smoke while leak testing. • Never leak test with an open flame. •...

  • Page 12: Lighting Instructions

    LIGHTING INSTRUCTIONS: WARNING BEFORE LIGHTING… COVER MUST BE OPEN WHEN LIGHTING THE BURNER. COVER SHOULD NOT BE CLOSED AT ANY TIME WHEN The pressure regulator and hose assembly supplied with THE BURNERS ARE IN USE. the unit must be used. Never substitute regulators for those supplied with the Power Burner.

  • Page 13: Burner Adjustments

    DAY TO DAY CARE: To maintain the original appearance of your Artisan™ Power Burner, a regular cleaning routine should be carried out using the following guidelines: 1. After use, following the safety precautions detailed on page 4 and 5, wipe the Power Burner with a soft damp soapy cloth and rinse with clean water, preferably warm/hot water.
  • Page 14 7. If required, dry the Power Burner after use with a soft dry cloth or towel. If the preceding guidelines are adhered to, your Artisan™ Power Burner should offer excellent life and should live up to its reputation of being “stainless”.

  • Page 15: Troubleshooting

    TROUBLESHOOTING: BEFORE CALLING FOR SERVICE: If your Artisan™ Power Burner does not function properly use the following checklist before contacting your dealer for service. You may save the cost of a service call and the inconvenience of being without your Power Burner. Additional troubleshooting tips can be found on our website at: www.artisangrills.com.
  • Page 16 ADDITIONAL IMPORTANT CLEANING AND STORAGE CONSIDERATIONS: In order to maintain your Power Burner in clean working order, it will be necessary, under certain condi- tions, to take additional precautions. If your Power Burner is located in a coastal area, it will be exposed to salty air which is corrosive.
  • Page 17 In the event that any light rusting is found on the stainless steel, it will usually not be the stainless steel which is corroding but iron particles which have somehow been deposited on the surface. For more in- formation on this subject, please request our “Rust removal bulletin”. As a first course of action though, we recommend “Bar Keepers Friend”, available from many supermarkets and hardware stores.

  • Page 18: How To Obtain Service

    HOW TO OBTAIN SERVICE For service, please contact our Artisan™ authorized service agency at: (866) 203-5607 Please provide: Model Number • Serial Number (located in Page # 2 of this manual or under the unit) • Gas Type • Date of installation •...

  • Page 19: Service & Replacement Parts

    Care and Use Manual, with no exceptions, and by a qualified professional installer. All replacement components, such as valves, etc, must be an Artisan product. Artisan’s warranty only applies to the original purchaser and may not be transferred, and commences from the date of purchase, and is valid only with proof of purchase.
