PCB Piezotronics IMI SENSORS EX641B72 Installation And Operating Manual page 16

Model Number
641B72
Performance
Measurement Range
Output
Frequency Range (±3 dB)
Broadband Resolution
Non-Linearity
Environmental
Temperature Range
Electrical
Excitation Voltage
Settling Time (within 2% of value)
Electrical Isolation (Case)
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Electrical Connector
Electrical Connection Position
Electrical Connections (Tab 1)
Electrical Connections (Tab 2)
Screw Terminal Wire Size
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without
notice.
ICP® is a registered trademark of PCB group, Inc.
4-20 MA OUTPUT VELOCITY SENSOR
ENGLISH SI
0.0 to 2 in/sec rms 0.0 to 50.8 mm/s rms
4-20 mA 4-20 mA
600 to 60000 cpm 10 to 1000 Hz
0.01 in/sec rms 0.26 mm/s rms
±1 % ±1 %
-40 to 185 °F -40 to 85 °C
12 to 30 VDC 12 to 30 VDC
<15 sec <15 sec
8 8
>10 Ohm >10 Ohm
1.5 in x 3.7 in 38.1 mm x 94 mm
19.5 oz 553 gm
1/4-28 UNF No Metric Equivalent
3 to 5 ft-lb 4 to 7 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Removable Screw Removable Screw
Terminals Terminals
Top Top
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
2
12-24 AWG 3.0 - .2mm
Optional Versions (Optional versions have identical specifications and accessories as listed
[1] for standard model except where noted below. More than one option maybe used.)
EP - Explosion-proof certified conduit housing with 1" pipe thread
[2][3] RV - Buffered Analog Signal Output - 100 mV/g (±20%)
[4] Electrical Connector
Electrical Connections (Tab 1)
Electrical Connections (Tab 2)
Electrical Connections (Tab 3)
Electrical Connections (Tab 4)
Notes
[1] Conversion Factor 1 in/sec = 0.0254 m/sec.
[2] 1Hz = 60 cpm (cycles per minute).
[3] Current will fluctuate at frequencies below 5 Hz.
[4] Typical.
[5] See PCB Declaration of Conformance PS039 for details.
Supplied Accessories
ICS-4 NIST-traceable single-axis amplitude response calibration from 0 cpm (0 Hz) to
upper 10% frequency for 4 - 20 mA output vibration sensor (1)
Entered: LLH Engineer:
MPN
Date: Date:
11/15/2007 11/12/2007
Revision B
ECN #: 27692
Removable Screw Removable Screw
Terminals Terminals
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
Signal Output Pos Signal Output Pos
Signal Output Neg Signal Output Neg
Sales: NJF Approved: LLH Spec Number:
Date: Date: 36552
11/12/2007 11/26/2007
3425 Walden Avenue
Depew, NY 14043
UNITED STATES
Phone: 716-684-0003
Fax: 716-684-3823
E-mail: imi@pcb.com
Web site: www.imi-sensors.com
