Electronic Skip Protection; Lcd Display - Philips Expanium EXP513 Specifications

Portable MP3-CD player
Standard product information
Amplifier/ system
• Output power (in-ear headphone)
2 x 5mW RMS
• 1-Bit D/A convertor for pure sound
reproduction
• Digital dynamic bass boost
• Rotary volume control
• S/N ratio (A weighted) >80 dB
• Frequency response 20 Hz - 20 kHz
• Audible feedback
CD Player
• Supports the CD-ROM, CD-Recordable and
CD-Rewritable in ISO-9660, Joliet format and
UDF
• Playback possibility of 32, 40, 48, 56, 64, 80, 96,
112, 128, 160, 192, 224, 256 and 320 Kbps per
MP3 track
• Supports Variable Bit Rate per track
• Supports CD's that contains music tracks with
mixed bit rates
• 50-track programmable, shuffle album/ all,
repeat one/ album/ all
• Search forward/ backward in tracks
• Resume and hold

Electronic skip protection

• MP3-CD 200-second Magic ESP
at 128Kbps
• Audio CD 100-second ESP tbc

LCD display

• Indications for song & artist name, track & album
number, time, 2-stage DBB, CD functions, ESP and
battery status
Connections
• Headphone/ line out stereo, 3.5 mm
• DC in 4.0 mm, 4.5V, centre '+'
Power supply
• Batteries 2 x 1.5V,
type AA/ LR6/ UM3 cell
• Battery playing time 24 hours (2 AA Alkaline,
MP3-CD) tbc
• Battery playing time 15 hours (2 AA Alkaline,
CD) tbc
• Automatic power switch-off
General
• Weight 0.44 lbs
• Product dimensions 1.1" L x 5.44" W x
5.04" H
• Clamshell weight 2 lbs
• Mastercarton
dimensions tbc
• Mastercarton weight tbc
• Mastercarton quantities 3
• Country of Origin China
• Warranty 12 months
OTC Exchange
Accessories
• AC/DC adapter
• Stereo in-ear headphone
• Belt-clip (detacheable)
• LCD remote control
• Car-kit
More than 10 hours of music on one MP3 CD
One MP3-CD can contain over 10 hours of music or
more than 150 tracks.
Upgradeable for future audio compressed
formats
Future proof technology allows user to upgrade the
playback software to accommodate new audio
compression codec.
My favorite function
Stores up your favourite tracks for playing back.
480-second Magic electronic skip protection
Automatically stores up to 480 seconds of music at
128 Kbps (MP3 format) to prevent music interruptions
caused by shocks.
Dot matrix display supporting ID3 tag
Display that shows name of track, artist and album &
track number for easy navigation.
CD, CD-R and CD-Rewritable compatible
Ensures that all CD's including CD-Recordable and
CD-Rewritable discs, made by any CD-Recorder, can
be played.
Playback of MP3 (16-320 Kbps) and VBR
Supports 16 upto 320 Kbps per MP3 track and
variable bitrate per MP3 track.
24-hour playback with 2 x AA Alkaline batteries
(MP3-CD)
Powersaving technology extends battery playing time
to 24 hours with 2 regular LR6-size (AA) alkaline
batteries.
Digital Dynamic Bass Boost (2-step)
Enhances bass at low, mid and high volume, to give
deep, rich sounds.
Compact disc audio player
Compact Disc technology that provides uncompressed
superb digital sound quality.
Heat resistant body
Unique composite material enables the CD player to
withstand very high temperature.
513
513
EXP
EXP
1-Bit D/A converter
Advanced digital conversion technology ensures crystal-
clear sound.
Hold
Locks all buttons to prevent interruption of play or
change of program settings.
Resume
Bookmark function that ensures the CD starts precisely
from the point it was stopped.
Automatic power off
Automatically switches off the CD player at the end of
a compact disc.
TM Album/ track - plus/ minus
Scrolls through albums and very fast through all songs.
CD next/ previous
Plays the next or previous track at the touch of a
button.
Repeat one/ album/ all
Repeat the current track, the current album or the
total CD.
Shuffle album/ all
Plays album or disc randomly, giving you each time a
new sequence of tracks.
50-track programmable
Stores up to 50 of your favorite tracks for playing
back in your order of preference.
Audible feedback
Confirms any key-push with friendly beep to
acknowledges that a command has been given.
UPC: 0 37849 91935 4
Master Pack UPC: 1 37849 91935 1
Printed 2001-11-16
Specifications subject to modification without notice
© 2001 Koninklijke Philips Electronics N.V.
All rights reserved
