MBD 102239 Quick Start Manual

IP55 Kiosk Single Door
750x750x300mm Flat pack
STOCK CODE: 102239
Suitable for electrical and commercial installations. Complies with the international standard for
empty enclosures as applied to low-voltage switchgear and control gear assemblies (IEC 62208:2011).
KEY FEATURES
• Electromagnetic compatibility, ideal for protecting internal
electronic communication.
• Suitable for low-voltage switchgear and control gear
assemblies, meters, compressors, etc.
• Will not corrode, weather resistant to IP55 grade protection.
• High impact resistance up to 20 Kilojoules (IK10).
• Double insulation and electrically non-conductive (1000V).
• Triple lock system supported by non-corrosive vertical bars.
• Door hinges on right, 180º opening.
• Easily cleaned and can be painted.
SPECIFICATONS
• Constructed from GRP.
• Supplied with hinges, lock and key.
• Polyester back mounting plate (optional) available.
• Supplied in light grey colour (Ral 7035).
• Suitable for use in temperatures ranging from -30ºC to +120ºC.
• Made from non-hygroscopic material ensuring minimum
water absorption.
• Constructed from halogen-free and self-extinguishing
material.
• UV protected.
ASSOCIATED PRODUCTS
• 30.05.012BACK: Backplate
• EC1001: Black Hockey Stick suitable for use inside cavity walls
• EC1002: White Hockey Stick suitable for use on external walls
• 102242: Kiosk Pedestal, 750x750x300 Flat pack
DIMENSIONS
750mm high x 750mm wide x 300mm deep.
The overall height of this box is 814 mm and overall width is 754mm.
The opening size is 719mm x 678mm*.
Buy Online
Example: electrical indirect metering
754mm
300mm
102239-2096/00-MBD-DEC2018
814mm
